REMACO TECHNOLOGIES CMS-1515 Installation Manual & Manual

C COPYRIGHTS 1998 REMACO TECHNOLOGIES PTE LTD
Installation Guide / Manual
Warning Warning
Universal Bracket can be used for any type of installation as shown below.
False Ceiling
Wall Mount
False Ceiling
Corner Mount
M6 Anchors
M5 Stopper
M6
Screws
Countersunk
Screws
* For details dimension , please refer to technical specifications at
Caution with main supply and live wires. Install with qualified technician or trained
personnel.
Ceiling Mount
Ceiling Recessed
For Suspension from Ceiling
Insert these accessories in
between the indicated arrow.
M6 Long Nuts
www.remacotech.com
(CMS-1515 to CMS-2727)
False Ceiling
Ceiling Suspension
False Ceiling
Website: www.remacotech.com
False Ceiling
Use these holes
Universal
Bracket
Brown (to Live)
Blue (to Neutral)
Green (to Earth)
4-Cores
Control
.
Cable
Remote
Details
connection
inside
Blue
Internally Shorted
N
Brown
Black
DN
Motor
Brown
UP
Green
E
V: 5.1
CMS
False Ceiling
3-Cores
Power
Supply
AC Cable
Electronics
Screen
Control
DOWN UP
DOWN UP
STOP
(ESC+)
UP
_
STOP
DOWN
IR RF
Remote
Blue
}
Green To 3-Cores
Power Supply
Brown
Red
}
Black
To ESC+
Brown
Blue
