- Page 1 Gas Wok Ranges Models CE-CN-W1L0-NG, W1L1-NG, W2L1-NG, W3L1-NG Items 48411, 48412, 48413, 48409 Instruction Manual Revised - 08/26/2024 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model CE-CN-W1L0-NG / Model CE-CN-W1L1-NG Model CE-CN-W2L1-NG / Model CE-CN-W3L1-NG Section Page General Information --------------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------------- 4 - 6 Technical Specifications ------------------------------------------------------------------------------- 6 Installation ----------------------------------------------------------------------------------------------- 7 - 9 Operation ---------------------------------------------------------------------------------------------------- 10... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 Safety and Warranty IMPORTANT Safe and satisfactory operation of your equipment depends to a great extent on its proper installation. Installation must conform to local codes, or in the absence of local codes, with the National Fuel Gas Code ANSI Z223.1/NFPA 54, the National Gas Installation Code, CSA/B149.1or the Propane Installation code, CSA/ B149.1, as applicable.
-
Page 6: Technical Specifications
1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally. -
Page 7: Installation
Installation CLEARANCES The appliance area must be kept free and clear of all combustibles. Ensure a clearance of 6” from the sides and rear when placing near combustibles. CAUTION: DO NOT PUSH against the end of the valve cover/landing ledge in an attempt to adjust the ranges position. - Page 8 Installation The regulators supplied for wok ranges are adjusted at the factory for 5” WC (natural gas) or 10” WC (propane) depending on the customer’s ordering instructions. Prior to connecting the regulator, check the incoming line pressure, as these regulators can only withstand a maximum pressure of ½ PSI (14” WC). If the line pressure is beyond this limit, a step-down regulator will be required.
- Page 9 Installation ASSEMBLY GUIDE Unpacked package, assembly the frame and stove body, back splash and pipes, follow below pictures.
-
Page 10: Operation
Operation INITIAL PILOT LIGHTING CAUTION: when lighting pilots and checking for leaks, do not stand with your face close to the combustion chamber. All appliances are adjusted and tested before leaving the factory, effectively matching them to sea level conditions. Adjustments and calibrations to assure proper operation may be necessary on installation to meet local conditions, low gas characteristics, to correct possible problems caused by rough handling or vibration during shipment, and are to be performed only by qualified service personnel. -
Page 11: Maintenance
Maintenance CLEANING AND MAINTENANCE Any piece of equipment works better and lasts longer when maintained properly. Cooking equipment is no exception. Your Imperial range must be kept clean during the working day and thoroughly cleaned at the end of the day. CAUTION: NEVER USE AMMONIA IN AN OVEN THAT IS WARMER THAN ROOM TEMPERATURE AND ALWAYS HAVE DIRECT VENTILATION. -
Page 12: Parts Breakdown
Parts Breakdown Model CE-CN-W1L0-NG 48411... - Page 13 Parts Breakdown Model CE-CN-W1L0-NG 48411 Item No. Description Position Item No. Description Position Item No. Description Position AO220 Regulator for 48411 AI583 Pilot Valve for 48411 AR689 Stove Connecting Tube for 48411 AO221 Pilot Tube for 48411 AO227 Valve Joint for 48411...
- Page 14 Parts Breakdown Model CE-CN-W1L1-NG 48412...
- Page 15 Parts Breakdown Model CE-CN-W1L1-NG 48412 Item No. Description Position Item No. Description Position Item No. Description Position AO220 Regulator for 48412 AI583 Pilot Valve for 48412 AR694 Stove Connecting Tube for 48412 AO221 Pilot Tube for 48412 AO227 Valve Joint for 48412 AO231 Faucet for 48412 AI586...
- Page 16 Parts Breakdown Model CE-CN-W2L1-NG 48413...
- Page 17 Parts Breakdown Model CE-CN-W2L1-NG 48413 Item No. Description Position Item No. Description Position Item No. Description Position AO220 Regulator for 48413 AI582 Gas Valve with Handle for 48413 AM917 Burner Base for 48413 AO221 Pilot Tube for 48413 AO229 Valve Handle for 48413 AO231 Faucet for 48413 AI586...
- Page 18 Parts Breakdown Model CE-CN-W3L1-NG 48409...
- Page 19 Parts Breakdown Model CE-CN-W3L1-NG 48409 Item No. Description Position Item No. Description Position Item No. Description Position AO220 Regulator for 48409 AI582 Gas Valve with Handle for 48409 AM917 Burner Base for 48409 AO221 Pilot Tube for 48409 AO229 Valve Handle for 48409 AO231 Faucet for 48409 AI586...
-
Page 20: Notes
Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________... - Page 21 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
- Page 22 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
-
Page 23: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 24 à plus de 6500 produits provenant du monde entier. Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir a nuestro compromiso de fortalecer y desarrollar nuevas relaciones...
