REMACO TECHNOLOGIES PRO-L3030 Manual

C COPYRIGHTS 1998 REMACO TECHNOLOGIES PTE LTD
Installation Guide / Manual
Warning Warning
Universal Bracket can be used for any type of installation as shown below.
Wall Mount
Corner Mount
M8 Anchors
M6 Stopper
M8
Screws
Countersunk
Screws
* For details dimension , please refer to technical specifications at
* For PRO-L3030 to PRO-L3636
* For PRO-L3939 to PRO-L4343
Caution with main supply and live wires. Install with qualified technician or trained
personnel.
Ceiling Mount
Ceiling
Recessed
For Suspension from Ceiling
Insert these accessories in
between the indicated arrow.
M8 Long Nuts
www.remacotech.com
2 pieces of universal bracket are provided.
3 pieces of universal bracket are provided.
(PRO-L3030 to PRO-L4343)
Ceiling
Suspension
Pelmet Mount
Universal
Bracket
Blue
Black
Motor
Brown
Green
Website: www.remacotech.com
V: 10.2
PRO-L
Use these holes
Side Pelmet Mount
3-Cores
Power
Supply
AC Cable
Brown (to Live)
Blue (to Neutral)
Green (to Earth)
4-Cores
Control
.
Electronics
Cable
Screen
Control
DOWN UP
DOWN UP
STOP
(ESC+)
UP
STOP
DOWN
IR RF
Remote Remote
Details
connection
inside
Blue
}
Green To 3-Cores
Power Supply
Brown
Internally Shorted
N
Brown Red
}
Black
DN
To ESC+
Brown
Blue
UP
E
_
