- Page 1 SOLEA FLOOD LIGHT Operating Instructions...
-
Page 2: Table Of Contents
CONTENTS Preface ................................3 Features ................................3 Precautions ................................3 Components ...............................4 Assembling and Installation ..........................5 Connection .................................6 Controls ................................7 Technical Specifications ...........................10 Declaration of Conformity ..........................14 Warranty ................................15 _________________________________________________________________________________... -
Page 3: Preface
PREFACE PRECAUTIONS The SOLEA series of modular outdoor light • The flood light has to be installed and used with built-in driver is designed to use the latest in accordance with the instructions of this LED lighting technology. manual only. -
Page 4: Components
COMPONENTS (1) Engine assembly LED lighting assembly built-in sand-blasted anodized aluminium casing with different lighting color, power and beam options. Code 1 Color of lighting ENGWW Warm White ENGDW Daylight White ENGCW Cool White ENGR ENGG Green ENGB Blue ENGRGB Red + Green + Blue ENGRGBW Red + Green + Blue + Warm White... -
Page 5: Assembling And Installation
The modular FLOOD LED light SOLEA series consists of the following assemblies: • Engine assembly • Bezel assembly • Flood-light bracket assembly The assembling and installation have to be realized by qualified personnel. The SOLEA has to be assembled and fixed as shown in the drawing below:... -
Page 6: Connection
a) Fix the basic component of the high-end Flood-light bracket assembly or the economy Flood- light bracket assembly to the wall by using of 3(2) fixing screws 5.5x45 with wallplugs. b) Connect the power supply and control wires c) Fix the moving head of the high-end Flood-light bracket assembly with 4 enclosed screws M4 d) Fix the Engine assembly to the Flood-light bracket assembly with 2 enclosed screws M6 with washers e) Tighten the Bezel assembly to the Engine assembly... -
Page 7: Controls
Synchronization When more than one light is connected to the system the optional Synchronization Unit LSU08 is recommended to synchronize the colors of lighting at the Rainbow Color Spectrum mode of lighting. On the other case the colors of all installed lights would not be the same after few minutes or hours of operation in the Rainbow Color Spectrum mode. - Page 8 Turning on /off Press the momentary switch shortly. Changing the color or mode of lighting When the light is turned-off press the momentary switch for 2 seconds. Setting the Custom Color At the selected Rainbow Color Spectrum mode press the momentary switch shortly to turn the light off.
- Page 9 Setting the Custom Color At the selected Rainbow Color Spectrum mode press the momentary switch shortly to turn the light off. After that press the momentary switch for 5 seconds or until the light is switched to the selected color and then the Custom Color is set and selected. Dimming When the light is turned-on press the momentary switch until the desired illumination is achieved.
-
Page 10: Technical Specifications
TECHNICAL SPECIFICATIONS Engine assembly Power supply 12 – 24 Vdc, max. 260 mA/12 Vdc or 135 mA/24 Vdc (1 LED) 12 – 24 Vdc, max. 500 mA/12 Vdc or 260 mA/24 Vdc (2 LEDs) 12 – 24 Vdc, max. 800 mA/12 Vdc or 420 mA/24 Vdc (3 LEDs) 12 –... - Page 11 The model specification: SOLEA - BEZEL code ENGINE code BRACKET code Design and specifications subject to change without notice.
-
Page 14: Declaration Of Conformity
Dutovlje 138 6221 Dutovlje Slovenija declares that the products Item, Product Name and Model Number: 1. FLOOD LED light SOLEA series conform to the following Product Specifications: EMC: EN 55015:2006 + A1:2007 EN 61547:1995 + A1:2000 + A2:2009 EN 61547:2009... -
Page 15: Warranty
WARRANTY 1. The equipment manufactured by ASTEL d.o.o. is warranted to be free from defects in workmanship and materials under normal use and service. 2. This Warranty is in effect for of two years from the date of purchase by the user. Proof of purchase must be included, to establish that it is inside the warranty period. - Page 16 ASTEL d.o.o., Dutovlje 138, 6221 Dutovlje, Slovenia Tel: +386 5 7310771, +386 5 7310772 Fax:+386 5 7310789 info@astel-lighting.com E-mail: www.astel-lighting.com Web:...
