- Page 1 Edit Text Industry APEX 200 QUICK START GUIDE ICI cameras fall under US Federal Law and Export Control. 2105 W. Cardinal Dr. Beaumont, TX 77705 Phone: (409) 861-0788 Toll Free: (866) 861-0788 infraredcameras.com support@infraredcameras.com We Are IR ™...
- Page 2 ©Copyright 2021, Infrared Cameras, Inc. - All rights reserved. The contents of this document may not be reproduced in whole or in parts without the written consent of the copyright owner. Printed in the United States of America. 2105 W. Cardinal Dr.
-
Page 3: Package Includes
Package Includes APEX 200 Ethernet Data Cable Alignment Guides PoE Injector M2 Screws x8 ST2.2 Screws x8 ENSURE ALL SYSTEM EQUIPMENT AND COMPONENT ITEMS ARE PRESENT BEFORE BEGINNING INSTALLATION... - Page 4 Option 1: Rear Housing Installation USE THE ALIGNMENT GUIDES TO DRILL HOLES FOR SETTING DEVICE SCREWS. DO NOT USE TOO LONG SCREWS WHEN INSTALLING THE FRONT/ REAR MOUNTING BRACKET. USING SCREWS THAT ARE TOO LONG MAY DAMAGE THE THERMAL CAMERA. Place the rear facing Mount the device with four alignment guide on the...
- Page 5 Align the 8-pin connector of Rotate the securing nut to the the Ethernet data cable to the right to lock cable in place. 8-pin receptor on the device; Rotate the securing nut to the then, plug in the cable. left to unlock the cable. ALIGN THE PINS BEFORE TRYING TO CONNECT THE ETHERNET DATA CABLE.
- Page 6 Option 2: Front Housing Installation USE THE ALIGNMENT GUIDES TO DRILL HOLES FOR SETTING DEVICE SCREWS. DO NOT USE TOO LONG SCREWS WHEN INSTALLING THE FRONT/ REAR MOUNTING BRACKET. USING SCREWS THAT ARE TOO LONG MAY DAMAGE THE THERMAL CAMERA. Place the front facing Mount the device with four alignment guide on the...
- Page 7 Align the 8-pin connector of Rotate the securing nut to the the Ethernet data cable to the right to lock cable in place. 8-pin receptor on the device; Rotate the securing nut to the then, plug in the cable. left to unlock the cable. ALIGN THE PINS BEFORE TRYING TO CONNECT THE ETHERNET DATA CABLE.
- Page 8 You can see our products and services used in industrial, commercial, and government applications worldwide. Originally named Texas Infrared (still DBA), Infrared Cameras, Inc. has been in business since March, 1995. Thank you for your dedicated and continued support.
