Instruction and Safety Manual
Model
Improper use of this Nailer can result in death or serious injury!
This Manual contains important information about product safety.
Read and understand this Manual before operating the Nailer.
Never allow anyone who has not reviewed this manual to use the tool.
This manual should be stored in a safe place.
9BE40
DANGER
！
Advertisement
Table of Contents
Related Manuals for ALLFASTENERS 9BE40
Summary of Contents for ALLFASTENERS 9BE40
- Page 1 Instruction and Safety Manual 9BE40 Model DANGER ！ Improper use of this Nailer can result in death or serious injury! This Manual contains important information about product safety. Read and understand this Manual before operating the Nailer. Never allow anyone who has not reviewed this manual to use the tool.
-
Page 2: Table Of Contents
USING THE HOOK ......22 REGARDING LITHIUM-ION BATTERY CLEARING A JAM ......23 TRANSPORTATION ......10 MAINTENANCE EMPLOYER'S RESPONSIBILITIES ...10 MAINTENANCE AND INSPECTION.............24 OPERATION NAME OF PART .............11 SERVICE AND REPAIRS ......25 SPECIFICATIONS ............12 EXPLOSION OF 9BE40......28 NAIL SELECTION ............13 PARTS LIST ..........29... -
Page 3: Important Information
IMPORTANT INFORMATION Read and understand tool labels and all of the operating instructions,safety precautions and warnings in this manual before operating or maintaining this nailer. Failure to follow warnings could result in DEATH or SERIOUS INJURY. Most accidents that result from the operation and maintenance of Nailers are caused by the failure to observe basic safety rules or precautions. -
Page 4: Safety
SAFETY GENERAL POWER TOOL SAFETY WARNINGS ！ WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock,fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains-operated(coeded) power tool or battery-operated(cordless) power tool. - Page 5 SAFETY - Continued turning the power tool on. and any other condition that may affect the A wrench or a key left attached to a rotating part power tool’s operation. of the power tool may result in personal injury. If damaged, have the power tool repaired e) Do not overreach.
-
Page 6: Nailer Safety Warnings
SAFETY - Continued irritation or burns. California to cause cancer,birth defects or other 6) Service reproductive harm.Some example of these a) Have your power tool serviced by a qualified chemicals are: repair person using only original replacement ● Lead from lead-based paints, ●... - Page 7 SAFETY - Continued When operating the Nailer,always wear safety glasses with side shields,and make sure others in work area wear glasses too. Safety glasses must conform to the requirements of ANSI Standards Institute and provide protection against flying particles both from the front and side. The employer must enforce the use of safety glasses by the Nailer operator and others in work area.
- Page 8 SAFETY - Continued When loading fasteners into the Nailer, The fasteners can be driven into and through 1) do not depress the trigger; the wall and hit a person on the opposite side. 2)do not depress the push lever; 20. CHECK FOR LIVE WIRES. 3)keep the Nailer pointed downward.
-
Page 9: Important Safety Instructions For Battery Charger
SAFETY - Continued Do not operate the Nailer when you are tired. To avoid these risks, follow these basic safety The Nailer should never be used by you if you are instructions: under the influence of alcohol, drugs or medication READ ALL INSTRUCTIONS that makes you drowsy. -
Page 10: Important Safety Instructions For Use Of The Battery And Battery Battery Charger
SAFETY - Continued Table 1 RECOMMENDED MINIMUM AWG SIZE FOR EXTENSION CORDS FOR BATTERY CHARGERS AC Input Rating Amperes* AWG Size of Cord Length of Cord,Feet(Meter) Equal to or but less 25(7.5) 50(15) 100(30) 150(45) greater than than * If the input rating of battery charger is given in watts Follow these instructions to avoid the risk of injury: rather than in amperes,the corresponding ampere ！... -
Page 11: Caution On Lithium-Ion Battery
SAFETY - Continued the battery to severe physical shock. CAUTION ON LITHIUM-ION BATTERY 3. Do not use an apparently damaged or deformed To extend the lifetime, the lithium-ion battery is battery. equipped with a protection function to stop output. 4. Do not use the battery in reverse polarity. In the cases of 1 to 3 described below,when using 5. -
Page 12: Regarding Lithium-Ion Battery
SAFETY - Continued Power Output If an electrically conductive foreign object enters the terminals of the lithium ion battery,a short-circuit may 2 to 3 digit number occur resulting in the risk of fire.Please observe the following matters when storing the battery. ○... -
Page 13: Operation
The information contained in this Manual is designed to assist you in the safe operation of the Nailer. Some illustrations in this Manual may show details or attachments that differ from those on your own Nailer. PART NAMES 1. Cordless Concrete Nailer <9BE40> Top cover Handle Battery Trigger... -
Page 14: Specifications
3. Battery Charger Indicator light SEPCIFICATIONS 1. Cordless Concrete Nailer Model 9BE40 Motor DC Brushless Applicable Nail Length 1/2" - 1-1/2" Firing Mode Full sequential Cycle rate [Nails/second] 2 (Intermittent) Sound pressure level LpA 100 dB(A) Sound power level LwA... -
Page 15: Nail Selection
！ WARNING ● Be sure to use only the genuine nails for the 9BE40.The use of any other nails can result in tool malfunction and/or nail breakdown,leading to serious injuries. Only nails shown in the Table below can be driven with this Nailer. -
Page 16: Accessories
ACCESSORIES ！ DANGER ● Accessories other than those shown below can lead to malfunction and result in injuries. STANDARD ACCESSORIES 9BE40 1. Safety glasses..........1 2. Allen wrench for M5 screw......1 3. Battery(B1804003).......... 2 4. Battery Charger..........1 5. S torage Case ........... 1... - Page 17 3. Charging ！ WARNING Do not charge at voltage higher than indicated on the When the battery is connected to the battery charger, nameplate. charging will commence and the indicator light will If charged at voltage higher than indicated on the light in red.(See Table 2) nameplate,the charger will overheat.
-
Page 18: Before Operation
current,the battery may be damaged and its life will (3) Regarding recharging time(At 68°F(20°C)) become shorter. (2) Avoid recharging at high temperatures. Table 4 Charging time A rechargeable battery will be hot immediately after Current use.If such a battery is recharged immediately after 1.8A 2.3A 4.0A... -
Page 19: Testing The Nailer
(3) Other functions Power indicator In case of operating error,LED lamps show as below. Status of indicator Tool is in too cold Power switch (below 23°F(-5°C)) or too hot condition. Allow the nailer to cool LED(Green) blinks 2 times or warm-up thoroughly in adequate condition. - Page 20 CAUTION (3) Turn on the power switch. ！ ● Use caution not to throw the push lever trip onto Light in green wood. Before actually beginning the nailing work,test the Nailer by using the checklist below.Conduct the tests in the following order.
-
Page 21: Loading Nails
Make sure the power indicator is not blinking. (6) ① Without touching the trigger,depress the push If the power indicator is blinking in green three times lever against the workpiece with pulling back the regularly,the battery doesn't have enough power and it feeder knob. -
Page 22: Nailer Operation
NOTE: ● Quietly push the nail feeder and feeder knob against 3-Action Nail Feeding! (1) Insert nail strip into the back of the magazine. the nail. If the nail feeder and feeder knob are released from backward the magazine and bumped against the nail, the connecting plastic of the nail can be damaged. -
Page 23: Methods Of Operation
！ 7) handing it to another person. WARNING ● NEVER point tool at yourself or 1) loading nails; other in work area. 2) turning the adjuster. ● Keep fingers AWAY from trigger ！ when not driving nails to avoid CAUTION accidental firing. -
Page 24: Using The Hook
！ NOTE WARNING ● If all warnings and instructions are followed,safe To continue nailing in a separate location,move the nailer operation is possible with all two systems:FULL SEQUENTIAL ACTUATION MECHANISM, along the wood,repeating steps ② - ⑤ as required. CONTACT ACTUATION MECHANISM. ●... -
Page 25: Clearing A Jam
CLEARING A JAM If nails are jammed in firing head,remove it and adjust the nailing in the following order. ！ CAUTION ● Remove the battery from the Nailer. ① Remove the battery from the Nailer. ② Remove all nails. ③ Turn the lock knob in a clockwise direction. ④... -
Page 26: Maintenance
MAINTENANCE NOTE The information contained in this Manual is designed to assist you in the safe maintenance the Nailer. Some illustrations in this Manual may show details or attachments that differ from those on your own Nailer. MAINTENANCE AND INSPECTION <Nailer>... -
Page 27: Service And Repairs
or rendering the batteries incapable of holding a Important notice on the batteries for the cordless charge. power tools However,significantly reducing battery usage time may Please always use one of our designated genuine be recovered by repeatedly charging and using the batteries.We cannot guarantee the safety and batteries two to five times. - Page 28 PROBLEM CHECK METHOD CORRECTION Charge the battery. Low battery charge. Damaged internal electronics. Contact for replacement. Power switch doesn't turn on. Turns on once,but turn off Push lever and/or trigger is ON Keep push lever and trigger in OFF automatically. state? state.
- Page 29 PROBLEM CHECK METHOD COPRECTION Check for proper nails. Use only recommended nails. Nail feeder damaged? Replace nail feeder. Check position of nailing depth Replace ribbon spring. Skipping nails. adjustment adjuster. Intermittent feed. Contact service center for Driver blade worn or damaged? replacement.
-
Page 30: Explosion Of 9Be40
EXPLOSION OF 9BE40... -
Page 31: Parts List
Rubber Cap Dust Proof Retaining Ring d0=28 Countersunk Screw ST4.2×20 Bearing 6001-2RS Housing Cover Support Plate Cylinder Rubber Pad Upper Plate Valve Cover Magnet Valve Cylinder Cover Pin Ø5 O-ring 67.95X2.62 Pin Ø4 Cylinder Support Lifter Piston Guiding Ring Lower Plate X-Ring 40.64X5.33 Shaft Gear Box Assy... - Page 32 LOCATIONS NATIONWIDE: 888.859.6060 SALES@ALLFASTENERS.COM...
