- Page 1 Installation Manual info@evb.com www.evb.com WWW.EVB.COM VERSION: 20240116-01...
-
Page 2: Table Of Contents
CONTENTS CONTENTS evb.com evb.com CONTENTS 1. Safety Information P-01 Important safety instructions ● P-01 2. Product Introduction P-02 ● 2.1. Product Appearance P-02 ● 2.2. Parameter table P-03 ● 2. . Product Features P-04 ● 2.4. Protection Functions P-04 3. Installation Instructions P-05 ●... -
Page 3: Safety Information
1. Safety Information 2. Product Introduction evb.com evb.com 2.1. Product Appearance Important safety instructions: this document contains important instructions and warnings that must be followed when installing and maintaining the EV Charger. Warning Read this entire mandatory document before installing or using the EV charger. -
Page 4: Parameter Table
2.3. Product Features Cover opened detection: if the cover is opened, the Charger will alarm in red ligh and stop the work. ● Wallbox Models BCPC-B2N-P BCPC-BT2N-P BCPC-D2N-P BCPC-DT2N-P LCD Screen: The data of the Charger can be seen more directly and clear. -
Page 5: Installation Instructions
3. Installation Instructions 3. Installation Instructions evb.com evb.com 3.3. Minimum Installation Requirements Installation of the wall charger requires that you: ● Calculate the existing electrical load to determine the maximum operating current. ● Calculate the distance to ensure minimal voltage drop. -
Page 6: Accessories List
3. Installation Instructions 3. Installation Instructions evb.com evb.com 3.8. Installation Step 3.7. Accessories List ① ② ③ ④ 3.8.1. Step-by-step Installation Instructions (bottom entry wiring) EV charger Position template Mounting bracket RFID card (optional) wall Step 1 Drill Position The 8 points The bottom of the ⑨... - Page 7 3. Installation Instructions 3. Installation Instructions evb.com evb.com 3.8.1. Step-by-step Installation Instructions (bottom entry wiring) 3.8.2. Step-by-step Installation Instructions (rear entry wiring) wall M6*8 bolts Step 1 Drill Step 3 The 8 points Position Install the EV Charger to the mounting plate on the The bottom of the ⑨...
-
Page 8: Operating Instructions
3. Installation Instructions 4. Operating instructions evb.com evb.com 4.1. Button Usage ● Function Test Button 3.8.2. Step-by-step Installation Instructions (rear entry wiring) light up the LCD screen short press Choose which charging gun to use. (When the screen is on) -
Page 9: Led Lights Display
4. Operating instructions 4. Operating instructions evb.com evb.com 4.3. LED Lights Display Normal Status Normal Status LED Behavior LED Status Status Description Potential Cause Solution LED Behavior LED Status Status Description Potential Cause Solution Green lights up and The Charging... - Page 10 4. Operating instructions 4. Operating instructions evb.com evb.com Fault Status Fault Status LCD Screen/LED Light Status Description LCD Screen/LED Light Status Description LED Behavior Potential Cause Solution LED Behavior Potential Cause Solution 1.Check if the The connection connector is with...
-
Page 11: Warranty
5. Warranty 5. Warranty evb.com evb.com 5. Warranty In order to ensure the normal service life of charging piles and reduce the risks in use, maintenance must be done within the specified time by professionals with accredited safety maintenance tools.
