GCL -NT10/78GDF595 Installation Manual

Solar pv modules
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION
MANUAL
FOR GCL SOLAR PV MODULES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GCL-NT10/78GDF595 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GCL GCL-NT10/78GDF595

Summary of Contents for GCL GCL-NT10/78GDF595

  • Page 1 INSTALLATION MANUAL FOR GCL SOLAR PV MODULES...
  • Page 2 Contents...
  • Page 3 This manual contains important safety instructions for the Photovoltaic solar module of GCL System Integration Technology Co., Ltd. (hereafter referred to as "GCL” Solar). Installers should follow all safety precautions described in this guide as well as local codes when installing a Module.

  • Page 4: Safety Precautions

    Introduce This Installation Manual contains essential information for electrical and mechanical installation that you must know before handling, installing Modules. This Manual also contains safety information you need to be familiar with. All the information described in this Manual is the intellectual property of us and is based on the technologies and experience that have been acquired and accumulated by us.

  • Page 5: Fire Safety

    Reflection from snow or water can increase sunlight and therefore boost current and power. In addition, colder temperatures can substantially increase voltage and power. If the glass or other material is damaged, please wear personal protection equipment and separated the nodule from the circuit.

  • Page 6: Installation Condition

    Installation Condition Installation Position and Working Environment Do not use mirrors or other magnifiers to concentrate sunlight onto the modules. Modules must be mounted on appropriate mounting structures positioned on suitable buildings, the ground, or other structures suitable for modules (e.g. carports, building facades or PV trackers). Modules must not be installed in locations where they could be submerged in water.
  • Page 7 Fig.1 Tilt angle Table 1 Recommended tilt angle for fixed systems Latitude Tilt angle 0°~15° 15° 15°~25° The same latitude 25°~30° Same latitude +5° 30°~35° Same latitude +10° Tilt angle 35°~40° Same latitude +15° Horizontal 40°+ Same latitude +20° Installation Requirements for Bifacial Module Under the certain installation conditions, the backside of bifacial cells module will also generate electricity power after receiving the reflected light, which will bring additional power generation gain to the power station system.

  • Page 8: Mechanical Installation

    Mechanical Installation Conventional Requirements Ensure the installation method and supporting system of Modules is strong enough to make the nodules can withstand all the load conditions. The Installer should provide this guarantee. The installation supporting system should be tested by the third-party organization with the analysis ability of Static Mechanical, according to the local national or international standards.
  • Page 9 Installation with the mounting clamp Clamping on the long side Note: The length of the clamp ≥50mm. Installation Method A Module dimensions Module Type Design load: (mm) downward/upward ym=1.5(Pa) GCL-NT10/78GDFxxx 2465×1134×30 3600/1600 GCL-NT10/72GDFxxx 2278×1134×30 3600/1600 GCL-NT10R/72GDFxxx 2382×1134×30 3600/1600 1800×1134×30 GCL-NT10R/54GDFxxx 3600/1600 1762×1134×30...

  • Page 10: Electrical Installation

    Electrical Installation Electrical Property Rated electrical characteristics such as Pmax is +/-3 % and Voc +/-3% and Isc +/-4% of tolerance values at Standard Test Conditions. Under normal conditions, the photovoltaic Modules may experience conditions that produce more current and/or voltage than reported at Standard Test Conditions. Accordingly, the values of short circuit current, Isc, and open circuit voltage, Voc, marked on Modules should be multiplied by a factor of 1.25 when determining component voltage ratings, conductor capacities, fusing sizes, and size of controls connected to the Modules output.
  • Page 11 Bypass Diodes If PV module part by shadow block, which can lead to reverse voltage related to solar cells, PV modules in other unaffected battery string or other PV modules in the system and current will force through keep out part of the power loss and heat affected cell.

  • Page 12: Operation And Maintenance

    The grounding conductor must be connected to ground via an appropriate grounding electrode. It is recommended to use lugs to connect the grounding cables. I f it is only mechanically connected to a grounded module without bolts and nuts, the mounting system should be grounded as well. First, peel the grounding cable to a proper length without damage to the metal core.

  • Page 13: Troubleshooting

    Module Appearance Inspection Inspect the Modules visually to find if there are appearance defect, the following two types need more attention especially: A) Whether the glass is broken; B) Corrosion along the cells’ bus-bar. The corrosion is caused by the dampness infiltrated into the Modules when the surface encapsulation material damaged during the installation or transportation.
  • Page 14 Performance at STC GCL- GCL- GCL- GCL- Module type NT10/78GDF595 NT10/78GDF600 NT10/78GDF605 NT10/78GDF610 Pmp [W] /Tolerance 595±3% 600±3% 605±3% 610±3% Voc [V] /Tolerance 55.80±3% 55.95±3% 56.10±3% 56.25±3% Isc [Adc] /Tolerance 13.45±4% 13.50±4% 13.55±4% 13.60±4% condition Vmp [V] 46.85 47.06 47.27 47.48...
  • Page 15 GCL- GCL- GCL- Module type NT10/78GDF635 NT10/78GDF640 NT10/78GDF645 Pmp [W] /Tolerance 635±3% 640±3% 645±3% Voc [V] /Tolerance 57.00±3% 57.15±3% 57.30±3% Isc [Adc] /Tolerance 13.85±4% 13.90±4% 13.95±4% condition 48.68 48.87 Vmp [V] 48.48 13.20 Imax [Adc] 13.10 13.15 Pmp [W] /Tolerance 695±3%...
  • Page 16 GCL- GCL- GCL- GCL- Module type NT12R/66GDF600 NT12R/66GDF605 NT12R/66GDF610 NT12R/66GDF615 Pmp [W] /Tolerance 600±3% 605±3% 610±3% 615±3% Voc [V] /Tolerance 47.80±3% 47.95±3% 48.10±3% 48.25±3% Isc [Adc] /Tolerance 15.75±4% 15.80±4% 15.85±4% 15.90±4% condition 40.34 40.53 40.73 Vmp [V] 40.14 15.05 15.10 Imax [Adc] 14.95...
  • Page 17 GCL- GCL- GCL- GCL- Module type NT12R/60GDF530 NT12R/60GDF535 NT12R/60GDF540 NT12R/60GDF545 Pmp [W] /Tolerance 530±3% 535±3% 540±3% 545±3% Voc [V] /Tolerance 42.87±3% 43.01±3% 43.15±3% 43.29±3% Isc [Adc] /Tolerance 15.62±4% 15.68±4% 15.74±4% 15.79±4% condition 35.96 36.15 36.36 Vmp [V] 35.76 14.94 14.99 Imax [Adc] 14.82...
  • Page 18 GCL- GCL- GCL- GCL- Module type NT12R/54GDF475 NT12R/54GDF480 NT12R/54GDF485 NT12R/54GDF490 Pmp [W] /Tolerance 475±3% 480±3% 485±3% 490±3% Voc [V] /Tolerance 38.55±3% 38.70±3% 38.85±3% 39.00±3% Isc [Adc] /Tolerance 15.58±4% 15.64±4% 15.70±4% 15.76±4% condition 32.35 32.55 32.76 Vmp [V] 32.14 14.90 14.96 Imax [Adc] 14.78...
  • Page 19 GCL- GCL- GCL- GCL- Module type NT10/44GDF-T340 NT10/44GDF-T345 NT10/44GDF-T350 NT10/44GDF-T355 Pmp [W] /Tolerance 340±3% 345±3% 350±3% 355±3% Voc [V] /Tolerance 31.28±3% 31.43±3% 31.58±3% 31.73±3% Isc [Adc] /Tolerance 13.73±4% 13.83±4% 13.93±4% 14.03±4% condition 26.38 26.58 26.78 Vmp [V] 26.18 13.17 13.26 Imax [Adc] 12.99...
  • Page 20 GCL- GCL- GCL- GCL- Module type NT10/72GDF550 NT10/72GDF555 NT10/72GDF560 NT10/72GDF565 Pmp [W] /Tolerance 550±3% 555±3% 560±3% 565±3% Voc [V] /Tolerance 50.99±3% 51.14±3% 51.29±3% 51.44±3% Isc [Adc] /Tolerance 13.65±4% 13.71±4% 13.77±4% 13.83±4% condition 42.75 42.95 43.15 Vmp [V] 42.54 13.04 13.09 Imax [Adc] 12.93...
  • Page 21 GCL- GCL- Module type NT10/72GDF590 NT10/72GDF595 Pmp [W] /Tolerance 590±3% 595±3% Voc [V] /Tolerance 52.20±3% 52.35±3% Isc [Adc] /Tolerance 14.13±4% 14.19±4% condition 44.35 Vmp [V] 44.15 Imax [Adc] 13.37 13.42 Pmp [W] /Tolerance 645±3% 650±3% BNPI Voc [V] /Tolerance 52.30±3% 52.45±3%...
  • Page 22 GCL- GCL- GCL- GCL- Module type NT10/60GDF480 NT10/60GDF485 NT10/60GDF490 NT10/60GDF495 GCL- GCL- GCL- GCL- Module type NT10/60GT480 NT10/60GT485 NT10/60GT490 NT10/60GT495 490±3% 495±3% Pmp [W] /Tolerance 480±3% 485±3% Voc [V] /Tolerance 43.15±3% 43.30±3% 43.45±3% 43.60±3% Isc [Adc] /Tolerance 13.96±4% 14.03±4% 14.10±4% 14.16±4%...
  • Page 23 GCL- GCL- GCL- Module type NT10/54GDF435 NT10/54GDF440 NT10/54GDF445 GCL- GCL- GCL- Module type NT10/54GDF-J435 NT10/54GDF-J440 NT10/54GDF-J445 GCL- GCL- GCL- Module type NT10/54GDF-B435 NT10/54GDF-B440 NT10/54GDF-B445 Pmp [W] /Tolerance 435±3% 440±3% 445±3% Voc [V] /Tolerance 39.06±3% 39.20±3% 39.34±3% Isc [Adc] /Tolerance 14.01±4% 14.07±4%...
  • Page 24 GCL- GCL- GCL- GCL- Module type NT10R/72GDF590 NT10R/72GDF595 NT10R/72GDF600 NT10R/72GDF605 Pmp [W] /Tolerance 590±3% 595±3% 600±3% 605±3% Voc [V] /Tolerance 51.29±3% 51.44±3% 51.60±3% 51.75±3% Isc [Adc] /Tolerance 14.45±4% 14.50±4% 14.55±4% 14.60±4% condition 43.15 43.35 43.56 Vmp [V] 42.95 13.84 13.89 Imax [Adc] 13.74...
  • Page 25 GCL- GCL- GCL- GCL- Module type NT10R/54GDF425 NT10R/54GDF430 NT10R/54GDF435 NT10R/54GDF440 GCL- GCL- GCL- GCL- Module type NT10R/54BGDF425 NT10R/54BGDF430 NT10R/54BGDF435 NT10R/54BGDF440 435±3% 440±3% Pmp [W] /Tolerance 425±3% 430±3% Voc [V] /Tolerance 38.75±3% 39.00±3% 39.25±3% 39.50±3% Isc [Adc] /Tolerance 13.70±4% 13.75±4% 13.80±4% 13.85±4%...
  • Page 26 GCL- Module type NT10R/54GDF465 GCL- Module type NT10R/54BGDF465 Pmp [W] /Tolerance 465±3% Voc [V] /Tolerance 40.75±3% Isc [Adc] /Tolerance 14.10±4% condition Vmp [V] 34.21 Imax [Adc] 13.60 Pmp [W] /Tolerance 510±3% BNPI Voc [V] /Tolerance 40.85±3% condition Isc [Adc] /Tolerance 15.40±4%...
  • Page 27 GCL- GCL- GCL- GCL- Module type NT12/66GDF680 NT12/66GDF685 NT12/66GDF690 NT12/66GDF695 Pmp [W] /Tolerance 680±3% 685±3% 690±3% 695±3% Voc [V] /Tolerance 46.98±3% 47.17±3% 47.36±3% 47.55±3% Isc [Adc] /Tolerance 18.24±4% 18.27±4% 18.31±4% 18.35±4% condition 39.45 39.65 39.86 Vmp [V] 39.26 17.40 17.44 Imax [Adc] 17.33...
  • Page 28 GCL- GCL- GCL- GCL- Module type NT12/60GDF600 NT12/60GDF605 NT12/60GDF610 NT12/60GDF615 Pmp [W] /Tolerance 600±3% 605±3% 610±3% 615±3% Voc [V] /Tolerance 42.06±3% 42.25±3% 42.45±3% 42.65±3% Isc [Adc] /Tolerance 18.08±4% 18.12±4% 18.17±4% 18.21±4% condition 35.15 35.35 35.55 Vmp [V] 34.95 17.26 17.30 Imax [Adc] 17.17...
  • Page 29 GCL- GCL- Module type NT12/60GDF640 NT12/60GDF645 Pmp [W] /Tolerance 640±3% 645±3% Voc [V] /Tolerance 43.62±3% 43.81±3% Isc [Adc] /Tolerance 18.42±4% 18.46±4% condition 36.75 Vmp [V] 36.55 Imax [Adc] 17.51 17.55 Pmp [W] /Tolerance 705±3% 710±3% BNPI Voc [V] /Tolerance 43.90±3% 44.10±3%...
  • Page 30 Company name: GCL System Integration Technology Co., Ltd. Address: Jianghai Economic Zone, Nanqiao Town, Fengxian District, 201406 Shanghai P. R. China E-mail: gclsiinfo@gclsi.com Tel: +86-512-6983 2860 (customer-service hotline)
