MTV22 & MTV02
ROUND THERMOSTATIC MIXER 2-way
FEATURES
• Refer to the Meir website for
warranty terms & conditions.
• Flow rate 30L p/m at 3 bar.
Flow rate 17L p/m at 1 bar.
Recommended for water pressure
above 0.5 bar.
• Box weight 0.95kg
• Vernet thermostatic cartridge
• Anti-scalding protection
• Temperature over-ride button
•
-Way Fluhs diverter
1
• High low-pressure flow rate
• Solid Brass Construction
• Used together with the MTV02 body
part.(2.3kg)
CARE
• Do not install tapware using any
form of acetone silicones.
• Do not apply physical items (such as
tools) directly to product.
• Never use house-hold or commercial
detergents, citrus based cleaners, or
abrasive cleaners.
• Clean using a mild washing soap
solution rinsed, and dry with
a soft cloth.
• Check for any product defects
before installation.
• Refer to the installation manual for
correct installation.
SPECIFICATIONS
Australian installers to visit the below website before working on the thermostatic mixer valve:
https://www.vba.vic.gov.au/plumbing/registrations-licences/thermostatic-mixing-valve
MTV22 V4
