- Page 1 TAPWARE INSTALLATION GUIDE Version 1. 2022.
-
Page 2: Table Of Contents
This Installation Guide contains information for safe use, installation and maintenance. JUMPER VALVE WALL TOP ASSEMBLY Meir does not accept responsibility for any damages due to not observing these instructions. QUARTER TURN WALL TOP ASSEMBLY If you have any questions regarding... -
Page 3: Precautions For Installation
Meir during any warranty meir.com.au/meir-australia-warranty/ claim request. • Follow the ‘Care and Cleaning’ guide on: meir.com.au/pages/warranty • Failure to comply with all the above instructions will void all warranties. Refer to www.meir.com.au for tolerances, flow rates and other additional information | 5... -
Page 4: Basin Mixer
BASIN MIXER INSTALLATION INSTRUCTIONS 1. Install the O-Ring (part 1), flexible 2. Position the mixer over the hoses (part 6) and the threaded center of the hole to be used tube (part 4) onto the mixer, for mounting. Ensure the ensuring the O-ring is flat, the flexible hoses and threaded hoses are tight, and the threaded... -
Page 5: Kitchen Mixer
Test for leaks and fixing plate and fixing nut over correct operation of the mixer. 6. Flexible hoses the flexible hoses and tighten firmly and tighten screws where applicable. Refer to www.meir.com.au for tolerances, flow rates and other additional information | 9... -
Page 6: Pull-Out Kitchen Mixer
PULL-OUT KITCHEN MIXER INSTALLATION INSTRUCTIONS 1. Position the mixer over the 2. Place the rubber seal (part 2) center of the hole to be used over the flexible hoses and push for mounting. Ensuring the up until it is firm against the flexible hoses and threaded surface being mounted on, then tube are pushed through first. -
Page 7: Diverter Mixer
(anti-clockwise) until the handle points exactly to the vertical. Skew diverter Outlet to handle shower Cold water inlet Hot water inlet Protective Plastic cover for during installation. Outlet to Bath or Hand-Held Refer to www.meir.com.au for tolerances, flow rates and other additional information | 13... -
Page 8: Wall Mixer
WALL MIXER INSTALLATION INSTRUCTIONS 1. Fix the body of the mixer to a 2. Install the hot (on the left) suitable fixing plate or noggin. and cold (on the right) water Ensure the mixer is level and connections. Once all the fittings will have enough of the body have been tightened, check for exposed to install the plate... -
Page 9: Jumper Valve Wall Top Assembly
Test for leaks around the spindle bodies and to ensure the wall tops Hot cartridge are functioning correctly. 2. Backplate 3. Fixing nut 4. Nut 5. C-clip 6. Handle 7. Cold cartridge 8. Installation tool Refer to www.meir.com.au for tolerances, flow rates and other additional information | 17... -
Page 10: Quarter Turn Wall Top Assembly
QUARTER TURN WALL TOP ASSEMBLY INSTALLATION INSTRUCTIONS 1. Ensure the seat surface is clean 2. Install the fibre washer then and smooth, if required, re-seat locking nut back onto the and flush. Disassemble the spindle and tighten. handle, back plate, locking nut and fibre washer from the spindle (see image below). -
Page 11: Wall Spout And Mixer
Body 2. Back plate 3. Spout 4. Handle 5. O-ring 6. Screw 7. Decor knob Refer to www.meir.com.au for tolerances, flow rates and other additional information | 21... -
Page 12: Wall Set
WALL SET INSTALLATION INSTRUCTIONS (CONCEALED SHOWER/BASIN/BATH 1. (A Typical Installation) Fix the 2. Install the hot (bottom left) BREECH ASSEMBLY SHOWN IS SOLD SEPARATELY) concealed assembly to a suitable and cold (bottom right) water fixing plate or noggin. Ensure the connections. -
Page 13: Basin Set / Hob Set
Tighten all off position and the handles fittings and test for leaks. are aligned correctly before tightening the grub screw). Refer to www.meir.com.au for tolerances, flow rates and other additional information | 25... -
Page 14: Spout
SPOUT INSTALLATION INSTRUCTIONS 1. Apply thread tape to the exposed G1/2” BSP thread, ensure the back plate (part 2) is installed on the body of the spout before screwing the spout clockwise (by hand) onto the G1/2” BSP thread (the spout should finish up tight against the finished surface). -
Page 15: Washing Machine Stops
G1/2” BSP pipes. G1/2” BSP thread and ensure the outlet is facing down (it is recommended to apply threaded tape before installation) Do not over-tighten. Body 2. Cover plates Refer to www.meir.com.au for tolerances, flow rates and other additional information | 29... -
Page 16: Round Wall Taps
ROUND WALL TAPS INSTALLATION INSTRUCTIONS 1. Before installation please take note of the installation tolerances, as well as the turning directions of the H and C cartridges. Cartridge (Hot) 2. Fiber Washer MAX HOLE DIAMETER = 40MM 3. Lock Nut TOLERANCE OPENING DIRECTION 4. - Page 17 ‘H’ and ‘C’ in the bottom position when the cartridge is closed. Aerator 2. Spout 3. Screw 4. O-ring 5. Back plate 6. O-ring 7. Base plate Refer to www.meir.com.au for tolerances, flow rates and other additional information | 33...
-
Page 18: Cleaning
INSTALLATION INSTRUCTIONS CLEANING • Do not install the tapware using any form of acetone silicones. 1. Screw the base to the water 2. Slide the cover plate onto the outlet tightly and then fasten spout from the bottom before •... - Page 19 CONTACT P: 1800 012 122 P: +61 3 8678 1722 (international) E: sales@meir.com.au...
