- Page 1 Wok Range Model CE-CN-W2L0-NG Item 47726 Instruction Manual Revised - 10/25/2023 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model CE-CN-W2L0-NG Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 6 Technical Specifications -------------------------------------------------------------------------- 6 Installation -------------------------------------------------------------------------------------- 6 - 10 Operation ------------------------------------------------------------------------------------- 10 - 11 Maintenance --------------------------------------------------------------------------------- 11 - 12 Parts Breakdown... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 1 YEAR PARTS AND LABOUR BENCH WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the equipment.
-
Page 6: Technical Specifications
Safety and Warranty Please see https://omcan.com/disclaimer for complete info. WARNING: The packaging components are classified as normal solid urban waste and can therefore be disposed of without difficulty. In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms. -
Page 7: Installation
Installation during any pressure testing of the system at test pressures in excess of ½ PSI. 4. The appliance must be isolated from the gas supply piping system by closing its individual manual shut off valve during any pressure testing of the gas supply piping system at test pressures equal to or less than ½ PSI. - Page 8 Installation is to place the unit under an exhaust hood. Filters and drip troughs should be part of any industrial hood, but consult local codes before construction and installing a hood. Strong exhaust fans in this hood or in the overall air conditioning system can produce a slight vacuum in the room and/or cause air drafts, either of which can interfere with pilot or burner performance and can also be hard to diagnose.
- Page 9 Installation The water supply is designed to provide a constant flow of water over the range top to allow for cooling of the range as well as enabling the range top to be kept clean. ASSEMBLY GUIDE Unpacked package, assembly the frame and stove body, back splash and pipes, follow below pictures.
-
Page 10: Operation
Installation Operation INITIAL PILOT LIGHTING CAUTION When lighting pilots and checking for leaks, do not stand with your face close to the combustion chamber. All appliances are adjusted and tested before leaving the factory, effectively matching them to sea level conditions. -
Page 11: Maintenance
Operation TO CHECK FOR LEAKS 1. Check pilot tubing and burner tubing for leaks where they enter the gas valve with a soapy water solution. 2. Light the pilot as described above. 3. Check the burner visually for blue flame. There should be no yellow tips or soot. If yellow tipping occurs, call an authorized service person. - Page 12 Maintenance STAINLESS STEEL All stainless steel body parts should be wiped regularly with hot soapy water during the day and with a liquid cleaner designed for this material at the end of each day. DO NOT USE steel wool. Abrasive cloths, cleansers or powders to clean stainless surface.
-
Page 13: Parts Breakdown
Parts Breakdown Model CE-CN-W2L0-NG 47726... - Page 14 Parts Breakdown Model CE-CN-W2L0-NG 47726 Item No. Description Position Item No. Description Position Item No. Description Position AO220 Regulator for 47726 AO226 Pilot Valve for 47726 AO232 Water Valve for 47726 AO221 Pilot Tube for 47726 AO227 Valve Joint for 47726...
-
Page 15: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 16 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
