E2 Lighting E2-T8-2ft-9W-EBBU Quick Start Manual

E2 Lighting International Inc.
LED Emergency T8 Tube
E2-T8-EBBU-ON/OFF-2FT-9W
E2-T8-EBBU-ON/OFF-4FT-18W
Microwave sensor part
long distance sensor (5-8m),sensor time
(30-120s), sensor power (0/3W)
PC Cover
Imported Japan Teijin PC cover, high transmittance,
dustproof, 240 degree beam angle and 140℃
hig temperature resistance
End caps
two types end caps are
available -G13 end cap
& integrated
Specifications
Product Number Wattage
E2-T8-2ft-9W-
EBBU
E2-T8-4ft-18W-
18W
EBBU
The dimming feature is only available with the integration of a microwave or PIR motion sensor.
Tested Data
Technical requirements
CCT
Input Voltage
Working Environment
Dimming Compatible
Base Type
Application
Phone: 213-270-1938 Fax:
Project Name:
Notes:
NEW
Housing material
full PC housing material
anti-corrosion, safety and stability
LED Chip
Imported Taiwan SMD2835 led
chip, high lumen output, high CRI
low heat and long life span
Color Certifications Dimmable
4000K ETL & DLC
9W
5000K Standard
4000K ETL & DLC
5000K Standard
5.0
4000K,5000K
AC100-277V
-4℉-149℉
No
Medium Bi-Pin G13
Double-Ended Bypass (Default)
Singled end (Option)
213-477-2257 Web: www.e2lightingusa.com
Product Description:
E2's G4 series emergency T8 tubes have a 2-in-1
functionality. Able to act as a regular T8 LED tube that
can be turned on/off by wall switch; and as an emergency
tube. E2's T8 emergency tubes are the most efficient and
convenient in the industry, consuming the least amount of
energy in retrofit applications. The T8 LED tube's unique
technology enables the use of an emergency battery pack
built into the LED tube. This is one of the easiest and most
convenient ways to replace a fluorescent system with
an emergency ballast. The tube itself contains a
90-minutebattery pack. ETL listed, DLC Standard listed
and RoHS compliant.
Features
• Emergency battery backup for 90 min or 1.5 hrs
• Test button and indicator lights for power, battery
charging, motion sensor and malfunctioning in line with
fire protection standards
• Internally isolated LED driver
• Built-in lithium batteries with over-charging and over-
discharging protection (800x charge and discharge cycle
lifespan
• Double-Single-Ended power bypass connectivity
• No distortion and no yellowing light
• Light output greater than 120 lm/W
• ETL and DLC Standard 5.0
• 50,000 Hours L70 Lifespan
• 5 year limited warranty
Voltage
®
.
No AC100-277V
®
.
No AC100-277V 2319 lm
Classification
Standard
Input Wattage 8.2W 18W
Power Factor 0.9
Lens Polycarbonate
Beam Angle 220°
Mercury Content No Hg
2ft for 9W
Dimensions
4ft for 18W
E-mail: sales@e2lightingusa.com
Catalog Number:
Fixture schedule:
Lumens Working Hours
998 lm 50,000hrs
50,000hrs
Light Output
998lm 2319 lm
Efficacy >120lm/W
CRI 80
Frequency 50-60HZ
IP Rating IP 44
THD <20%
Weight 0.8 lbs
CRI
80Ra
80Ra
