Page 1 3800g Retail/Commercial Handheld Linear Imager ™ User’s Guide...
Page 2 Hand Held Products, Inc. (“Hand Held Products”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult Hand Held Products to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of Hand Held Products.
Page 3: Statement Of Agency Compliance
Statement of Agency Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 4: Solids And Water Protection
Nijverheidsweg 9 5627 BT Eindhoven The Netherlands Hand Held Products shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked and does not comply with the Low Voltage Directive.
Page 5 3800g Imager Identification 3800gXXX XXXXXXXXXX XXXXXXXXXX...
Page 7: Table Of Contents
Chapter 2 - Terminal Interfaces Terminal ID ................2-1 Supported Terminals............. 2-2 Keyboard Country ..............2-4 Keyboard Style ..............2-5 Keyboard Modifiers.............. 2-6 RS-232 Baud Rate............2-7 RS-232 Word Length: Data Bits, Stop Bits, and Parity. 2-8 RS-232 Handshaking ............. 2-9...
Page 8 Prefix/Suffix Overview............4-1 To Add a Prefix or Suffix: 2 To Clear One or All Prefixes or Suffixes:...... 4-3 To Add a Carriage Return Suffix to all Symbologies ..4-3 Prefix Selections............. 4-3 Suffix Selections ............4-4 Function Code Transmit..........4-4...
Page 9 Intercharacter, Interfunction, and Intermessage Delays ..4-4 Intercharacter Delay ............4-5 User Specified Intercharacter Delay....... 4-5 Interfunction Delay............4-6 Intermessage Delay ............4-6 Chapter 5 - Data Formatting Data Format Editor Introduction........... 5-1 To Add a Data Format............ 5-1 Other Programming Selections ........5-2 Data Format Editor Commands........
Page 10 Code 93 Message Length ..........7-11 Code 93 Code Page ............7-11 Straight 2 of 5 Industrial ............. 7-12 Straight 2 of 5 Industrial Message Length ....7-12 Straight 2 of 5 IATA Message Length......7-13 Matrix 2 of 5 ............... 7-13 Matrix 2 of 5 Message Length ........
Page 11 UPC E0 and UPC E1 ............7-20 UPC E0 and UPC E1 Expand........7-21 UPC E0 and UPC E1 Addenda Required..... 7-21 UPC E0 and UPC E1 Addenda Separator ....7-21 UPC E0 Check Digit ............ 7-21 UPC E0 Number System..........7-22 UPC E0 Addenda ............
Page 12 Keyboard Function Relationships......... 8-1 Supported Interface Keys ............ 8-3 Chapter 9 - Utilities To Add a Test Code I.D. Prefix to All Symbologies.... 9-1 Show Software Revision............9-1 Show Data Format ..............9-1 Resetting the Standard Product Defaults ......9-1 Temporary Visual Xpress Configuration......
Page 13 Online Product Service and Repair Assistance .... 14-2 Technical Assistance............14-2 Online Technical Assistance ........14-3 Limited Warranty..............14-3 Appendix A - Appendix A Symbology Chart ..............A-1 ASCII Conversion Chart (Code Page 1252)......A-2 Code Page Mapping of Printed Bar Codes ......A-4...
Page 14 viii...
Page 15: Chapter 1 - Getting Started
3800g. Product specifications, dimensions, warranty, and customer support information are also included. Hand Held Products bar code imagers are factory programmed for the most common terminal and communications settings. If you need to change these settings, programming is accomplished by scanning the bar codes in this guide.
Page 16: Connecting The Imager With Usb
Held Products “USB Application Note,” available at www.handheld.com. USB PC or Macintosh Keyboard The 3800g imagers are factory programmed for a USB interface. If this is your interface and you do not need to modify the settings, skip to Chapter...
Page 17: Ibm Surepos
IBM SurePos Scan one of the following “Plug and Play” codes to program the 3800gX5 for IBM SurePos (USB Handheld imager) or IBM SurePos (USB Tabletop imager). Note: After scanning one of these codes, you must power cycle the cash register.
Page 18: Ack/Nak Mode
Plug and Play Plug and Play bar codes provide instant imager set up for commonly used interfaces. Note: After you scan one of the codes, power cycle the host terminal to have the interface in effect. 1 - 4 3800g User’s Guide...
Page 19: Connecting The Imager When Powered By Host (Keyboard Wedge)
3. Connect the appropriate interface cable to the imager and to the terminal/ computer. 4. Turn the terminal/computer power back on. Note: You will not hear a power-up beep because the 3800g is factory defaulted to a USB connection. You must scan the IBM PC AT and Compatibles...
Page 20: Laptop Direct Connect
1. Turn off power to the terminal/computer. 2. Connect the appropriate interface cable to the imager. Note: For the imager to work properly, you must have the correct cable for your type of terminal/computer. 3. Plug the serial connector into the serial port on your computer. Tighten the two screws to secure the connector to the port.
Page 21: Ibm 4683 Ports 5B, 9B, And 17 Interface
RS-232 protocol. Scanning the RS-232 interface bar code, programs the imager for an RS-232 interface at 38,400 baud, parity–none, 8 data bits, 1 stop bit, and adds a suffix of a CR LF. RS-232 Interface...
Page 22: Reading Techniques
The best focus point for reading most code densities is about 5 inches (12.7 cm) from the unit. To read a single bar code or multiple bar codes (on a page or on an object), hold the imager at an appropriate distance from the target, pull the trigger, and center the aiming beam on the bar code.
Page 23: Chapter 2 - Terminal Interfaces
ID. Scan Save to save your selection. For example, an IBM AT terminal has a Terminal ID of 003. You would scan the Terminal ID bar code, then 0, 0, 3 from the...
Page 24: Supported Terminals
Esprit 200, 400 Heath Zenith PC, AT Vectra PS/2 25, 30, 77DX2 AT, PS/2 30–286, 50, 55SX, 60, 70, 70–061, 70–121, 80 IBM 102 key 3151, 3161, 3162, 3163, 3191, 3192, 3194, 3196, 3197, 3471, 3472, 3476, 3477 IBM 122 key...
Page 25 Supported Terminals (Continued) Terminal Model(s) Terminal ID Telex 122 key 078, 078A, 79, 80, 191, 196, 1191,1192, 1471, 1472, 1476, 1477, 1482, 1483 USB PC Keyboard 124 * USB Mac Keyboard USB Com Port USB HIDPOS * Factory default setting 3800g User’s Guide...
Page 26: Keyboard Country
As a general rule, the following characters are supported, but need special care for countries other than the United States: @ | $ # { } [ ] = / ‘ \ < > ~ * United States Belgium...
Page 27: Keyboard Style
U.S. keyboards). Shift Lock Automatic Caps Lock is used if you change the Caps Lock key on and off. The software tracks and reflects if you have Caps Lock on or off (AT and PS/2 only). This selection can only be used with systems that have an LED which notes the Caps Lock status.
Page 28: Keyboard Modifiers
Emulate External Keyboard should be scanned if you do not have an external keyboard (IBM AT or equivalent). Emulate External Keyboard Note: After scanning the Emulate External Keyboard bar code, you must power cycle your computer. Keyboard Modifiers This modifies special keyboard features, such as CTRL+ ASCII codes and Turbo Mode.
Page 29: Rs-232 Baud Rate
* Automatic Direct Connect Mode Off RS-232 Baud Rate Baud Rate sends the data from the imager to the terminal at the specified rate. The host terminal must be set for the same baud rate as the imager. Default = 115,200 .
Page 30: Rs-232 Word Length: Data Bits, Stop Bits, And Parity
RS-232 Word Length: Data Bits, Stop Bits, and Parity Data Bits sets the word length at 7 or 8 bits of data per character. If an application requires only ASCII Hex characters 0 through 7F decimal (text, digits, and punctuation), select 7 data bits. For applications which require use of the full ASCII set, select 8 data bits per character.
Page 31: Rs-232 Handshaking
RS-232 Handshaking RS-232 handshaking is a set of rules concerning the exchange of data between serially communicating devices. Default = RTS/CTS, XON/XOFF and ACK/ NAK Off . RTS/CTS On * RTS/CTS Off XON/XOFF On * XON/OFF Off ACK/NAK On * ACK/NAK Off 3800g User’s Guide...
Page 32 2 - 10 3800g User’s Guide...
Page 33: Chapter 3 - Output
Good Read Indicators Beeper – Good Read The beeper may be programmed On or Off in response to a good read. Turning this option off, only turns off the beeper response to a good read indication. All error and menu beeps are still audible. Default = On.
Page 34: Beeper Duration - Good Read
* On Number of Beeps – Good Read The number of beeps of a good read can be programmed from 1 - 9. The same number of beeps will be applied to the beeper and LED in response to a good read.
Page 35: Good Read Delay
Long Delay (1500 ms) User-Specified Good Read Delay If you want to set your own length for the good read delay, scan the bar code below, then set the delay (from 0-30,000 milliseconds) by scanning digits from the inside back cover, then scanning Save .
Page 36: Automatic Trigger
Presentation Mode uses ambient light to detect bar codes. The LEDs are off for ambient conditions until a change occurs in the imager’s field of view. Then the LEDS turn on automatically to read the code. If the light level in the room is not high enough, Presentation Mode may not work properly.
Page 37: Hands Free Time-Out
Hands Free Time-Out Reread Delay This sets the time period before the imager can read the same bar code a second time. Setting a reread delay protects against accidental rereads of the same bar code. Longer delays are effective in minimizing accidental rereads at POS (point of sale).
Page 38: User-Specified Reread Delay
User-Specified Reread Delay If you want to set your own length for the reread delay, scan the bar code below, then set the delay (from 0-30,000 milliseconds) by scanning digits from the inside back cover, then scanning Save . User-Specified Reread Delay Centering Window Use the centering feature to narrow the imager’s field of view so the imager reads...
Page 39 100% Example: If you have two bar codes next to one another and the centering window is set to 40% left edge and 60% right edge, only the bar code that intersects that window will be decoded. Decoded bar code 100% 3800g User’s Guide...
Page 40: Output Sequence Overview
Output Sequence Overview Require Output Sequence When turned off, the bar code data will be output to the host as the imager decodes it. When turned on, all output data must conform to an edited sequence or the imager will not transmit the output data to the host device.
Page 41: Output Sequence Editor
When the output sequence is Off , the bar code data is output to the host as the imager decodes it.
Page 42 To program the previous example using specific lengths, you would have to count any programmed prefixes, suffixes, or formatted characters as part of the length. If you use the example on page 3-9, but assume a <CR> suffix and specific code lengths, you would use the following command line:...
Page 43: Multiple Symbols
* Off No Read With No Read turned On , the imager sends an “NR” to the host if you pull and release the trigger without reading a code (e.g., bad bar code). If No Read is turned Off , the “NR” will not be sent to the host.
Page 44: Video Reverse
No Read symbol is 9C. Video Reverse Video Reverse is used to allow the imager to read bar codes that are inverted. The “Off” bar code below is an example of this type of bar code. Note: If additional menuing is required, Video Reverse must be disabled to read the menu bar codes and then re-enabled after menuing is completed.
Page 45: Chapter 4 - Data Editing
A-2, plus Code I.D. and AIM I.D. • You can string together several entries for several symbologies at one time. • Enter prefixes and suffixes in the order in which you want them to appear on the output.
Page 46: To Add A Prefix Or Suffix
To add AIM I.D., scan 5, C, 8, 1. To add a backslash (\), scan 5, C, 5, C. Note: To add a backslash (\) as in Step 7, you must scan 5C twice – once to create the leading backslash and then to create the backslash itself.
Page 47: To Clear One Or All Prefixes Or Suffixes
Your change is automatically saved. To Add a Carriage Return Suffix to all Symbologies Scan the following bar code if you wish to add a carriage return suffix to all symbologies at once. This action first clears all current suffixes, then programs a carriage return suffix for all symbologies.
Page 48: Suffix Selections
Intercharacter, interfunction, and intermessage delays slow the transmission of data, increasing data integrity. Each delay is composed of a 5 millisecond step. You can program up to 99 steps (of 5 ms each) for a range of 0-495 ms. 4 - 4...
Page 49: Intercharacter Delay
Page 1252) on page A-2. Delay Length Character to Trigger Delay To remove this delay, scan the Delay Length bar code, and set the number of steps to 0. Scan the SAVE bar code using the Programming Chart inside the back cover of this manual.
Page 50: Interfunction Delay
An interfunction delay of up to 495 milliseconds may be placed between the transmission of each segment of the message string. Scan the Interfunction Delay bar code below, then scan the number of milliseconds and the SAVE bar code using the Programming Chart inside the back cover of this manual.
Page 51: Chapter 5 - Data Formatting
The selections in the following pages are used only if you wish to alter the output. Default Data Format setting = None. Normally, when you scan a bar code, it gets outputted automatically; however when you do a format, you must use a “send”...
Page 52: Other Programming Selections
Programming Chart inside the back cover of this manual. If you are clearing an alternate format, scan 1, 2, or 3, depending on the alternate format you are clearing. Scan the Terminal Type (refer to the Supported Terminals Chart on page 2-2), Code I.D.
Page 53 FC command is encountered, the suppress function is terminated. The cursor is not moved by the FB command. Syntax = FBnnxxyy . .zz where nn is a count of the number of suppressed characters in the list and xxyy .. 3800g User’s Guide...
Page 54: Data Format Editor
(xx stands for the hex value for an ASCII code, see ASCII Conversion Chart (Code Page 1252) on page A- FC Disables suppress filter and clear all suppressed characters. Syntax = FC.
Page 55: Data Formatter
Data Formatter When Data Formatter is turned off, the bar code data is output to the host as read (including prefixes and suffixes). Choose one of the following options. Default = Data Formatter On. * Data Formatter On, but Not Required...
Page 56 5 - 6 3800g User’s Guide...
Page 57: Chapter 6 - Secondary Interface
By switching secondary interface cables, the 3800g imager, for example, can communicate with a portable data terminal (secondary interface) in addition to the host terminal (primary interface). See the table below for the secondary interfaces for the 3800g. 3800g Models...
Page 58: Secondary Trigger Mode
RS-232 programmable selections are used by both the primary and secondary interfaces. Changing an RS-232 parameter (e.g., baud rate or parity), while in primary or secondary mode will affect both interfaces. If you want to change the RS-232 settings, refer to the Connecting the Imager with RS-232 Serial Port section on page 1-6.
Page 59: Hands Free Time-Out
The Automatic Trigger and Presentation Modes are referred to as “hands free” modes. If the imager’s trigger is pulled when using a hands free mode, the imager changes to manual trigger mode. You can set the time the imager should remain in manual trigger mode by setting the Hands Free Time-Out.
Page 60 6 - 4 3800g User’s Guide...
Page 61: Introduction
UPC E All Symbologies If you want to decode all the symbologies allowable for your imager, scan the All Symbologies On code. If on the other hand, you want to decode only a particular symbology, scan All Symbologies Off followed by the On symbol for that particular symbology.
Page 62: Message Length
Message Length You are able to set the valid reading length of some of the bar code symbologies. If the data length of the scanned bar code doesn’t match the valid reading length, the imager will issue an error beep. You may wish to set the same value for minimum and maximum length to force the imager to read fixed length bar code data.
Page 63: Codabar
No Check Character indicates that the imager reads and transmits bar code data with or without a check character. When Check Character is set to Validate and Transmit , the imager will only read Codabar bar codes printed with a check character, and will transmit this character at the end of the scanned data.
Page 64: Codabar Concatenation
When Check Character is set to Validate, but Don’t Transmit , the unit will only read Codabar bar codes printed with a check character, but will not transmit the check character with the scanned data. * No Check Character Validate Modulo 16, but Don’t Transmit...
Page 65: Codabar Message Length
< Default All Code 39 Settings > Code 39 * On Code 39 Start/Stop Characters Start/Stop characters identify the leading and trailing ends of the bar code. You may either transmit, or not transmit Start/Stop characters. Default = Don’t Transmit. Transmit * Don’t Transmit...
Page 66: Code 39 Check Character
When Check Character is set to Validate, but Don’t Transmit, the unit only reads Code 39 bar codes printed with a check character, but will not transmit the check character with the scanned data.
Page 67: Code 39 Append
(excluding the start and stop symbols), and does not immediately transmit the data. The imager stores the data in the order in which the bar codes are read, deleting the first space from each. The imager transmits the appended data when it reads a Code 39 bar code that starts with a character other than a space.
Page 68: Full Ascii
Full ASCII If Full ASCII Code 39 decoding is enabled, certain character pairs within the bar code symbol will be interpreted as a single character. For example: $V will be decoded as the ASCII character SYN, and /C will be decoded as the ASCII character #.
Page 69: Code 39 Code Page
If this is the case, scan the bar code below, select the code page with which the bar codes were created from the chart,...
Page 70: Interleaved 2 Of 5 Message Length
When Check Digit is set to Validate, but Don’t Transmit, the unit only reads Interleaved 2 of 5 bar codes printed with a check digit, but will not transmit the check digit with the scanned data. When Check Digit is set to Validate and Transmit, the imager only reads Interleaved 2 of 5 bar codes printed with a check digit, and will transmit this digit at the end of the scanned data.
Page 71: Code 93
If this is the case, scan the bar code below, select the code page with which the bar codes were created from the chart,...
Page 72: Straight 2 Of 5 Industrial
<Default All Straight 2 of 5 Settings> Straight 2 of 5 Industrial * Off Straight 2 of 5 Industrial Message Length Scan the bar codes below to change the message length. Refer to Message Length on page 7-2 for additional information. Minimum and Maximum lengths = 1-48.
Page 73: Straight 2 Of 5 Iata Message Length
Straight 2 of 5 IATA * Off Straight 2 of 5 IATA Message Length Scan the bar codes below to change the message length. Refer to Message Length on page 7-2 for additional information. Minimum and Maximum lengths = 1-48. Minimum Default = 4, Maximum Default = 48.
Page 74: Matrix 2 Of 5 Message Length
<Default All Code 11 Settings> Code 11 * Off Check Digits Required This option sets whether 1 or 2 check digits are required with Code 11 bar codes. Default = Two Check Digits. One Check Digit * Two Check Digits 7 - 14 3800g User’s Guide...
Page 75: Code 11 Message Length
ISBT formats requires a paid license. The ISBT 128 Application Specification describes 1) the critical data elements for labeling blood products, 2) the current recommendation to use Code 128 due to its high degree of security and its space-efficient design, 3) a variation of Code 128 that supports concatenation of neighboring symbols, and 4) the standard layout for bar codes on a blood product label.
Page 76: Code 128 Message Length
If this is the case, scan the bar code below, select the code page with which the bar codes were created from the chart,...
Page 77: Telepen
* Off Telepen Output Using AIM Telepen Output, the imager reads symbols with start/stop pattern 1 and decodes them as standard full ASCII (start/stop pattern 1). When Original Telepen Output is selected, the imager reads symbols with start/stop pattern 1 and decodes them as compressed numeric with optional full ASCII (start/stop pattern 2).
Page 78: Upc A
* On UPC A Number System The numeric system digit of a U.P.C. symbol is normally transmitted at the beginning of the scanned data, but the unit can be programmed so it will not transmit it. Default = On. * On...
Page 79: Upc A Addenda Required
Required * Not Required UPC A Addenda Separator When this feature is on, there is a space between the data from the bar code and the data from the addenda. When turned off, there is no space. Default = On.
Page 80: Upc E0 And Upc E1
Most U.P.C. bar codes lead with the 0 number system. For these codes, use the UPC E0 selection. If you need to read codes that lead with the 1 number system, use the UPC E1 selection. Default = On (UPC E0) and Off (UPC E1).
Page 81: Upc E0 And Upc E1 Expand
* Not Required UPC E0 and UPC E1 Addenda Separator When this feature is on, there is a space between the data from the bar code and the data from the addenda. When turned off, there is no space. Default = On.
Page 82: Upc E0 Number System
Default = On. * On UPC E0 Addenda This selection adds 2 or 5 digits to the end of all scanned UPC E data. Default = Off for both 2 Digit and 5 Digit Addenda. 2 Digit Addenda On...
Page 83: Ean/Jan 13 Check Digit
Default = On. * On EAN/JAN 13 Addenda This selection adds 2 or 5 digits to the end of all scanned EAN/JAN 13 data. Default = Off for both 2 Digit and 5 Digit Addenda. 2 Digit Addenda On...
Page 84: Ean/Jan 13 Addenda Separator
EAN/JAN 13 Addenda Separator When this feature is on, there is a space between the data from the bar code and the data from the addenda. When turned off, there is no space. Default = On. * On Note: If you want to enable or disable EAN13 with Extended Coupon Code,...
Page 85: Ean/Jan 8 Check Digit
Default = On. * On EAN/JAN 8 Addenda This selection adds 2 or 5 digits to the end of all scanned EAN/JAN 8 data. Default = Off for both 2 Digit and 5 Digit Addenda. 2 Digit Addenda On...
Page 86: Ean/Jan 8 Addenda Separator
EAN/JAN 8 Addenda Separator When this feature is on, there is a space between the data from the bar code and the data from the addenda. When turned off, there is no space. Default = On. * On <Default All MSI Settings>...
Page 87: Msi Message Length
MSI Message Length Scan the bar codes below to change the message length. Refer to Message Length on page 7-2 for additional information. Minimum and Maximum lengths = 4-48. Minimum Default = 4, Maximum Default = 48. Minimum Message Length...
Page 88: Rss Limited
RSS-14 < Default All RSS-14 Settings > RSS-14 * On RSS Limited < Default All RSS Limited Settings > RSS Limited * On RSS Expanded < Default All RSS Expanded Settings > 7 - 28 3800g User’s Guide...
Page 89: Rss Expanded Message Length
Identifier will be reported as “]C1”. If RSS Emulation is selected, the AIM Symbology Identifier will be reported as “]e0.” Any application that accepts EAN•UCC data can be simplified since it only needs to recognize one data carrier type. Default = EAN•UCC Emulation Off .
Page 90: China Post Code
<Default All China Post Code Settings> China Post Code * Off China Post Message Length Scan the bar codes below to change the message length. Refer to Message Length on page 7-2 for additional information. Minimum and Maximum lengths = 2-80. Minimum Default = 4, Maximum Default = 80.
Page 91: Korea Post Code
<Default All Korea Post Code Settings> Korea Post Code * Off Korea Post Message Length Scan the bar codes below to change the message length. Refer to Message Length on page 7-2 for additional information. Minimum and Maximum lengths = 2-80. Minimum Default = 4, Maximum Default = 48.
Page 92: Posicode Message Length
You have to have PosiCode A and B on to read any of the PosiCode symbologies. A and B On (No Limited) A and B and Limited A On (Limited B Off) * A and B and Limited B On...
Page 93: Codablock F
<Default All Codablock F Settings> Codablock F * Off Codablock F Message Length Scan the bar codes below to change the message length. Refer to Message Length on page 7-2 for additional information. Minimum and Maximum lengths = 1-2048. Minimum Default = 1, Maximum Default = 2048.
Page 94: Code 16K
Code 16K * Off Code 16K Message Length Scan the bar codes below to change the message length. Refer to Message Length on page 7-2 for additional information. Minimum and Maximum lengths = 0-160. Minimum Default = 1, Maximum Default = 160.
Page 95: Code 49 Message Length
Code 49 Message Length Scan the bar codes below to change the message length. Refer to Message Length on page 7-2 for additional information. Minimum and Maximum lengths = 1-81. Minimum Default = 1, Maximum Default = 81. Minimum Message Length Maximum Message Length 3800g User’s Guide...
Page 96 7 - 36 3800g User’s Guide...
Page 97: Chapter 8 - Interface Keys
Interface Keys Keyboard Function Relationships The following Keyboard Function Code, Hex/ASCII Value, and Full ASCII “CTRL”+ relationships apply to all terminals that can be used with the imager. Refer to page 2-6 enable Control + ASCII mode. Function Code HEX/ASCII Value Full ASCII “CTRL”...
Page 98 The last five characters in the Full ASCII “CTRL”+ column ( [ \ ] 6 - ), apply to US only. The following chart indicates the equivalents of these five characters for different countries. Country Codes United States Belgium <...
Page 99: Supported Interface Keys
Insert Insert Escape Escape Reserved Error Reset Home Home Home Print Print Back Space Back Space Back Space Back Tab Back Tab Backfield/Back Tab Reserved * IBM 3191/92, 3471/72, 3196/97, 3476/77, Telex (all models) 3800g User’s Guide 8 - 3...
Page 100 Reserved Print Print Back Space Back Space Back Tab Back Field Reserved Home * IBM 3196/97, 3476/77, 3191/92, 3471/72, Memorex Telex (all models) with 102 key keyboards ** Memorex Telex with 88 key keyboards 8 - 4 3800g User’s Guide...
Page 101 Supported Interface Keys Esprit 200, 400 Esprit 200, 400 Esprit 200, 400 ANSI ASCII ASCII Supported Keys Supported Keys Supported Keys Reserved Reserved Reserved New Line New Line New Line New Line New Line New Line Delete New Line New Line...
Page 102 Supported Interface Keys Apple Mac/iMac ASCII Supported Keys Reserved Enter/Numpad Enter CAPS ALT make ALT break CNTRL make CNTRL break RETURN APPLE make APPLE break RETURN Ins Help Home Prnt Scrn BACKSPACE LSHIFT TAB BACKSPACE 8 - 6 3800g User’s Guide...
Page 103: Chapter 9 - Utilities
Utilities To Add a Test Code I.D. Prefix to All Symbologies This selection allows you to turn on transmission of a Code I.D. before the decoded symbology. (See the Symbology Chart, included in the Appendix A, page A-1) for the single character code that identifies each symbology.) This action first clears all current prefixes, then programs a Code I.D.
Page 104: Temporary Visual Xpress Configuration
Visual Xpress on page 10-1 for additional information about Visual Xpress. Note: If you have a unit capable of keyboard wedge mode, scan the bar code below and the unit will communicate in RS-232 mode, allowing it to work with Visual Xpress. To convert the imager back to keyboard wedge communication, cycle the power.
Page 105: Chapter 10 - Visual Xpress
This saved file can be e-mailed or, if required, you can create a single bar code that contains all the customized programming parameters and mail or fax that bar code to any location. Users in other locations can scan the bar code to load in the customized programming.
Page 106: Installing Visual Xpress From The Web
6. Once you have finished downloading the file, exit the web site. 7. Using Explorer, go to the c:\windows\temp file and unzip the file you saved. 8. Double click on Setup.exe and follow the screen prompts to install the Visual Xpress program.
Page 107: Chapter 11 - Serial Programming Commands
PC com port using terminal emulation software. Conventions The following conventions are used for menu and query command descriptions: parameter A label representing the actual value you should send as part of a command. [ option ] An optional part of a command.
Page 108: Query Commands
Tag Field Usage When a query is used in place of a Tag field, the query applies to the entire set of commands available for the particular storage table indicated by the Storage field of the command. In this case, the SubTag and Data fields should not be used because they are ignored by the device.
Page 109: Examples Of Query Commands
(the period, exclamation point, comma, or semicolon) in the command. Examples of Query Commands In the following examples, a bracketed notation [ ] depicts a non-displayable response. Example: Example #1:What is the range of possible values for Codabar...
Page 110: Trigger Commands
Standard Product Default Settings bar code below. Standard Product Default Settings The chart on the following pages lists the factory default settings for each of the menu commands (indicated by an asterisk (*) on the programming pages). 11 - 4...
Page 111: Menu Commands
Caps Lock KBDSTY1 Shift Lock KBDSTY2 Keyboard Style Automatic Caps Lock KBDSTY6 Emulate External KBDSTY5 Keyboard *Control + ASCII Off KBDCAS0 Control + ASCII On KBDCAS1 *Turbo Mode Off KBDTMD0 Turbo Mode On KBDTMD1 Keyboard Modifiers *Numeric Keypad Off KBDNPS0...
Page 112: Output Selections
19200 BPS 232BAD6 38400 BPS 232BAD7 57600 BPS 232BAD8 *115200 BPS 232BAD9 7 Data, 1 Stop, Parity Even 232WRD3 7 Data, 1 Stop, Parity None 232WRD0 7 Data, 1 Stop, Parity Odd 232WRD6 7 Data, 2 Stop, Parity Even 232WRD4...
Page 113 Serial Setting Command Selection Page * Indicates default # Indicates a numeric entry Low (1600) (min 400Hz) BEPFQ11600 Beeper Pitch - Good Read *Medium (2550) BEPFQ12550 (Frequency) High (4200) (max 9000Hz) BEPFQ14200 *Normal Beep BEPBIP0 Beeper Duration - Good Read...
Page 114: Data Formatter Selections
3-11 No Read *Off SHWNRD0 3-11 VIDREV1 3-11 Video Reverse *Off VIDREV0 3-11 Prefix/Suffix Selections Add CR Suffix to All Symbologies VSUFCR Add Prefix PREBK2## Prefix Clear One Prefix PRECL2 Clear All Prefixes PRECA2 Add Suffix SUFBK2## Suffix Clear One Suffix...
Page 115 Validate, But Don’t Transmit CBRCK21 Validate, and Transmit CBRCK22 *Off CBRCCT0 Codabar Concatenation CBRCCT1 Require CBRCCT2 Minimum (2 - 60) *4 CBRMIN## Codabar Message Length Maximum (2 - 60) *60 CBRMAX## Default All Code 39 Code 39 C39DFT Settings 3800g User’s Guide...
Page 116 C93ENA1 7-11 Minimum (0 - 80) *0 C93MIN## 7-11 Code 93 Message Length Maximum (0 - 80) *80 C93MAX## 7-11 Default All Straight 2 of 5 Straight 2 of 5 Industrial R25DFT 7-12 Settings 11 - 10 3800g User’s Guide...
Page 117 Minimum (1 - 48) *4 R25MIN## 7-12 Straight 2 of 5 Industrial Message Length Maximum (1 - 48) *48 R25MAX## 7-12 Default All Straight 2 of 5 IATA Straight 2 of 5 IATA A25DFT 7-13 Settings *Off A25ENA0 7-13 Straight 2 of 5 IATA...
Page 118 7-17 Telepen TELENA1 7-17 *AIM Telepen Output TELOLD0 7-17 Telepen Output Original Telepen Output TELOLD1 7-17 Minimum (1 - 60) *1 TELMIN## 7-17 Telepen Message Length Maximum (1 - 60) *60 TELMAX## 7-17 Default All UPC A UPADFT 7-18 UPC A Settings...
Page 119 7-21 UPC E Check Digit UPECKX1 7-21 UPENSX0 7-22 UPC E Number System UPENSX1 7-22 *Off UPEAD20 7-22 UPC E 2 Digit Addenda UPEAD21 7-22 *Off UPEAD50 7-22 UPC E 5 Digit Addenda UPEAD51 7-22 *Not Required UPEARQ0 7-21 UPC E Addenda Required...
Page 120 Coupon Code CPNENA1 7-20 Default All MSI Settings MSIDFT 7-26 *Off MSIENA0 7-26 MSIENA1 7-26 *Validate Type 10, but Don’t MSICHK0 7-26 Transmit MSI Check Character Validate Type 10 and MSICHK1 7-26 Transmit Minimum (4 - 48) *4 MSIMIN## 7-27...
Page 121 7-31 POSENA0 7-31 POSENA1 7-31 PosiCode A and B On POSLIM0 7-32 A and B and Limited A On POSLIM1 7-32 *A and B and Limited B On POSLIM2 7-32 Minimum (2 - 80) *4 POSMIN## 7-32 PosiCode Msg. Length...
Page 122 * Indicates default # Indicates a numeric entry *Off CBFENA0 7-33 Codablock F CBFENA1 7-33 Minimum (1 - 2048) *1 CBFMIN#### 7-33 Codablock F Msg. Length Maximum (1 - 2048) *2048 CBFMAX#### 7-33 Code 16K Default All Code 16K Settings...
Page 123: Chapter 12 - Product Specifications
3800GX5E @4.5-12Vdc 126mA 50mA Temperature Ranges: Operating 32° F to +122° F (0° C to +50° C) Storage -40° F to +140° F (-40° C to +60° C) Humidity 0 to 95% non-condensing Operational after 50 drops from 5 feet Mechanical Drop (1.5 m) to concrete...
Page 124: 3800G Depth Of Field (Typical Performance)
20 mil Code 39 .5 in (1.3 cm) 29 in (74 cm) 55 mil Code 39 4 in (10.2 cm) 44 in (112 cm) 1. May be impacted by bar code quality and environmental conditions. 12 - 2 3800g User’s Guide...
Page 125: Standard Cable Pinouts
Standard Cable Pinouts Keyboard Wedge 3800g User’s Guide 12 - 3...
Page 126 Standard Cable Pinouts Serial Output 12 - 4 3800g User’s Guide...
Page 127 Standard Cable Pinouts 3800g User’s Guide 12 - 5...
Page 128 12 - 6 3800g User’s Guide...
Page 129: Chapter 13 - Maintenance
Reading performance may degrade if the scanner’s window is not clean. If the window is visibly dirty, or if the scanner isn’t operating well, clean the window with a soft cloth or lens tissue dampened with water (or a mild soapy water solution).
Page 130: Replacing The Interface Cable
The standard interface cable is attached to the scanner with an 10-pin modular connector. When properly seated, the connector is held in the 3800g scanner’s handle by a flexible retention tab. The interface cable is designed to be field replaceable.
Page 131 (the Enter/Return key or the Tab key, for example). You need to program a suffix. Programming a suffix enables the scanner to output the bar code data plus the key you need (such as “CR”) to enter the data into your application. Refer to...
Page 132 13 - 4 3800g User’s Guide...
Page 133: Chapter 14 - Customer Support
Hand Held Products provides service for all its products through service centers throughout the world. To obtain warranty or non-warranty service, return the unit to Hand Held Products (postage paid) with a copy of the dated purchase record attached. Contact the appropriate location below to obtain a Return Material Authorization number (RMA #) before returning the product.
Page 134: Online Product Service And Repair Assistance
Telephone: +81-3-5770-6312 Fax: +81-3-5770-6313 E-mail: apservice@handheld.com Online Product Service and Repair Assistance You can also access product service and repair assistance online at www.handheld.com. Technical Assistance If you need assistance installing or troubleshooting, please call your Distributor or the nearest Hand Held Products technical support office:...
Page 135: Online Technical Assistance
(C) static electricity or electro-static discharge, (D) operation under conditions beyond the specified operating parameters, or (E) repair or service of the product by anyone other than Hand Held Products or its authorized representatives. This warranty shall extend from the time of shipment for the duration published by Hand Held Products for the product at the time of purchase ("Warranty...
Page 136 All provisions of this Limited Warranty are separate and severable, which means that if any provision is held invalid and unenforceable, such determination shall not affect the validity of enforceability of the other provisions hereof. Use of any peripherals not manufactured/sold by Hand Held Products voids the warranty.
Page 137: Symbology Chart
Note: Prefix/Suffix entries for specific symbologies override the universal (All Symbologies, 99) entry. Refer to Data Editing beginning on page 4-1 and Data Formatting beginning on page 5-1 for information about using Code ID and AIM ID. 3800g User’s Guide A - 1...
Page 138: Ascii Conversion Chart (Code Page 1252
ASCII Conversion Chart (Code Page 1252 Note: This table applies to U.S. style keyboards. Certain characters may differ depending on your Country Code/PC regional settings. Dec Hex Char Hex Char Dec Char Dec Hex Char ‘ “ & ‘ <...
Page 139 — · × ÷ ˜ ¸ Ø ø ™ ¹ Ù ù š Ú ú › » Û û œ ¼ Ü ü ½ Ý ý ž ¾ Þ þ Ÿ ¿ ß ÿ 3800g User’s Guide A - 3...
Page 140: Code Page Mapping Of Printed Bar Codes
If this is the case, select the code page with which the bar codes were created. The data characters should then appear properly.
Page 141 Sample Symbols UPC A 0 123456 7890 Interleaved 2 of 5 1234567890 Code 128 Code 128 EAN 13 9 780330 290951 EAN 8 3210 5 UPC-E 456123...
Page 142 Sample Symbols Code 39 Codabar BC321 Code 93 A13579B Straight 2 of 5 Industrial 123456-9$ Matrix 2 of 5 123456 6543210 RSS-14 (01)00123456789012...
Page 143: Programming Chart
Programming Chart Discard Save Note: If you make an error while scanning the letters or digits (before scanning Save), scan Discard, scan the correct letters or digits, and Save.
Page 144 Hand Held Products, Inc. 700 Visions Drive P.O. Box 208 Skaneateles Falls, NY 13153-0208 3800g-UG Rev A 4/06...
