  • Page 1 12 CFM Brushless DC Vacuum Pump Operation and Maintenance Instructions Model hilmor.com + 1-800-628-8810 ©2017 hilmor 1950532 1.800.561.8187 information@itm.com www. .com...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Introduction........................4 Safety and Warnings ......................4 Pump Components ......................9 LED Quick Start Guide ....................9 Operating Instructions ....................10 Technical Specifications ....................11 Maintenance ........................11 Troubleshooting ......................12 Technical Drawing ......................13 Limited Warranty ......................13 1.800.561.8187 information@itm.com www. .com...
  • Page 3: Introduction

    • hilmor® Brushless DC Vacuum Pumps are factory-tested to guarantee 25 microns of ultimate vacuum. Please inspect the hilmor® Brushless DC Vacuum Pump immediately IMPORTANT: This hilmor® Brushless DC vacuum pump has been drained of oil for shipment. Do not operate without adding hilmor® SAFETY AND WARNINGS Read this manual in its entirety before operating your hilmor®...
  • Page 4 Troubleshooting guide. If the problem persists, call hilmor® technical services. Failure to provide adequate grounding to Make certain that the electrical circuit to this product could result in serious injury or which the machine is connected provides death from electrocution.
  • Page 5 ENGLISH WARNING: RISK OF HOT SURFACES WHAT CAN HAPPEN HOW TO PREVENT IT Touching exposed metal such as the oil Never touch any exposed metal parts housing, motor plate, motor case or other on machine during or immediately after operation. The machine will remain hot for Do not reach around protective shrouds or attempt maintenance until unit has been DANGER: RISK FROM MOVING PARTS...
  • Page 6 LIFTING CAUTION: Unit is heavy use caution when lifting. Always lift by the handle or by the recommended hoist points using the hilmor® carrying strap. The lifting of the machine has not been tested with other accessories. Using untested accessories can cause damage to the equipment or personal injury.
  • Page 7 WARNING: tested with this product, use of such accessories with this tool could be hazardous. To reduce the risk of injury, use only hilmor® recommended accessories such as: carrying strap, hoses, wireless vacuum gauge, and valve core removal tool should WARNING: This machine should only be used for evacuation of refrigerant systems after refrigerant has been removed from the system.
  • Page 8: Pump Components

    PLUG QUICK START GUIDE Add hilmor® Vacuum Pump Oil until it has reached between the Min and Max levels on Turn the machine ON (there is a 2 second delay on start-up). Open unused inlet fitting and break vacuum; turn hilmor® Brushless DC Vacuum Pump 1.800.561.8187...
  • Page 9: Operating Instructions

    The light in the power switch 2. Fill the oil housing with hilmor® Vacuum Pump Oil by removing the oil fill cap and adding oil until it has reached the level between Min and Max on the sight glass. Make sure to fill with oil before switching the pump on.
  • Page 10: Technical Specifications

    • The condition and type of oil used in the machine are extremely important to achieve deep vacuum. For premium performance, use hilmor® Vacuum Pump Oil, which is a low- vapor pressure oil that improves vacuum performance and cold weather start-up.
  • Page 11: Troubleshooting

    3. Re-attach the oil drain plug. Remove the oil fill cap, and fill the oil housing with new hilmor® Vacuum Pump Oil until oil level has reached between the Min and Max IF OIL IS BADLY CONTAMINATED, FOLLOW THESE STEPS TO FLUSH 2.
  • Page 12: Technical Drawing

    Gas Ballast Valve Oil Housing Screws LIMITED WARRANTY • hilmor® Brushless DC Vacuum Pumps have a 2-year limited warranty from the • • Warranty service claims are subject to authorized inspection for product defects. If found defective, hilmor® will repair or replace registered products within •...
  • Page 13 ©2018 hilmor 1.800.561.8187 information@itm.com www. .com...
