- Page 1 C4 PLAYER...
-
Page 2: Table Of Contents
www.colorlightinside.com CONTENT Chapter 1 C4 Interface and Hardware Connection ................................1 1.1 C4 Interface ............................................2 1.2 Hardware Connection ........................................3 Chapter 2 LEDVISION Installation......................................4 Chapter 3 C4 Parameter Settings ......................................6 3.1 Connection Settings ......................................... 6 3.2 Basic Settings ............................................ 8 3.3 Advanced Settings .......................................... -
Page 3: Chapter 1 C4 Interface And Hardware Connection
www.colorlightinside.com Chapter 1 C4 Interface and Hardware Connection... -
Page 4: C4 Interface
www.colorlightinside.com 1.1 C4 Interface Name Functions Environmental temperature and brightness monitoring; Sensor Interface Automatic brightness adjustment Ethernet Output RJ45, signal output, connecting with receiving cards Audio Output HIFI stereo output CONFIG Port Screen parameters setting; Program publishing USB Port Program updating through U disc LAN Port Access network Power Port... -
Page 5: Hardware Connection
www.colorlightinside.com 1.2 Hardware Connection... -
Page 6: Chapter 2 Ledvision Installation
Chapter 2 LEDVISION Installation First download the installation package of LEDVISION software from Colorlight’s official website www.colorlightinside.com, and complete the installation according to the diagrams below. 1. Run the software package, then select [ English ] for installer language. Click [ OK ] to move on. - Page 7 www.colorlightinside.com 2. After selecting a language, an installation wizard like below will appear. Click [ Next ]. Choose the installation location, click [ Browse ] to change the default target location, then click [ Next ] after completing; Choose components according to your own computer status, then click [ Install ] to complete; After the installation is complete you are ready to use LEDVISION.
-
Page 8: Chapter 3 C4 Parameter Settings
www.colorlightinside.com Chapter 3 C4 Parameter Settings 3.1 Connection Settings 1. Before connecting your C4 to the computer, first click the control menu [ Control ] – [ Screen Control ], then select [ C-Series Play Box ] in Select Sending Device, then set up [ LED Screen Window Management ]. - Page 9 www.colorlightinside.com Note: If you do not complete this step, LEDVISION may not function properly because of a conflict between Net Card mode and C4 CONFIG interface. 2. Use a standard USB A/B cable to connect the C4 to your computer once the C4 is powered on, and note that one side is to connect to the USB port and the other side is for the C4 CONFIG port.
-
Page 10: Basic Settings
www.colorlightinside.com 3.2 Basic Settings ● Ensure the LED display is under normal configuration before setting up C4 parameters. ● When setting C4 parameters, you can connect the C4 to your PC through a standard USB A/B cable and connect the C4 to the LED screen with a network cable. Time Settings: Click [ Modify ] to set up date and time, or to select a time zone. - Page 11 1. After connecting the C4 to the computer, a C4 player icon will show up in Direct USB. You can check the specific information and some basic settings for it by selecting the player.
- Page 12 2. In Program Management, you can conduct a comprehensive management on programs included in the C4 player. All programs can be deleted in Program Management regardless of the type and source. 3. Schedule Settings: In Schedule Settings, click [ Add ] to add a scheduled command. Scheduled commands can conduct...
- Page 13 www.colorlightinside.com...
- Page 14 www.colorlightinside.com Commands can be edited and deleted after adding scheduled commands is completed.
-
Page 15: Advanced Settings
www.colorlightinside.com 3.3 Advanced Settings 3.3.1 Playing Parameters ①LED Resolution The [ Width ] / [ Height ] you input must be equal to or slightly larger than the actual screen resolution. ②Input Type: HDMI or Internal Media ③Output [ Every Frame ] (Default) [ Every Other Frame ] (Choosing [ Every Other Frame ] can help avoid lag when the image loading area is too large) ④Control Area... -
Page 16: Network
www.colorlightinside.com 3.3.2 Network ①WiFi Check [ WiFi ] in the network tab and input your WiFi login information for [ SSID ] and [ Password ], then click [ Apply ] and [ Refresh ] to complete the setting. Click [ Details ] to check the connection status. - Page 17 www.colorlightinside.com ②WiFi Hotspot Input your [ SSID ] and [ Password ] to use a WiFi Hotspot; [ Band ]: 2.4G or 5G (5G mode will be faster and more reliable if both the smart phone and computer support 5G WiFi) [ Channel ]: 14 or 24 choices, to avoid network overload.
- Page 18 www.colorlightinside.com ③LAN (Network Cable) 1. [ Automatically Obtain IP Address ] (Default) When you connect your C4’s LAN port to a networked router, the C4 will automatically obtain an IP address. 2. [ Use Following IP Address ] To use a specific IP address, enter information for [ IP ], [ Subnet Mask ], [ Gateway ], then connect the C4 LAN port to the router.
- Page 19 www.colorlightinside.com ④4G Check [ 4G ] in the network tab, click [ Apply ] and [ Refresh ] to access the 4G network, then click [ Test Network State ] to check the connection status.
-
Page 20: Chapter 4 Async Program Editing And Publishing
www.colorlightinside.com Chapter 4 Async Program Editing and Publishing 4.1 Async Program Editing When you open LEDVISION, you will see [ LED1 ] in the program editing area. Right-click [ LED1 ] to add [ Normal Page ]. You can add [ File Window ] in [ Normal Page ], then add [ Image ] and [ Video ] under the [ File Window ] to add media for asynchronous play. -
Page 21: Async Program Publishing
www.colorlightinside.com 4.2 Async Program Publishing 4.2.1 Publish Program through Direct USB... - Page 22 www.colorlightinside.com ①In [ Program Editing Area ], after finishing program editing, select the [ Program Page ] that you are going to publish; ②Click [ C4 ] and then right-click to choose [ Publish current program to the selected player ]. You must rename the program and allow it to finish uploading to fully publish your program.
-
Page 23: Publish Program Through Ethernet Port
www.colorlightinside.com 4.2.2 Publish Program through Ethernet Port... - Page 24 www.colorlightinside.com ①In [ Program Editing Area ], after finishing program editing, select the [ Program Page ] that you are going to publish; ②Click [ C4 ] and then right-click to choose [ Publish current program to the selected player ]. You must rename the program and allow it to finish uploading to fully publish your program.
-
Page 25: Publish Program Through Usb Disk
www.colorlightinside.com 4.2.3 Publish Program through USB Disk 1. To begin publishing through USB, first insert your USB disk to the PC USB port; Click [ Publish Program to C-Series Playboxes ] to extend program publishing window. Note: USB disk should be empty before publishing for best performance. Remove previously updated programs before using it to update or play new programs and to avoid any problems. - Page 26 www.colorlightinside.com 2. Software will automatically identify the USB disk when plugged in. Click [ U Disk ] to choose [ Your USB’s Drive ]. ①Select the [ Program Page ] in Program Editing Area. ②Choose USB Disk Mode:...
- Page 27 www.colorlightinside.com ●Play the program from the USB disk (automatically play the USB disk content after inserting it into the C4; the content won’t be stored on the C4) ●Update the program from the USB disk (automatically play the USB disk content after inserting it into the C4;...
-
Page 28: Chapter 5 Network Management Of C4
www.colorlightinside.com Chapter 5 Network Management of C4 5.1 Connection and Management 1. LAN Connection: Connect the C4 to the network through WiFi or a LAN port. 2. C4 Network Management: After the controller end (PC, smart phone, or other device) and C4 are connected to the same LAN network, select [ LAN ], then [ Refresh ], LEDVISION will automatically identify the C4 in the LAN... -
Page 29: Add Group And C4
www.colorlightinside.com 5.2 Add Group and C4 1. Add Group: Select [ LAN ] and right- click to choose [ Add Group ]. 2. Add C4: Select any player group and right-click to choose [ Manually Add Player ], then input the C4’s corresponding IP (add it even if your device did not connect to network).
