ALUMINIUM MINI-MOBILE
SCAFFOLD SYSTEM
FREEPHONE 0800 394 222
sales@easyaccess.co.nz www.easyaccess.co.nz
SCAFFOLD SYSTEMS
OPERATIONAL SAFETY AND ASSEMBLY
INSTRUCTIONS FOR ALUMINIUM
MINI-MOBILE SCAFFOLD SYSTEM
Users of an Easy Access Mini-
Mobile Scaffold System - Please
read the following instructions carefully
and do not erect or use the scaffold
until the instructions have been read
and understood.
We strongly suggest that users be
familiar with and follow the 'Standard
for Scaffolding' AS/NZS 1576.1-
6:2010. This is available from
Standards Australia and NZ.
Further information is available in the
SARNZ publication; 'Best Practise
guidelines for Scaffolding in NZ',
also www.workcover.nsw.govt.au
and www.worksafe.govt.nz
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Easy Access MM210
Summary of Contents for Easy Access MM210
- Page 1 INSTRUCTIONS FOR ALUMINIUM MINI-MOBILE SCAFFOLD SYSTEM ALUMINIUM MINI-MOBILE SCAFFOLD SYSTEM Users of an Easy Access Mini- Mobile Scaffold System - Please read the following instructions carefully and do not erect or use the scaffold until the instructions have been read and understood.
-
Page 2: Maintenance
Additional components such as handrails can be purchased at any time from the supplier. Ensure casters are firmly secured to the frames. Tighten retaining bolt if required. DO NOT OVER TIGHTEN. All components used in the Mini-Mobile must be supplied by Easy Access Co. ASSEMBLY INSTRUCTIONS... - Page 3 SAFETY DO NOT use the MINI-MOBILE: • If the total load will exceed 225 kilograms. • If the user is affected by alcohol or drugs. • If any conductors of an overhead electrical power line are less than 4 metres from the Mini-Mobile. •...
- Page 4 GUARDRAILING • Clip-on guardrails and midrails attach to the inside of the frame uprights above any cross-member. Note: the only location where a guardrail may be attached on the outside of the frame is where the cross brace location prevents it from attaching on the inside. •...
- Page 5 EXTRA HEIGHT FRAMES • Two Mini-Mobile sets may be joined vertically for greater reach heights. • Castors are easily removed from the top set if fitted by loosening the locking bolt in the base of the castor. • Expanding spigots are used to join the frames together. These must be securely tightened with a spanner after frames are located.
- Page 6 CORNER PACK • Mini-Mobiles can be joined together at 90 degrees to each other using a corner pack. • The corner pack consists of a base member which attaches to the side of a Mini-Mobile frame and supports one end of a platform as shown. •...
- Page 7 Mini Mobile frame upright at the opposite end of the tower. 11. Keep All-Terrain frame uprights lubricated to ensure easy adjustment. Only use Easy Access D-Clips to retain the sliding cross member. These are easily replaced if lost, call your supplier.
- Page 8 WIDE BOARD EXTENSION SET 1. The set joins any 2 mini mobiles side to side and includes a Wideboard, 2x joining Guardrail frames and 2x joining Ledgers. 2. Place the Wide Board platform hooks over relevant transoms in-line with the Mini Mobile platforms. 3.
