LMC FORD INNOVAN Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BEDIENUNGSANLEITUNG
FORD INNOVAN
OPERATING MANUAL
GEBRUIKERSHANDLEIDING
MANUEL D'UTILISATION
MANUAL DE INSTRUCCIONES
ISTRUZIONI D'USO
BRUGSANVISNING
KÄYTTÖOHJEET
KULLANIM KILAVUZU
操作说明

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FORD INNOVAN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LMC FORD INNOVAN

Summary of Contents for LMC FORD INNOVAN

  • Page 1 BEDIENUNGSANLEITUNG FORD INNOVAN OPERATING MANUAL GEBRUIKERSHANDLEIDING MANUEL D‘UTILISATION MANUAL DE INSTRUCCIONES ISTRUZIONI D‘USO BRUGSANVISNING KÄYTTÖOHJEET KULLANIM KILAVUZU 操作说明...

  • Page 3: Table Of Contents

    The terms used in these operating instructions with regard to weight specifications are explained again in detail at the end of the operating instructions (legal information on weight-related specifications). For further details on weight specifications, please also refer to the "Weight information" section of our homepage at www.lmc-caravan.com/de/en/weight-information Contents Warranty ........5 ISOFIX child safety seat mounting system ........
  • Page 4 Contents Changing gas bottles ......65 11.2.4 Reducing the water quantity for Gas isolator taps ........66 mobile operation ........98 11.2.5 Draining water ........99 Electrical system ..... 67 11.2.6 Emptying the water system ....99 General safety instructions ....67 11.3 Waste water tank ........
  • Page 5 Contents 14.5 Tightening torque ........ 125 Helpful notes ......139 14.6 Tyre pressure ........125 17.1 Traffic rules in foreign countries ..139 17.2 Help on Europe's roads ...... 139 Troubleshooting ....127 17.3 Gas supply in European countries ..140 15.1 Braking system ........
  • Page 6 Contents 3401120 - 10/23 - EHG-0041-03EN...

  • Page 7: Warranty

    Warranty Warr anty Warranty certificate Vehicle data Model: Car manufacturer/type of engine: Serial number: Delivery date: Initial registration: Purchased from company: Expiry of the warranty period: Key number: Chassis number: Customer address: Surname, Christian name: Street, house number: Postal code, town: Dealer's stamp and signature We reserve the right to alter the construction, equipment and the scope of delivery.
  • Page 8 Warranty 3401120 - 10/23 - EHG-0041-03EN...

  • Page 9: Introduction

    Introduction Introduction Please read this instruction manual completely before using the vehicle for the first time! Always keep this instruction manual in the vehicle. Also inform all other us- ers of the safety regulations.  The non-observance of this symbol can lead to personal injury. ...

  • Page 10: General

    Introduction General The vehicle is constructed in accordance with the latest technology and the recognised safety regulations. Nevertheless, personal injury may result and the vehicle may be damaged if the safety instructions in this instruction man- ual are not followed. Before using the vehicle for the first time, equip it with the legally prescribed equipment (e.g.

  • Page 11: Environmental Tips

    Introduction Environmental tips  Be considerate of the environment.  Remember that: All kinds of waste water and household waste are not to be disposed of in drains or in the open countryside. On board, collect waste water only in the waste water tank or – if neces- ...
  • Page 12 Introduction 3401120 - 10/23 - EHG-0041-03EN...

  • Page 13: Safety

    Safety Saf ety Chapter overview This chapter contains important safety instructions. The safety instructions are for the protection of persons and property. Fire prevention 3.1.1 Avoidance of fire risks  Never leave children in the vehicle unattended.  Keep flammable materials clear of heating and cooking appliances. ...

  • Page 14: General

    Safety General  The oxygen in the vehicle interior is used up by breathing and the use of gas operated appliances. That is why the used air must be replaced permanently. For this purpose, forced ventilation options (e.g. sky- lights with forced ventilation) are fitted to the vehicle. Never cover or block forced ventilations from the inside or outside with objects such as e.g.
  • Page 15 Safety  During the journey, persons are only to sit on the permitted seats (see chapter 5). The authorised number of seats is stipulated in the vehicle documents.  Seat belts must be worn by all passengers.  Fasten your seat belts before the beginning of the journey and keep them fastened during the journey.

  • Page 16: Towing

    Safety  When using snow chains, the tyres, wheel suspension and steering are subjected to an additional load. When using snow chains, drive slowly (maximum speed 50 km/h) and only on streets which are completely covered with snow. Otherwise the vehicle could be damaged. Towing ...

  • Page 17: Gas Bottle

    Safety  Before using the cooker make sure that there is sufficient ventilation. Open a window or the skylight.  Do not use the gas cooker for heating purposes.  If there are several gas devices, each gas device must have its own gas isolator tap.

  • Page 18: Electrical System

    Safety  Depending on the connection, unscrew the gas tube from the gas bot- tle and screw it on the gas bottle again by hand or using an suitable special spanner. The screw connection on the gas bottle generally has a left-hand thread. Do not tighten too firmly. ...

  • Page 19: Before The Journey

    Before the journey Before the journ ey Chapter overview This chapter contains important information which has to be noted before commencing your journey or carrying out any tasks before the journey. At the end of the chapter there is a checklist which once again summarises the most important points.

  • Page 20: Terms

    Before the journey  If you drive the vehicle even though it exceeds the technically permissi- ble maximum laden mass specified by the manufacturer, you may face legal consequences, such as a fine or loss of insurance. Description Max. load (kg) Maximum permissible Double bed (transverse rear bed) payloads...
  • Page 21 Before the journey Mass in running order The mass in running order is the weight of the ready-to-drive series vehicle (excluding optional equipment fitted at the factory). The mass in running order is made up as follows: ⚫ Unladen weight (mass of the empty vehicle) with factory-installed stand- ard equipment (excluding optional equipment fitted at the factory) ⚫...
  • Page 22 Before the journey  We will inform your dealer of the actual weighed mass of your vehicle and the remaining load capacity when we issue the invoice. Your dealer is required to pass on the information to you. If you have not received this information, you can contact your dealer and request it.

  • Page 23: Calculating The Vehicle Load Capacity

    Before the journey ⚫ Toiletries ⚫ Small electrical appliances (e.g. coffee machine) No matter where kept, personal equipment also includes: ⚫ Animals ⚫ Bikes ⚫ Sports equipment For the personal equipment, according to the applicable regulations, the manufacturer must use a minimum weight that is determined according to the following formula: Formula Minimum weight M (kg) = 10 x N + 10 x L...

  • Page 24: Load Securing And Load Distribution

    Before the journey The calculation of the vehicle load capacity from the difference between the technically permissible maximum laden mass and the actual vehicle mass specified by the manufacturer is however only a theoretical value. Only if the vehicle is weighed on a public scale with filled tanks (fuel and wa- ter), filled gas bottles and complete optional equipment (and accessories) can the actual vehicle load capacity be determined.
  • Page 25 Before the journey Large storage compartments also offer room for heavy objects. The mass on the front or rear axle may be exceeded as a result. However, the individual axles may not be overloaded under any circum- stances. That is why it is important, at which distance to the axles the load is stored.
  • Page 26 Before the journey To distribute the load correctly, you will need a scale, a tape measure, a cal- culator and some time. Two simple formulas are needed to calculate the effect of the weight of the load on the axles: Formulas A x G : R = weight on the rear axle Weight on the rear axle –...
  • Page 27 Before the journey  Please note that the mass on the respective axles or axle groups may differ. For this reason, please read the information provided in the regis- tration papers carefully.  If you drive the vehicle even though it exceeds the technically permissi- ble maximum laden mass on the axle specified by the manufacturer, you may face legal consequences, such as a fine or loss of insurance.

  • Page 28: Rear Storage Space

    Before the journey Increase and reduction of In the case of an increase of load capacity, a change in the chassis usually load capacity increases the technically permissible maximum laden mass of the vehicle, the technically permissible maximum laden mass on the axle and, as a re- sult, the remaining load capacity for luggage, camping equipment, etc.

  • Page 29: Roof Rack With Led Lamps And Rear Ladder (Optional)

    Before the journey When loading the rear storage space, please observe the following instruc- tions to ensure safe driving: ⚫ Baggage and items carried in the rear storage space must also be evenly distributed in accordance with the section "Load securing and load distribution"...

  • Page 30: Towing

    Before the journey Towing  Care is to be taken when connecting and detaching a trailer. Risk of accident and injury!  No persons are to be between the towing vehicle and the trailer during positioning for connecting and detaching. ...

  • Page 31: Removable Partition Wall

    Before the journey Emergency operation If the entrance step does not retract electrically due to a defect, it must be pushed in by hand and secured against sliding out.  The entrance step may only be moved by hand when the drive rods have been released.

  • Page 32: Flat Screen

    Before the journey Flat screen  Before commencing the journey, store the flat screen securely. Gas regulator  Operating gas-operated appliances during the journey is permitted only if the gas system has the relevant equipment. The hose break guard and crash sensor prevent an escape of gas in the event of an accident.

  • Page 33: Snow Chains

    Before the journey Gas regulator with crash If a gas regulator with a crash sensor (Fig. 7,1 and Fig. 8,1) and hose break sensor and hose break guard (Fig. 7,2 and Fig. 8,2) is installed in the vehicle: guard The regulator tap on the gas bottle and the "Heater" gas isolator tap may remain open during the journey.
  • Page 34 Before the journey Before commencing the journey, work through the checklist: Checks Checked Base vehicle All vehicle documents are on board Tyres in proper condition and tyre pressure correct Vehicle lighting, brake lights and reversing lights function Oil levels for engine, gearbox and power steering controlled Coolant and fluid for windscreen washers filled up Brakes function Brakes react evenly...
  • Page 35 Before the journey Checks Checked Gas system Gas bottles firmly fixed in the gas bottle compartment so that they are unable to turn If the gas bottles are not connected to the gas tube, always place the protective cap on top Regulator tap on the gas bottle and gas isolator taps are closed ...
  • Page 36 Before the journey 3401120 - 10/23 - EHG-0041-03EN...

  • Page 37: During The Journey

    During the journey During th e jou rney Chapter overview This chapter contains instructions on how to drive the Camper Van. Driving the Camper Van  The base vehicle is a commercial vehicle (small truck). Adjust your driving technique accordingly. ...

  • Page 38: Brakes

    During the journey  Some add-on parts can be damaged at higher speeds: ̶ If the vehicle is equipped with a Teleco satellite unit: Do not drive faster than 160 km/h. ̶ If the vehicle is equipped with a Heki skylight (mini or midi): Do not drive faster than 160 km/h.

  • Page 39: Fastening The Seat Belts Correctly

    During the journey  Only attach the child restraint system to seats that are specified for this purpose. If the front passenger's seat airbag is activated, only for- ward-facing child restraint systems may be used on the front passen- ger's seat. ...

  • Page 40: Isofix Child Safety Seat Mounting System

    During the journey Fig. 9 Warning notice on child restraint system (front passenger's seat sun visor) The front passenger's seat is equipped with an airbag. When this airbag is No rearward-facing child restraint systems on the activated, it is not permitted to use a rearward-facing child restraint system front passenger's seat on the front passenger's seat.
  • Page 41 During the journey Fig. 10 Seat with ISOFIX Fig. 11 Fastening with top tether Retaining clip Connector ISOFIX symbol Retaining clip Top tether symbol Fixing hook Child seat Top tether strap Slot ◼ Child restraint systems with Pull the headrest all the way up. top tether: ◼...

  • Page 42: Driver's Seat And Front Passenger's Seat

    During the journey Driver's seat and front passenger's seat  Before commencing the journey, rotate all swivel seats in the direction of travel and lock in position.  The seats must remain fixed in position during the journey and are not to be rotated.

  • Page 43: Setting Up The Camper Van

    Setting up the Camper Van Setting up th e C amp er Van Chapter overview This chapter contains instructions on how to pitch the vehicle at the campsite.  Pitch the vehicle so that it is as horizontal as possible. Use ramps where necessary.
  • Page 44 Setting up the Camper Van 3401120 - 10/23 - EHG-0041-03EN...

  • Page 45: Living

    Living Livin g Chapter overview This chapter contains instructions about living in the vehicle. Doors  Only drive with locked doors.  Locking the doors can prevent them from opening of their own accord, e.g. during an accident.  Locked doors also prevent forced entry, e.g. when waiting at traffic lights.

  • Page 46: External Flaps

    Living External flaps  Before commencing the journey, close all external flaps and lock them.  To open and close the external flap, open or close all locks that are fitted to the external flap.  When leaving the vehicle, close all external flaps. The external flaps fitted to the vehicle are all fitted with identical locking cyl- inders.

  • Page 47: Hinged Window

    Living  When leaving the vehicle, always close the windows.  In extreme weather conditions or if the temperature fluctuates strongly, a light condensation film can form on the double-glazed acrylic glass. The glass is designed in such a way that condensation can evaporate when the external temperature increases.
  • Page 48 Living Fig. 15 Catch lever in "continuous ventilation" position Continuous ventilation With the catch lever, the hinged window can be placed in two positions: ⚫ "Continuous ventilation" (Fig. 15) ⚫ "Firmly closed" (Fig. 13). To place the hinged window into the "continuous ventilation" position: ◼...

  • Page 49: Roman Shade And Insect Screen

    Living 7.4.2 Roman shade and insect screen The windows are fitted with a Roman shade and an insect screen. The in- sect screen and the Roman shade can be operated together or separately. Fig. 16 Hinged window Fig. 17 Catch Roman shade The Roman shade (Fig.

  • Page 50: Cabin Black-Out Shade With Textile Curtain (Standard)

    Living 7.4.3 Cabin black-out shade with textile curtain (standard)  Before commencing the journey, remove the cabin black-out shade and store it securely. Hat shelf Sun visor Fig. 18 Hat shelf ◼ Closing: Remove the cabin black-out shade from the wall unit in the driver's cabin.
  • Page 51 Living Handle Fig. 19 Side window with folding blind ◼ Closing the driver's door Pull the folding slider blind by the handle (Fig. 19,1) in the direction of and the front passenger's the arrow (as far as it will go). A magnetic catch keeps the folding blind door shades: closed.

  • Page 52: Skylights

    Living Skylights Skylights with and without forced ventilation are installed in the vehicle. The smaller skylights in the living area and in the bathroom are equipped with forced ventilation.  The apertures for forced ventilation must always be kept open. Never cover or block forced ventilations with objects such as e.g.

  • Page 53: Skylight With Snap Latch

    Living 7.5.1 Skylight with snap latch Fig. 21 Skylight with snap latch The skylight can be pushed upwards either from one side or from both sides. ◼ Opening: Pull on the handle (Fig. 21,3). ◼ Fold insect screen (Fig. 21,4) downward. ◼...

  • Page 54: Heki Skylight

    Living 7.5.2 Heki skylight  The Heki skylight can be damaged at high speeds. Therefore, do not drive the vehicle faster than 160 km/h.  If the vehicle is to be transported: do not load the vehicle backwards. Otherwise, the Heki skylight may be damaged. Fig.

  • Page 55: Tables

    Living Roman shade To close and open the Roman shade: ◼ Closing: Pull out Roman shade at the handle and release in the required position. The Roman shade will stay in that position. ◼ Opening: Slowly push the Roman shade at the handle to its initial position. Insect screen To close and open the insect screen: ◼...

  • Page 56: Pvc-Floor Covering

    Living ◼ Conversion into bed Lift the front of the table top (Fig. 26,6) by approx. 45°. foundation: ◼ Pull out the lower part of the support leg (Fig. 26,4) down and lay aside. ◼ Remove the table top from the upper retainer. ◼...

  • Page 57: Lighting System And Usb Socket

    Living 7.8.1 Lighting system and USB socket  Bulbs and lamp holders can be extremely hot.  Allow the light bulbs and lamp holders to cool down before touching them.  If the light is switched on or still hot, there must always be a safety dis- tance of at least 30 cm between stores or curtains and flammable ob- jects.

  • Page 58: Tv Unit

    Living ◼ Removing fluorescent tube: Release and shift one of the brackets away from the lamp body. ◼ Remove lamp body. ◼ Turn both brackets through 90° and remove from rail. Fig. 29 USB socket element The USB socket element (Fig. 29,1) can be inserted, turned, and removed in the same way as the spotlight.

  • Page 59: Beds

    Living 7.10 Beds 7.10.1 Transverse rear bed  The maximum load of the rear bed is 200 kg.  But in particular with regard to small children less than 6 years of age, users should ensure that they cannot fall out of the bed. Fig.

  • Page 60: Converting Seating Group For Sleeping

    Living 7.11 Converting seating group for sleeping A removable board and two additional cushions are required for the conver- sion. The removable board and the two additional cushions are strapped in place for storage above the left rear bed. ◼ Push both seats in the driver's cabin fully forwards.

  • Page 61: Gas System

    Gas system Gas system Chapter overview This chapter contains instructions regarding the gas system of the vehicle. The operation of the gas operation appliances of the vehicle is described in chapter 10. General instructions  The operator of the gas system is responsible for the performance of recurring inspections and for complying with the maintenance inter- vals.

  • Page 62: Gas Bottles

    Gas system  The built-in gas devices are exclusively meant for use with propane or butane gas or a mixture of both. The gas pressure regulator as well as all built-in gas devices are designed for a gas pressure of 30 mbar. ...

  • Page 63: Gas Pressure Regulating System Duocontrol Cs

    Gas system  Use only 11 kg or 5 kg gas bottles. (The size of the gas bottles may vary depending on the country.)  Use the shortest possible tube lengths (150 cm max.) for external gas bottles.  Never block the floor ventilation openings below the gas bottles. ...
  • Page 64 Gas system Fig. 36 Gas pressure regulating system DuoControl CS Status indicator primary bottle / reserve bottle (green/red) Gas filter High-pressure hose Hose break guard Gas bottle regulator tap Knob for switching from primary bottle to reserve bottle Screw cap (test connection) Yellow reset button of the crash sensor Reversing valve with crash sensor Construction of the unit...
  • Page 65 Gas system Yellow indicator lamp, defroster Winter operation position OFF position Summer operation position Red indicator lamp, primary bottle empty Green indicator lamp, supply from primary bottle Rocker switch Fig. 37 Operating unit (DuoControl) Operating unit At the operating unit (Fig. 37), the gas supply via the DuoControl regulating system is switched on and off.
  • Page 66 Gas system Fig. 38 Correct connection of the gas bottle If the green indicator lamp (Fig. 37,6) goes out during operation and the red indicator lamp (Fig. 37,5) lights up, the primary bottle is empty and must be changed. The red marking is shown by the status indicator (Fig. 36,1). The reserve bottle continues supplying the gas appliances with gas.

  • Page 67: Changing Gas Bottles

    Gas system Changing gas bottles  When changing gas bottles, do not smoke or create any open fire.  When you have changed the gas bottle, check whether gas escapes at the connection points and unions. Use a leakage search spray to spray the relevant connection point or union.

  • Page 68: Gas Isolator Taps

    Gas system Gas isolator taps For every gas-operated device there is a gas isolator tap installed in the ve- hicle. The gas isolator taps are installed in the seating group. Heater / hot water gas isolator tap, closed Cooker gas isolator tap, open Fig.

  • Page 69: Electrical System

    Electrical system Electrical syst em Chapter overview This chapter contains instructions regarding the electrical system of the ve- hicle. The operation of the electrical appliances of the housing body is described in chapter 10. General safety instructions  Only allow qualified personnel to work on the electrical system. ...

  • Page 70: Power Supply

    Electrical system Capacity Capacity refers to the amount of electricity which can be stored in a battery. The capacity of a battery is given in ampere hours (Ah). The so-called K20 value is normally used. The K20 value indicates how much current a battery is able to dispense over a time period of 20 hours without causing damage, or how much current is required to charge a flat battery within 20 hours.

  • Page 71: Living Area Battery Type Agm

    Electrical system 9.3.1 Living area battery Type AGM  Disconnecting and connecting the terminals, as well as changing the liv- ing area battery shall only be carried out by qualified personnel. In the event of an incorrect connection, there is the risk of short circuit and fire due to rubbing cables.

  • Page 72: Charging Batteries Via A 230 V Power Supply

    Electrical system Note that even a fully charged living area battery can be fully discharged by closed circuit currents (inactive appliances). Low temperatures outside reduce the capacity available. The self-discharge rate of the battery is also dependant on temperature. At 20 to 25 °C the self-discharge rate is approx.
  • Page 73 Electrical system  Do not connect the battery cables to the wrong poles (red cable -> positive pole, black cable-> negative pole).  Do not actuate the ignition if the terminals of the battery are discon- nected. Danger of short circuit! ...

  • Page 74: Charging Booster For The Living Area Battery

    Electrical system 9.3.5 Charging booster for the living area battery  Do not carry out any maintenance or repair work on the device. There is an electrical shock hazard and risk of fire.  If the housing or the cables are damaged: do not put the device into operation.
  • Page 75 Electrical system Fig. 41 Transformer/rectifier (EBL 31) Block 6: Solar charge regulator (if fitted) Block 1: Refrigerator Block 2: Control lines Block 4: Heating, basic light (lighting in the entrance area), entrance step Block 3: Panel Block 5: Spare, sockets, basic light Block 7: Auxiliary charging unit Block 8: Appliances, TV, water pump, spare, multimedia, sockets Battery selector switch (Gel/AGM)

  • Page 76: Battery Cut-Off Switch

    Electrical system 9.4.1 Battery cut-off switch  After switching the battery cut-off switch back on again: Put the basic light (lighting in the entrance area), entrance step, heater and spare 4 back into service (depending on the model). To do so, switch on the 12 V main switch briefly.

  • Page 77: Charging The Battery

    Electrical system 9.4.4 Charging the battery When the vehicle engine is running, a relay in the transformer/rectifier alter- nator switches on the living area battery and the starter battery together and recharges them with the vehicle generator. When the vehicle engine is switched off, the batteries are automatically disconnected from one another again by the transformer/rectifier.

  • Page 78: Panel (Lt 100)

    Electrical system Panel (LT 100) Fig. 42 Panel (LT 100) Button to query the voltage of the living area battery Button to query the fill level in the fresh water tank Button to query the fill level in the waste water tank LED array to display the tank fill level LED array to display the battery voltage 12 V main switch and green LED...

  • Page 79: Led Array For Battery Voltage

    Electrical system 9.5.2 LED array for battery voltage The LED array (Fig. 42,5) displays the battery voltage of the living area bat- tery as follows: ⚫ All LEDs light up: Battery is sufficiently charged. ⚫ Yellow and red LED are lit: Battery is partly discharged. ⚫...

  • Page 80: Led Array For Tank Fill Level

    Electrical system The following table helps to correctly interpret the displayed battery off-load voltage. The specified values are guide values for dryfill batteries. LT 100 indicator Off-load voltage values Battery charge Red LED flashes 11.0 V or less Battery is fully discharged Red and yellow LED are lit 11.0 V to 12.2 V Battery is discharged to totally discharged...

  • Page 81: Power Supply

    Electrical system 230 V power supply  Only allow qualified personnel to work on the electrical system.  Have the vehicle's electrical system checked by a qualified electrician at least once every 3 years. If the vehicle is used frequently, an an- nual check is recommended.
  • Page 82 Electrical system Fig. 43 Safety cut-out and FI-switch Fig. 44 230 V connection on the ve- (230 V fuse box) hicle (CEE socket outlet) ◼ Connecting the vehicle: Check whether the power supply device is suitable regarding connec- tion, voltage, frequency and current. ◼...

  • Page 83: Fuses

    Electrical system Fuses  Only replace defective fuses when the cause of the defect is known and has been remedied.  Replace defective fuses only after the power supply has been turned off.  Never bridge or repair fuses.  Only replace faulty fuses with a new fuse with the same rating. 9.7.1 12 V fuses The appliances connected to the 12 V power supply in the living area are...
  • Page 84 Electrical system Fuses on the living area The fuses are installed in the rear, on the left in the bedding box. battery Vehicles with one living area battery and small booster: Flat fuse 2 A/grey (voltage sensor for transformer/rectifier) Jumbo flat fuse 40 A/orange (living area battery) Jumbo flat fuse 20 A/yellow (refrig- erator)

  • Page 85: Fuse

    Electrical system 9.7.2 230 V fuse  Check the fault current protection switch for each connection to the 230 V power supply, at least once every 6 months. Fig. 49 230 V fuse box with safety cut-out and FI-switch A fault current protection switch (FI-switch) in the fuse box protects the com- plete vehicle from fault current (0.03 A).
  • Page 86 Electrical system 3401120 - 10/23 - EHG-0041-03EN...

  • Page 87: Appliances

    Appliances Appliances Chapter overview This chapter contains instructions regarding the appliances of the vehicle. The instructions refer exclusively to the operation of the appliances. Further information about the appliances can be found in the instruction manuals for the appliances, included separately with the vehicle. 10.1 General ...

  • Page 88: Heater / Production Of Hot Water

    Appliances 10.2 Heater / production of hot water The heater can both heat up the vehicle interior (heating the room air) and heat up the domestic water (boiler function). The following instructions are also valid if the heater is only used as boiler. ...

  • Page 89: To Heat Properly

    Appliances 10.2.1 To heat properly Fig. 51 Air outlet nozzle (hot-air heater) Hot air distribution Several air outlet nozzles (Fig. 51) are built into the vehicle. Pipes conduct the warm air to the air outlet nozzles. Turn the air outlet nozzles in a suitable position so the air can escape as required.
  • Page 90 Appliances Summer operation water tempera- ture 60 °C Summer operation water tempera- ture 40 °C Winter operation "Only heater" Winter operation "Heater and pro- duction of hot water" Rotary switch (external ring) Indicator lamp "Heater operation" (green) Temperature control knob Indicator lamp "Heating up period of Fig.
  • Page 91 Appliances Summer operation It is not possible to heat the vehicle in "Summer" operating mode. In this op- erating mode, only the domestic water is heated up to 40 °C or 60 °C. ◼ Switching production of hot Open the regulator tap on the gas bottle and the gas isolator tap water on: "Heater/boiler".

  • Page 92: Diesel Heater And Production Of Hot Water (Truma Combi D)

    Appliances ◼ Set all the water taps to "Hot" and open them. The water pump is turned on. The warm water pipes are filled with water. ◼ Keep the water taps open until the water flowing out of the water taps has no bubbles in it.

  • Page 93: Gas Cooker

    Appliances Fig. 54 Wall flue (hot-air heater) The wall flue is mounted on the left side wall. 10.3 Gas cooker  During operation of the gas cooker, do not leave the gas cooker unat- tended. Even if the gas cooker cannot be overseen for only a short time (e.g.
  • Page 94 Appliances  Do not use the glass gas cooker cover as a hob.  Do not close the gas cooker cover while the gas cooker is in operation.  Do not apply pressure on the gas cooker cover when it is closed. ...

  • Page 95: Refrigerator

    Appliances ◼ Turn the control knob to the desired position between "Smallest flame" (Fig. 58,5) and "Largest flame" (Fig. 58,6). ◼ If ignition is unsuccessful, repeat the entire procedure. ◼ Switching off: Turn the control knob (Fig. 58,4) to position 0 (Fig. 58,2). ◼...

  • Page 96: Compressor Refrigerator Dometic Series 10 (Rc10.4T.70)

    Appliances 10.4.2 Compressor refrigerator Dometic series 10 (RC10.4T.70)  All carrying grates in the refrigerator are fixed, so that children cannot climb into the refrigerator and get locked in accidentally. Remove car- rying grates for cleaning and insert and fix them in the same place af- ter cleaning.

  • Page 97: Sanitary Fittings

    Sanitary fittings San itar y fitting s Chapter overview This chapter contains instructions regarding the sanitary fittings of the vehi- cle. 11.1 Water supply, general  Fill water tank from supply systems that have been verified to provide drinking water quality. ...

  • Page 98: Water Tank

    Sanitary fittings 11.2 Water tank The water tank holds approx. 100 l.  For driving safety and for regulatory reasons, when the vehicle is motion the fill quantity must be reduced. If the water is drained using the safety drainage rotary handle (see section 11.2.4), a residual quantity of ap- proximately 20 litres will remain in the water tank.

  • Page 99: Filling The Water System

    Sanitary fittings 11.2.2 Filling the water system  When filling the water tank, observe the maximum permissible gross weight of the vehicle. Luggage must be reduced accordingly when the water tank is full.  The water pump will overheat without water and can get damaged after one minute at the latest.

  • Page 100: Topping Up The Water

    Sanitary fittings 11.2.3 Topping up the water  When filling the water tank, observe the maximum permissible gross weight of the vehicle. Luggage must be reduced accordingly when the water tank is full. To fill the water tank with drinking water, proceed as follows: ◼...

  • Page 101: Draining Water

    Sanitary fittings 11.2.5 Draining water Fig. 64 Water tank with rotary handle ◼ Turn the rotary handle (Fig. 64,1) on the water tank in an anticlockwise direction as far as possible beyond the resistance to fully open the drain- age opening. 11.2.6 Emptying the water system ...
  • Page 102 Sanitary fittings Fig. 65 Safety/drainage valve closed Fig. 66 Safety/drainage valve open The safety/drainage valve is installed in the bench seat behind the driver's Position seat. ◼ Open the safety/drainage valve (Fig. 65). To do this, turn the knob (Fig. 65,1) parallel to the safety/drainage valve. The push button (Fig.

  • Page 103: Waste Water Tank

    Sanitary fittings 11.3 Waste water tank  In case of frost add so much anti-freeze (such as kitchen salt) to the waste water tank so that the waste water cannot freeze.  Never pour boiling water directly into the sink outlet. Boiling water could cause deformation and leaks in the waste water pipe system.

  • Page 104: Insulated And Heated Waste Water Tank

    Sanitary fittings 11.4 Insulated and heated waste water tank Depending on the model and the equipment, the vehicle will have been equipped with an insulated and heated waste water tank, as well as with an automatic control of the waste water tank heater. If the On/Off switch of the control has been switched on (Fig.

  • Page 105: Toilet

    Sanitary fittings Fig. 71 Toilet compartment with shower ◼ For showering, close the door (Fig. 71,1) and completely close the shower curtain (Fig. 71,2) so that all walls are protected. ◼ Pull shower handset out and hook it into the opening provided for this purpose on the shower curtain.

  • Page 106: Swivel Toilet

    Sanitary fittings 11.6.1 Swivel toilet The flushing of the toilet is fed directly from the water system of the vehicle. Fig. 72 Toilet The toilet bowl can be rotated into the required position. In order to do this, grab the toilet's upper part (Fig. 72,2) with both hands and rotate it. The operating unit with the flush button (Fig.

  • Page 107: Winter Operation

    Sanitary fittings ◼ Press both push-button locks (Fig. 73,2) simultaneously with your thumb and open the flap for the sewage tank. ◼ Swivel flap fully upwards and carefully set on the exterior wall. The flap is kept open magnetically. ◼ Pull the retaining clip (Fig.
  • Page 108 Sanitary fittings 3401120 - 10/23 - EHG-0041-03EN...

  • Page 109: Care

    Care Car e Chapter overview This chapter contains instructions regarding the care of the vehicle. At the end of the chapter there is a checklist of measures you must carry out if you are not going to use the vehicle for an extended period of time. 12.1 External care 12.1.1...

  • Page 110: Washing The Vehicle

    Care 12.1.3 Washing the vehicle  Never clean the vehicle in the car wash. The brush rollers can damage the external applications. Water can enter the waste gas vents or the forced ventilations. The vehicle could be damaged. ◼ Wash the vehicle only on a washing site intended for this purpose. ◼...

  • Page 111: Underbody

    Care 12.1.5 Underbody The underbody of the vehicle is partly coated with an age-resistant under- body protection. Should the underbody protection be damaged, repair imme- diately. Do not treat areas coated with underbody protection with spray oil.  Only use products approved by the manufacturer. Our authorised deal- ers and service centres will be happy to advise you.

  • Page 112: Interior Care

    Care 12.2 Interior care  If possible, treat stains immediately.  Acrylic glass windows are delicate and require very careful handling (see section 12.1.4).  Synthetic parts in the toilet and living area are very delicate and should be treated with care. Do not use solvents, alcohol-containing cleansers or scourers.

  • Page 113: Refrigerator

    Care ◼ Brush blinds with a soft brush or vacuum with the brush attachment of the vacuum cleaner. Grease or stubborn dirt may be removed with a mild soap at 30 °C (curd soap). ◼ Brush Roman shades with a soft brush or vacuum with the brush attach- ment of the vacuum cleaner.

  • Page 114: Water System

    Care ◼ Removing rust stains: Clean the stainless steel surface with an ordinary household sponge and with cleanser. If necessary, use a soft cleaning cloth and stainless steel cleaner. ◼ Rinse the stainless steel surface and dry it with household wipes. 12.4 Water system 12.4.1...

  • Page 115: Disinfecting The Water System

    Care ◼ Set all water taps to "Cold" and open them. ◼ Leave the water taps open until the mixture of water and cleaning agent has reached the drain. ◼ Close all water taps. ◼ Flush the toilet several times. ◼...

  • Page 116: Care For Vehicle Operation In Winter

    Care 12.5 Care for vehicle operation in winter De-icing salt damages the underbody and the parts open to water spray. We recommend that you wash the vehicle more frequently during wintertime. Mechanical and surface treated parts and the underside are under particular strain, and should therefore be cleaned thoroughly.

  • Page 117: Lay-Up

    Care 12.6 Lay-up 12.6.1 Temporary lay-up  If the vehicle has been stationary for a long period (approx. 10 months) have the braking and gas systems checked by an author- ised specialist workshop.  Take into consideration that water is undrinkable after only a short time.
  • Page 118 Care Activity Done Interior Place upholstery in an upright position for ventilation, and cover Clean refrigerator Allow refrigerator and freezer compartment doors to remain slightly open Search for traces of animals that have gained entry Disconnect the flat screen from the mains and, if necessary, remove it from the vehicle Gas system Close regulator tap on the gas bottle...

  • Page 119: Winter Lay-Up

    Care 12.6.2 Winter lay-up Additional measures are required if laying up the vehicle over winter: Activity Done Base vehicle Clean body and underbody thoroughly and spray with hot wax or pro- tect with varnish Fill fuel tank with winter diesel Check antifreeze in the cooling water Rectify damage to the paintwork Fill in windscreen washer fluid with frost protection...

  • Page 120: Starting Up The Vehicle After A Temporary Lay-Up Or After Lay-Up Over Winter

    Care 12.6.3 Starting up the vehicle after a temporary lay-up or after lay- up over winter Go through the following checklist before start-up: Activity Done Base vehicle Check the tyre pressure on all tyres Check the tyre pressure of the spare wheel (if present) Body Check the function of the entrance step Check that the doors, windows and skylights are working properly...

  • Page 121: Maintenance

    Maintenance Mainten an ce Chapter overview This chapter contains instructions about official inspections and inspection and maintenance work in the vehicle. At the end of the chapter you will find important instructions on how to obtain spare parts. 13.1 Official inspections Depending on the national legislative provisions, the following official inspec- tions must be carried out periodically: ⚫...

  • Page 122: Inspection Work

    Maintenance 13.2 Inspection work Like any technical appliance, the vehicle must be inspected at regular inter- vals. This inspection work must be carried out by qualified personnel. Special technical knowledge, which cannot be taught within the framework of this instruction manual, is required for these tasks. Personnel possessing this technical knowledge are available for assistance at all service centres.

  • Page 123: Spare Parts

    Maintenance 13.5 Spare parts  Every alteration of the original condition of the vehicle can alter road behaviour and jeopardize road safety.  The optional equipment and original spare parts recommended by us have been specially developed and supplied for your vehicle. These products are available at your dealer.

  • Page 124: Warning And Information Stickers

    Maintenance 13.7 Warning and information stickers There are warning and information stickers on and inside the vehicle. Warn- ing and information stickers are for the sake of safety and must not be re- moved.  Replacement stickers can be obtained from an authorised dealer or a service centre.

  • Page 125: Wheels And Tyres

    Wheels and tyres Wheels and tyr es Chapter overview This chapter contains instructions regarding the tyres of the vehicle. At the end of the chapter there is a table you can use to find the correct tyre pressure for your vehicle. 14.1 General ...

  • Page 126: Tyre Selection

    Wheels and tyres Fig. 78 Tightening the wheel nuts or wheel bolts cross-wise ◼ Tighten the wheel nuts or wheel bolts in the order shown in Fig. 78. In order to do this, use a torque wrench and comply with the specified tightening torque (see section 14.5).

  • Page 127: Tyre Specifications

    Wheels and tyres 14.3 Tyre specifications Description Explanation 215/70 R 15C 109 Q Tyre width in mm (example) Height-to-width proportion in percent Tyre design (R = radial) Rim diameter in inches Commercial (transporter) Load index code for single tyres Speed index (Q = 160 km/h) 14.4 Handling of tyres ◼...
  • Page 128 Wheels and tyres  Check the tyre pressure on cold tyres. Do not reduce the higher tyre pressure when the tyres are warm.  Information stickers with the required tyre pressure are attached to the inside of the B column. The payload and the durability of tyres is directly dependent on the tyre pressure.

  • Page 129: Troubleshooting

    Troubleshooting Troubleshoot ing Chapter overview This chapter contains instructions about possible faults in your vehicle. The faults are listed with their possible causes and corresponding remedies. The specified faults can be remedied with relative ease and without a great deal of specialised knowledge. In the event that the remedies detailed in this instruction manual should not be successful, an authorised specialist work- shop must find and eliminate the cause of the fault.
  • Page 130 Troubleshooting Fault Cause Remedy Starter or living area bat- Jumbo flat fuse on the Replace jumbo flat fuse on tery is not charged when starter or living area bat- the starter or living area bat- operated in 230 V mode tery is defective tery No mains voltage...
  • Page 131 Troubleshooting Fault Cause Remedy 12 V power supply does 12 V power supply is Switch 12 V power supply switched off not work in 230 V opera- tion Battery cut-off switch on Set battery cut-off switch to the transformer/rectifier is switched off 230 V automatic circuit Contact customer service breaker has triggered...

  • Page 132: Gas System

    Troubleshooting Fault Cause Remedy Battery charge through Electrical connection to Check plug connectors and solar module not working solar module interrupted cables Fuse is defective Replace fuse on the trans- former/rectifier Solar charge regulator Contact customer service defective Living area battery over- Battery selection switch Move position of battery se- loaded ("hot")

  • Page 133: Cooker

    Troubleshooting 15.4 Cooker Fault Cause Remedy Ignition fuse does not op- Heat-up time is too short Keep control knob erate (flame does not burn pressed for approx. 15 to after the control knobs are 20 seconds after ignition released) Ignition fuse is defective Contact customer service Flame extinguishes when Thermocouple sensor is...

  • Page 134: Refrigerator

    Troubleshooting Fault Cause Remedy Green LED comes on, red The safety switch on the Close the window LED flashes window above the waste gas vent has triggered Risk of undervoltage; bat- Charge the battery tery voltage too low < 10.4 V The heater permanently Air circulation suction sys- Remove blocking of air...
  • Page 135 Troubleshooting Fault Possible cause Remedy The refrigerator is not The fuse in the direct cur- Have the fuse on the relay working rent line is defective replaced. Contact an ap- proved customer service company Vehicle fuse blown Replace vehicle fuse (see instruction manual for the base vehicle) Vehicle battery is dis-...

  • Page 136: Water Supply

    Troubleshooting 15.7 Water supply Fault Cause Remedy Leakage water inside the A leak has occurred Identify leak, re-connect vehicle water pipes No water Water tank is empty Replenish drinking water Drain cock not closed Close drain cock 12 V power supply is Switch 12 V power supply switched off Switch for water pump is...

  • Page 137: Body

    Troubleshooting Fault Cause Remedy Any change in the taste or Tank filled with dirty water Clean water system me- odour of the water chanically and chemically; then disinfect and rinse copiously with drinking water Fuel filled into the water Clean water system me- tank by mistake chanically and chemically;...
  • Page 138 Troubleshooting 3401120 - 10/23 - EHG-0041-03EN...

  • Page 139: Dimensions And Permissible Number Of Persons

    Dimensions and permissible number of persons Dimen sions and permissible n umb er of p er son s Model Seats Sleeping Outer dimensions places L / W / H (in cm) CV 590 FWD 2 / 3 (OPT) 598 / 247 / 291 CV 590 AWD 2 / 3 (OPT) 598 / 247 / 291...
  • Page 140 Dimensions and permissible number of persons 3401120 - 10/23 - EHG-0041-03EN...

  • Page 141: Helpful Notes

    Helpful notes Helpful notes Chapter overview This chapter contains helpful tips for the journey. At the end of the chapter there is a checklist containing the most important equipment for the journey. 17.1 Traffic rules in foreign countries  The vehicle driver is required to inform himself as to the traffic rules of the countries in which he plans to travel before beginning the trip.

  • Page 142: Gas Supply In European Countries

    Helpful notes 17.3 Gas supply in European countries  In Europe, there are several different connection systems for gas bottles. It is not always possible to fill or exchange your gas bottles in a foreign country. Get information about the connection system in the country you are travelling to before embarking on your journey, e.g.

  • Page 143: Tips On Staying Overnight Safely During Travel

    Helpful notes 17.5 Tips on staying overnight safely during travel Prudent behaviour is the most important protective measure for insuring a safe night in the vehicle. The risk of thievery is reduced to a minimum when the following basic rules are observed: ⚫...

  • Page 144: Travel Checklists

    Helpful notes 17.7 Travel checklists The following checklists will help that nothing important is left at home alt- hough not everything on the checklists might be necessary.  Do not leave checking of documents (e.g. vehicle papers and infor- mation) as well as checking the condition of the vehicle until just before commencing the trip.
  • Page 145 Helpful notes Object Object Object Vehicle/tools Waste water con- Gas tube Snow chains (win- tainer ter) Adapter socket Fabric tape Screwdriver CEE adapter Watering can for Current-measuring drinking water instrument Wire Cable reel Wheel chocks Spare wheel Glue First-aid kit Spare lamps Universal pliers Vehicle jack...
  • Page 146 Helpful notes 3401120 - 10/23 - EHG-0041-03EN...

  • Page 147: Legal Notes On Weight-Related Information

    2022: EU Implementing Regulation No. 1230/2012). We have summarised and explained the key terms and legal requirements from this regulation for you below. Our dealers and the LMC configurator on our website offer you additional assistance in configuring your vehicle.
  • Page 148 Legal notes on weight-related information 3. Mass of the passengers The mass of the passengers is set a standard value of 75 kg for each seat provided by the manufacturer, regardless of the actual weight of the passengers. The mass of the driver is already included in the mass in running order (see no.
  • Page 149 - 325 kg optional equipment (maximum permissible value) = 43 kg actual load capacity (< minimum pay-mass of 100 kg) In order to avoid such a situation, LMC further reduces the maximum permissible weight of the total optional equipment that can be ordered on a model-specific basis.
  • Page 150 Legal notes on weight-related information 6. Effects of tolerances of the mass in running order on the pay-mass Regardless of the minimum pay-mass, you should note that unavoidable production-related fluctuations in the mass in running order – both up- wards and downwards – have a mirror-image effect on the remaining load capacity: If you order our example vehicle (see no.
  • Page 151 Index Index 12 V fuses ............ 81, 82 Caravan coupling ..........28 For awning light ..........82 With detachable ball neck ......28 For generator D+ .......... 82 Care ..............107 For plus signal ..........82 Blind............. 111 For Thetford toilet.......... 82 Carpet ............
  • Page 152 Index Conversion door ..........43 Fire prevention ........... 11 Insect screen..........43 Fire risks, avoidance .......... 11 Curtains, cleaning ..........110 FI-switch see fault current protection switch ..83 Flat screen Driving position ..........56 Storing ............30 Danger of suffocation ........12, 44 Television position .........
  • Page 153 Index Switching automatics ........61 Inspections ............120 Troubleshooting .......... 130 Inspections, official ........... 119 General instructions ..........8 Interior care ............110 Interior lighting ............ 54 Illuminant, changing ........120 Interior lighting, troubleshooting ....... 127 Handbrake............41 ISOFIX child safety seat mounting system ..38 Applying ............
  • Page 154 Index Oven see gas cooker or gas oven ..... 91 Overloading ............22 Safety cut-out ............. 83 Safety instructions ..........11 Electrical system ........... 16 Fire prevention ..........11 Panel (LT 100) ........... 76 Road safety ........... 12 12 V main switch ........... 76 Towing ............
  • Page 155 Index Symbols TV unit ..............56 For notes ............7 Tyre specifications ..........125 Gas isolator taps ........66, 85 Tyres Synthetic parts in the toilet and Certification ..........125 living areas, cleaning ........110 Excessive wear .......13, 31, 123, 125 General instructions ........
  • Page 156 Index Water tank see also water system ..... 96 Wheel rim type ..........123 Windows............. 44 Insect screen..........47 Roman shade..........47 Windows, cleaning ........... 108 Winter care ............114 Winter operation ..........114 3401120 - 10/23 - EHG-0041-03EN...
  • Page 158 LMC CARAVAN GMBH & CO. KG Rudolf-Diesel-Straße 4 D-48336 Sassenberg T +49 (0) 2583 / 27-0 E info@lmc-caravan.de H www.lmc-caravan.de Münster (Westf.): HRB 9914 USt-IdNr. 126 733 941 Geschäftsführer: Bodo Diller, Timo Ecke, René Ricken...

Table of Contents
