- Page 1 TRIPLE INFRATECH PAINT CURING LAMP - POWER 3150W PN: R1107 RHINOMOTIVE LTD - UK 71-75 Shelton Street, London, United Kingdom Scan QR Code www.rhinomotive.com...
-
Page 2: Warranty
LED light for flash time setting k) LED light for cure time setting l) LED light for lamp 1 m) LED light for lamp 2 n) LED light for lamp 3 o) Start key p) Power switch/Circuit breaker www.rhinomotive.com... -
Page 3: Electrical Diagram
Install castors with brake 17 to stand’s rear screw 16 and castors without brake to stand’s front screw. b) Install column 10 with stand 13 by screws 14 and washers 15 c) Install gas shock strut 11 with arm 9. d) Put cassette assembly 5 up to hanger 6, and screw down handle 4 www.rhinomotive.com... - Page 4 • Toggle on “on-off key for lamp 1”, “on-off key for lamp 2” and/or “on-off key for lamp 3” Press “start key”. • If you want to pause, press “pause/stop key”, then press “start key” if you want to continue. Pressing “pause/stop key” two times will stop working. • It will give a “dee-dee” alarm when drying is finished. www.rhinomotive.com...
-
Page 5: 11. Safety Instructions
Refit grille heat dissipation cover and side cover of cassette in turn. h) Use a soft cloth with solvent such as Methylated Spirits to clean reflector, side cover and tubes. Disconnect tube wire connecter www.rhinomotive.com... -
Page 6: 14. Troubleshooting
2. Move unit for -2nd application Softness on edges of repair Repair too large for I.R. unit 3. If warm-up is used, it will not be necessary on -2nd application Note: only K1, K2, K3 & K3C has warm-up function. www.rhinomotive.com... - Page 7 15. PARTS BRAKEDOWN www.rhinomotive.com...
- Page 8 Column Rear Caster Linking Board Bolt Mio Washer M12 U Rack Washer Mio Nut M12 Handle M12 Cap Mio Front Caster Washer M12 Gas Strut RHINOMOTIVE LTD - UK 71-75 Shelton Street, London, United Kingdom Scan QR Code www.rhinomotive.com www.rhinomotive.com...
