Owner's Manual
2022
2022
CBR300R/RA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CBR300R 2022 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Honda CBR300R 2022

Summary of Contents for Honda CBR300R 2022

  • Page 1 Owner’s Manual 2022 2022 CBR300R/RA...
  • Page 2 This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
  • Page 3 Welcome Congratulations on your purchase of a new When service is required, remember that Honda vehicle. Your selection of a Honda your Honda dealer knows your vehicle best. makes you part of a worldwide family of If you have the required mechanical “know- satisfied customers who appreciate Honda's how”...
  • Page 4 A Few Words About Safety DANGER Your safety, and the safety of others, is very important. Operating this vehicle safely is an You WILL be KILLED or SERIOUSLY important responsibility. HURT if you don’t follow instructions. To help you make informed decisions about safety, we have provided operating WARNING procedures and other information on safety...

  • Page 5: Table Of Contents

    Contents Vehicle Safety P. 2 Operation Guide P. 18 Maintenance P. 33 Troubleshooting P. 72 Information P. 85 Specifications P. 110...

  • Page 6: Vehicle Safety

    Vehicle Safety This section contains important information for safe riding of your vehicle. Please read this section carefully. Safety Guidelines ..........P. 3 Safety Labels............P. 8 Safety Precautions..........P. 10 Riding Precautions ..........P. 11 Accessories & Modifications......P. 15 Loading ..............

  • Page 7: Safety Guidelines

    Safety Guidelines Safety Guidelines Before Riding Make sure that you are physically fit, mentally Follow these guidelines to enhance your safety: focused, and free of alcohol and drugs. Check Perform all routine and regular inspections ● that you and your passenger are both wearing specified in this manual.
  • Page 8 Safety Guidelines Take Time to Learn & Practice Ride Defensively Even if you have ridden other vehicles, practice Always pay attention to other vehicles around riding in a safe area to become familiar with you, and do not assume that other drivers see how this vehicle works and handles, and to you.
  • Page 9 Safety Guidelines Make Yourself Easy to See Don't Drink or Use Drugs and Ride Make yourself more visible, especially at night, Alcohol or drugs and riding don't mix. Even one by wearing bright reflective clothing, positioning alcoholic drink can reduce your ability to yourself so other drivers can see you, signaling respond to changing conditions, and your before turning or changing lanes, and using...
  • Page 10 Safety Guidelines Keep Your Honda in Safe Condition If You are Involved in a Crash It's important to keep your vehicle properly Personal safety is your first priority. If you or maintained and in safe riding condition. anyone else has been injured, take time to...
  • Page 11 Safety Guidelines WARNING Carbon Monoxide Hazard Exhaust contains poisonous carbon monoxide, a Running the engine of your vehicle colorless, odorless gas. Breathing carbon while in an enclosed or even partially monoxide can cause loss of consciousness and enclosed area can cause a rapid build- may lead to death.

  • Page 12: Safety Labels

    Safety Labels Safety Labels serious injury. Read these labels carefully and don't remove them. Safety and information labels on your vehicle If a label comes off or becomes hard to read, provide important safety information and may contact your dealer for a replacement. warn you of potential hazards that could cause...
  • Page 13 Safety Labels...

  • Page 14: Safety Precautions

    Safety Precautions Safety Precautions Helmet Should be safety-standard certified, high- Ride cautiously and keep your hands on the visibility, and the correct size for your head. ● handlebars and feet on the footpegs. Must fit comfortably but securely, with the ●...

  • Page 15: Riding Precautions

    Riding Precautions Riding Precautions Gloves Full-finger leather gloves with high abrasion resistance Break-in Period Boots or Riding Shoes During the first 300 miles (500 km) of running, follow these guidelines to ensure your vehicle's Sturdy boots with non-slip soles and ankle future reliability and performance.
  • Page 16 Riding Precautions Anti-lock Brake System (ABS) Brakes CBR300RA Observe the following guidelines: This model is equipped with an Anti-lock Brake Avoid excessively hard braking and ● System (ABS) designed to help prevent the downshifting. brakes from locking up during hard braking. Sudden braking can reduce the vehicle's ABS does not reduce braking distance.
  • Page 17 Riding Precautions Engine Braking Parking Engine braking helps slow your vehicle down Park on a firm, level surface. ● when you release the throttle. For further If you must park on a slight incline or loose ● slowing action, downshift to a lower gear. Use surface, park so that the vehicle cannot engine braking with intermittent use of the move or fall over.
  • Page 18 Riding Precautions Parking with the Side Stand Refueling and Fuel Guidelines Stop the engine. Follow these guidelines to protect the engine, Push the side stand down. fuel system and catalytic converter: Slowly lean the vehicle to the left until its Use only unleaded gasoline.

  • Page 19: Accessories & Modifications

    We strongly advise that you do not add any seriously hurt or killed. accessories that were not specifically designed or approved for your vehicle by Honda or make Follow all instructions in this owner's modifications to your vehicle from its original manual regarding accessories and design.

  • Page 20: Loading

    Loading Loading WARNING Overloading or improper loading can Carrying extra weight affects your vehicle's ● cause a crash and you can be seriously handling, braking and stability. hurt or killed. Always ride at a safe speed for the load you are carrying.
  • Page 21 This page intentionally left blank.

  • Page 22: Operation Guide

    Parts Location Battery (P.54) Main fuse (P.83) Fuse box (P.82) ABS fuse CBR300RA (P.84) Front brake fluid reservoir (P.62) Throttle grip (P.70) Engine oil fill cap (P.58) Engine oil level inspection window (P.58) Coolant reserve tank (P.60) Rear brake fluid reservoir (P.62)
  • Page 23 Clutch lever (P.67) Fuel fill cap (P.31) Front seat (P.56) Helmet holder (P.32) Rear seat (P.57) Document bag (P.32) Tool kit (P.32) Rear suspension spring preload adjuster (P.71) Drive chain (P.66) Shift lever (P.30) Side stand (P.65)
  • Page 24 Instruments Tachometer NOTICE Do not operate the engine in the tachometer red zone. Excessive engine speed can adversely affect engine life. Tachometer red zone (excessive engine rpm range) button button MODE RESET Changing the Speed and Mileage Unit Press and hold button to change the speed and mileage units (“mph”...
  • Page 25 Speedometer Coolant temperature gauge ( When the coolant is over specified temperature, the segment H flashes. If it comes on while riding: (P.74) Fuel gauge Remaining fuel when only 1st (E) segment starts flashing: approximately 0.82 US gal (3.1 L) If the fuel gauge indicator flashes in a repeat pattern or turns off: (P.76)
  • Page 26 Instruments (Continued) Clock (12-hour display) Odometer [TOTAL] & Tripmeter [TRIP] button switches between MODE odometer and tripmeter. • Odometer: Total distance ridden. • Tripmeter: Distance ridden since tripmeter was reset (press and hold button to reset to RESET 0.0 mile/km). button button MODE...
  • Page 27 To set the clock: Press button until the desired minute RESET is displayed. Turn the ignition switch to the ON position. Press and hold button to Press and hold buttons RESET MODE RESET advance the minute fast. until the hour digits start flashing. Press button.
  • Page 28 Indicators If one of these indicators does not come on when it should, have your dealer check for problems. PGM-FI (Programmed Fuel Injection) malfunction indicator lamp (MIL) Comes on briefly when the ignition switch is turned to the ON position with the engine stop switch in the (Run) position.
  • Page 29 Left turn signal indicator Neutral indicator Comes on when the transmission is in Neutral. Right turn signal indicator High beam indicator...
  • Page 30 Switches Engine stop switch Should normally remain in the (Run) position. In an emergency, switch to the (Stop) position (the starter motor will not operate) to stop the engine. Start button Horn button Turn signal switch Pressing the switch turns the turn signal off.
  • Page 31 Ignition Switch Switches the electrical system on/off, locks the steering. Key can be removed when in the OFF or LOCK position. Turns electrical system on for starting/riding. Turns engine off. LOCK Locks steering. Continued...
  • Page 32 Switches (Continued) Steering Lock Locking Turn the handlebars all the way to the left. Lock the steering when parking to help Push the key down, and turn the ignition prevent theft. switch to the LOCK position. A U-shaped wheel lock or similar device is Jiggle the handlebars if the lock is also recommended.
  • Page 33 Starting the Engine Start your engine using the following Make sure the engine stop switch is in the procedure, regardless of whether the engine (Run) position. is cold or warm. Turn the ignition switch to the ON position. Shift the transmission to Neutral ( indicator comes on).
  • Page 34 Shifting Gears Your vehicle transmission has 6 forward Recommended Shift Points gears in a one-down, five-up shift pattern. Shifting Up 2 3 4 5 From 1st to 2nd 12 mph (20 km/h) From 2nd to 3rd 19 mph (30 km/h) From 3rd to 4th 25 mph (40 km/h) From 4th to 5th...
  • Page 35 Refueling Fuel fill cap Closing the Fuel Fill Cap Filler neck plate Ignition key After refueling, align the fuel fill cap latch with the slot in the filler neck. Push the fuel fill cap into the filler neck until it snaps closed and locks.
  • Page 36 Storage Equipment The helmet holder, helmet set wire (in the Document bag tool kit), tool kit, storage compartment, and document bag are located under the rear seat. Helmet set wire Helmet holder Tool kit WARNING Riding with a helmet attached to the holder can interfere with the rear wheel or suspension and could cause a crash in which you can be seriously hurt or...

  • Page 37: Maintenance

    Please read “Importance of Maintenance” and “Maintenance Fundamentals” carefully before attempting any maintenance. Refer to “Specifications” for service data. An optional larger tool kit may be available. Check with your Honda dealer's parts department. Importance of Maintenance ......P. 34 Clutch ..............P. 67 Maintenance Schedule........

  • Page 38: Importance Of Maintenance

    Importance of Maintenance WARNING Importance of Maintenance Keeping your vehicle well-maintained is Improperly maintaining your vehicle or absolutely essential to your safety and to failing to correct a problem before you protect your investment, obtain maximum ride can cause a crash in which you can performance, avoid breakdowns, and reduce air be seriously hurt or killed.
  • Page 39 Importance of Maintenance For information about the exhaust emission and Maintenance Safety noise emission requirements of the U.S. Always read the maintenance instructions Environmental Protection Agency (EPA), and the before you begin each task and make sure that California Air Resources Board (CARB). P.

  • Page 40: Maintenance Schedule

    Maintenance work should be performed in owner. accordance with Honda's standards and specifications by properly trained and equipped technicians. Your dealer meets all of these requirements. All scheduled maintenance is considered a normal owner operating cost and will be charged to you by your dealer.
  • Page 41 Clean mechanically skilled. Lubricate Procedures are provided in an official Honda Service Replace Manual (2 P. 103). : Technical. In the interest of safety, have your vehicle serviced by your dealer.
  • Page 42 Maintenance Schedule Frequency Items × 1,000 mi Refer to page × 1,000 km 12.8 19.2 25.6 32.0 38.4 Drive Chain Every 500 mi (800 km): Brake Fluid Brake Pads Wear Brake System Brake Light Switch Headlight Aim – Clutch System Side Stand Suspension Nuts, Bolts, Fasteners...

  • Page 43: Maintenance Record

    Maintenance Record Distance Odometer Date Performed By: Notes 600 miles (1,000 km) 4,000 miles (6,400 km) 8,000 miles (12,800 km) 12,000 miles (19,200 km) 16,000 miles (25,600 km) 20,000 miles (32,000 km) 24,000 miles (38,400 km) 28,000 miles (44,800 km) 32,000 miles (51,200 km) 36,000 miles (57,600 km) 40,000 miles (64,000 km)

  • Page 44: Maintenance Fundamentals

    Maintenance Fundamentals Check the following items after you get on your Pre-ride Inspection vehicle: To ensure safety, it is your responsibility to Throttle action moves smoothly without ● perform a pre-ride inspection and make sure binding P. 70 that any problem you find is corrected. A pre- Brake lever and pedal operate normally ●...
  • Page 45 Maintenance Fundamentals Also, check the odometer reading against the Periodic Checks Maintenance Schedule and perform all You should also perform other periodic maintenance that is due. P. 36 maintenance checks at least once a month regardless of how often you ride, or more often if you ride frequently.
  • Page 46 Maintenance Fundamentals WARNING Replacing Parts Always use Honda Genuine Parts or their Installing non-Honda parts may make equivalents to ensure reliability and safety. your vehicle unsafe and cause a crash in When ordering colored components, specify which you can be seriously hurt or the model name, color, and code mentioned on killed.
  • Page 47 Maintenance Fundamentals Electrolyte splashes into your mouth: Battery ● Rinse mouth thoroughly with water, and Your vehicle has a maintenance-free type battery. do not swallow. You do not have to check the battery electrolyte level or add distilled water. Clean the battery WARNING terminals if they become dirty or corroded.
  • Page 48 30 days using a charger designed specifically for If the terminals are heavily corroded, clean your Honda, which can be purchased from your and polish the terminals with a wire brush or dealer. Read the information that came with sandpaper.
  • Page 49 Bump starting is also not recommended. NOTICE Installing non-Honda electrical accessories can NOTICE Replacing a fuse with one that has a higher overload the electrical system, discharging the rating greatly increases the chance of damage to battery and possibly damaging the system.
  • Page 50 “Specifications.” P. 111 oils, excluding oils marked as “Energy Conserving” or “Resource Conserving” on the circular API If you use non-Honda engine oil, check the service symbol. label to make sure that the oil satisfies all of the following standards:...
  • Page 51 Wipe up spills immediately and wash thoroughly. chain inspected by your dealer. Recommended brake fluid: Also inspect the drive sprocket and driven Honda DOT 4 Brake Fluid or equivalent sprocket. If either has worn or damaged teeth, have the sprocket replaced by your dealer. Normal...
  • Page 52 O-ring chains as these can damage the Recommended lubricant: rubber O-ring seals. Pro Honda HP Chain Lube or equivalent Avoid getting lubricant on the brakes or tires. Avoid applying excess chain lubricant to prevent spray onto your clothes and the vehicle.
  • Page 53 Maintenance Fundamentals Recommended Coolant Crankcase Breather Pro Honda HP Coolant is a pre-mixed solution Service more frequently when riding in rain, at of antifreeze and distilled water. full throttle, or after the vehicle is washed or overturned. Service if the deposit level can be...
  • Page 54 Maintenance Fundamentals Inspecting for Damage Tires (Inspecting/Replacing) Checking the Air Pressure Inspect the tires for Visually inspect your tires and use an air cuts, slits, or cracks that pressure gauge to measure the air pressure at expose fabric or cords, least once a month or any time you think the or nails or other tires look low.
  • Page 55 Maintenance Fundamentals WARNING Inspecting Tread Depth Inspect the tread wear indicators. If they Riding on tires that are excessively worn become visible, replace the tires immediately. or improperly inflated can cause a crash For safe riding, you should replace the tires in which you can be seriously hurt or when the minimum tread depth is reached.
  • Page 56 Always use the size and type of tires speed rating, and load range. recommended in this owner's manual. Have the wheel balanced with Honda ● Genuine balance weights or equivalent after the tire is installed.
  • Page 57 Maintenance Fundamentals Tire Identification Number (TIN) Tire Service Life The tire identification number (TIN) is a group The service life of your tires is dependent on of numbers and letters located on the sidewall many factors, including, but not limited to, of the tire.

  • Page 58: Removing & Installing Body Components

    Removing & Installing Body Components Battery Remove the battery holder by removing the bolt. Disconnect the negative - terminal from Negative Bolt Positive terminal terminal the battery. Disconnect the positive + terminal from the battery. Remove the battery, taking care not to drop the terminal nuts.

  • Page 59: Clip

    Removing & Installing Body Components Clip Clip Installation Removal Center pin Push the bottom of the center pin. Insert the clip into the hole. Press down on the center pin to lock the Press down on the center pin to release clip.

  • Page 60: Front Seat

    Removing & Installing Body Components Front Seat Front Seat Removal Remove the rear seat. P. 57 Front seat Mounting bolts Remove the mounting bolts, and then pull the front seat back and up. Installation Insert the tab into the recess. Install and tighten the mounting bolts securely.

  • Page 61: Rear Seat

    Removing & Installing Body Components Rear Seat Rear Seat Removal Insert the ignition key into the seat lock. Turn it clockwise, then pull the rear seat Prongs Rear seat up and back. Installation Insert the prongs into the rear stays on the frame.

  • Page 62: Engine Oil

    Engine Oil Checking the Engine Oil Oil fill cap If the engine is cold, idle the engine for 3 Oil level inspection to 5 minutes. window Upper level Turn the ignition switch to the OFF position and wait for 2 to 3 minutes. Place your vehicle in an upright position on a firm, level surface.
  • Page 63 Engine Oil Adding Engine Oil Adding Engine Oil NOTICE Overfilling with oil or operating with insufficient oil can cause damage to your engine. Do not mix If the engine oil is below or near the lower different brands and grades of oil. They may level mark, add the recommended engine oil.

  • Page 64: Coolant

    Coolant Checking the Coolant If the coolant level is dropping noticeably or the reserve tank is empty, you likely have a serious leak. Have your vehicle inspected by Check the coolant level in the reserve tank your dealer. while the engine is cold. Place your vehicle on a firm, level surface.
  • Page 65 Coolant Adding Coolant Remove the screw. Reserve tank cover Pull out the prong from the hole and remove the reserve tank cover. Screw Reserve tank cap Remove the reserve tank cap and add fluid while monitoring the coolant level. Do not overfill above the UPPER level mark.

  • Page 66: Brakes

    Brakes Checking Brake Fluid If the brake fluid level in either reservoir is below the LWR mark or LOWER level mark or the brake lever and pedal freeplay becomes Place your vehicle in an upright position excessive, inspect the brake pads for wear. on a firm, level surface.
  • Page 67 Brakes Inspecting the Brake Pads Inspecting the Brake Pads Front CBR300R Check the condition of the brake pad wear Wear Wear indicators. indicator indicator The pads need to be replaced if a brake pad is worn to the indicator. Brake pads Disc CBR300RA Inspect the brake pads from below...
  • Page 68 Brakes Adjusting the Brake Light Switch Adjusting the Brake Light Brake light switch Switch Check the operation of the brake light switch. Hold the brake light switch and turn the adjusting nut in the direction A if the switch operates too late, or turn the nut in the direction B if the switch operates too soon.

  • Page 69: Side Stand

    Side Stand Checking the Side Stand Sit on the vehicle, shift the transmission to Neutral, and raise the side stand. Start the engine, pull the clutch lever in, and shift the transmission into gear. Lower the side stand all the way. The engine should stop as you lower the side stand.

  • Page 70: Drive Chain

    Drive Chain Inspecting the Drive Chain Slack Drive Chain Check the drive chain slack at several points along the chain. If the slack is not constant at all points, some links may be kinked and binding. Have the chain inspected by your dealer. Shift the transmission to Neutral.

  • Page 71: Clutch

    Clutch Checking the Clutch Check the clutch cable for kinks or signs of wear. If necessary, have it replaced by your Checking the Clutch Lever Freeplay dealer. Lubricate the clutch cable with a Check the clutch lever freeplay. commercially available cable lubricant to Freeplay at the clutch lever: prevent premature wear and corrosion.
  • Page 72 Clutch Adjusting the Clutch Lever Freeplay Adjusting the Clutch Lever Upper clutch cable adjuster Upper lock nut Freeplay Upper Adjustment – Attempt adjustment with the upper clutch cable adjuster first. Pull back the rubber dust cover. Loosen the upper lock nut. Turn the upper clutch cable adjuster until Rubber dust cover the freeplay is 3/8 - 13/16 in (10 - 20 mm).
  • Page 73 Clutch Adjusting the Clutch Lever Freeplay Loosen the upper lock nut and turn the Lower lock nut upper clutch cable adjuster all the way in to provide maximum freeplay. Tighten the upper lock nut. Loosen the lower lock nut. – Turn the lower adjusting nut until the clutch lever freeplay is 3/8 - 13/16 in (10 - 20 mm).

  • Page 74: Throttle

    Throttle Checking the Throttle Adjusting the Throttle Freeplay With the engine off, check that the throttle Slide the cable boot. rotates smoothly from fully closed to fully Loosen the lock nut. open in all steering positions and throttle Turn the adjuster until the freeplay is 1/16 freeplay is correct.

  • Page 75: Other Adjustments

    Other Adjustments Adjusting the Rear Suspension Extension bar 1 2 3 4 Adjusting the suspension requires a pin spanner. We recommend that you have your vehicle serviced by your dealer. Spring Preload You can adjust the spring preload by the adjuster to suit the load or the road surface.

  • Page 76: Troubleshooting

    Troubleshooting Engine Will Not Start........P. 73 Burned-out Light Bulb........P. 78 Overheating (Segment H flashes in coolant Blown Fuse ............P. 82 temperature gauge) ........P. 74 Warning Indicators On or Flashing....P. 75 PGM-FI (Programmed Fuel Injection) Malfunction Indicator Lamp (MIL)....P. 75 ABS (Anti-lock Brake System) Indicator ..

  • Page 77: Engine Will Not Start

    Engine Will Not Start Starter Motor Operates But Starter Motor Does Not Engine Does Not Start Operate Check the following items: Check the following items: Check the correct engine starting Check the correct engine starting ● ● sequence. P. 29 sequence.

  • Page 78: Overheating

    Overheating (Segment H flashes in coolant temperature gauge) The engine is overheating when the following Check that the radiator fan is operating, occurs: and then turn the ignition switch to the The segment H flashes in the coolant OFF position. ●...

  • Page 79: Warning Indicators On Or Flashing

    Warning Indicators On or Flashing PGM-FI (Programmed Fuel Indicator does not come on when the ● ignition switch is in the ON position. Injection) Malfunction Indicator does not go off at speeds above ● Indicator Lamp (MIL) 6 mph (10 km/h). If the indicator comes on while riding, you If the ABS indicator stays on, your brakes will may have a serious problem with the PGM-FI...

  • Page 80: Other Warning Indications

    Other Warning Indications Fuel Gauge Failure Indication Coolant Temperature Gauge Failure Indication If the fuel system has an error, all segments will blink or go off as shown in the illustration. If the cooling system has an error, all If this occurs, see your dealer as soon as segments will blink or go off as shown in the possible.

  • Page 81: Tire Puncture

    Tire Puncture WARNING Repairing a puncture or removing a wheel requires special tools and technical expertise. Riding your vehicle with a temporary We recommend you have this type of service tire repair can be risky. If the temporary performed by your dealer. repair fails, you can crash and be After an emergency repair, always have the seriously injured or killed.

  • Page 82: Electrical Trouble

    Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle Follow the procedure below to replace a battery charger. burned-out light bulb. Remove the battery from the vehicle before Turn the ignition switch to the OFF or LOCK charging.
  • Page 83 Electrical Trouble Burned-out Light Bulb Headlight Bulb The right and left headlight bulbs replacement can be done in the same way. Pull off the connector while pushing the knob. Remove the dust cover. Press the pin down and pull out the bulb assembly without turning it.
  • Page 84 Electrical Trouble Burned-out Light Bulb Brake Light/Taillight Bulb Front/Rear Turn Signal Bulb Remove the screw A and screw B. Remove the turn signal lens and lens Bulb packing. Slightly press the bulb and turn it counterclockwise. Lens packing Screw A Screw B Socket Remove the rear seat.
  • Page 85 Electrical Trouble Burned-out Light Bulb License Plate Light Bulb Remove the screws. Remove the license light cover and license light cover packing. Pull out the bulb without turning. Bulb Cover packing License light cover Screws Install a new bulb in the reverse order of removal.
  • Page 86 Electrical Trouble Blown Fuse Blown Fuse CBR300RA CBR300R Spare fuses Spare fuses Before handling fuses, see “Inspecting and Replacing Fuses.” P. 45 Fuse Box Fuses Remove the front seat. P. 56 Open the fuse box cover. Pull out the fuses one by one to check for a blown fuse.
  • Page 87 Electrical Trouble Blown Fuse Main Fuse Pull the main fuse out and check for a blown fuse. Always replace a blown fuse Wire connector with a spare of the same rating. The spare main fuse is provided in the starter magnetic switch. Reinstall parts in the reverse order of Main fuse removal.
  • Page 88 Electrical Trouble Blown Fuse ABS Fuse Remove the front seat. P. 56 Open the ABS fuse box cover. CBR300RA Pull the fuse out and check for a blown fuse. Always replace a blown fuse with a Spare fuse spare of the same rating. Close the ABS fuse box cover.

  • Page 89: Information

    Vehicle Identification Number....... P. 95 Emission Control Systems ....... P. 96 Catalytic Converter ......... P. 101 Oxygenated Fuels..........P. 102 Authorized Manuals ........P. 103 Warranty Coverage and Service ....P. 104 Honda Contacts ..........P. 107 Reporting Safety Defects ......P. 109...

  • Page 90: Keys

    Keys Keys Ignition Key Be sure to record the key number provided with the key number plate. Store the spare key and key number in a safe location. To make a duplicate, take the spare key or the key number to your dealer. If you lose all ignition keys and the key number, the ignition switch assembly will probably have to be removed by your dealer to determine the...

  • Page 91: Instruments, Controls, & Other Features

    Instruments, Controls, & Other Features Instruments, Controls, & Tripmeter Other Features The tripmeter resets to 0.0 when the trip mileage exceeds 999.9. Ignition Switch Leaving the ignition switch in the ON position Document Bag with the engine stopped will drain the battery. The owner’s manual, registration, and insurance Do not turn the key while riding.

  • Page 92: Caring For Your Vehicle

    Frequent cleaning and polishing is important to After the vehicle dries, lubricate any moving ensure the life of your Honda. A clean vehicle parts. makes it easier to spot potential problems.
  • Page 93 Caring for Your Vehicle Washing Precautions Do not direct water at the air cleaner: ● Water in the air cleaner can prevent the Follow these guidelines when washing: engine from starting. Do not use high-pressure washers: ● Do not direct water near the headlight: High-pressure water cleaners can ●...
  • Page 94 Caring for Your Vehicle Aluminum Components Windscreen Aluminum will corrode from contact with dirt, Using plenty of water, clean the windscreen with mud, or road salt. Clean aluminum parts a soft cloth or sponge. (Avoid using detergents regularly and follow these guidelines to avoid or any kind of chemical cleaner on the scratches: windscreen.) Dry with a soft, clean cloth.
  • Page 95 Caring for Your Vehicle Take care to keep battery electrolyte, brake If the exhaust pipe and muffler are painted, do fluid, or other chemical solvents off the not use a commercially available abrasive windscreen and screen garnish. They will kitchen cleaning compound. Use a neutral damage the plastic.

  • Page 96: Storing Your Vehicle

    If you won't be riding for an extended period, For more information about storage, refer to follow these guidelines: the Honda Winter Storage Guide, available from Wash your vehicle and wax all painted your dealer. ●...

  • Page 97: Transporting Your Vehicle

    Transporting Your Vehicle Transporting Your Vehicle If your vehicle needs to be transported, it should be carried on a motorcycle trailer or a flatbed truck or trailer that has a loading ramp or lifting platform and motorcycle tie-down straps. Never try to tow your vehicle with a wheel or wheels on the ground.

  • Page 98: You & The Environment

    You & the Environment You & the Environment Recycle Wastes Put oil and other toxic wastes in approved Owning and riding a vehicle can be enjoyable, containers and take them to a recycling center. but you must do your part to protect the Call your local or state office of public works or environment.

  • Page 99: Vehicle Identification Number

    Vehicle Identification Number Vehicle Identification Number The VIN and engine serial number uniquely identify your vehicle and are required in order to register your vehicle. They may also be required when ordering replacement parts. You should record these numbers and keep them in a safe place.

  • Page 100: Emission Control Systems

    Emission Control Systems Emission Control Systems Your vehicle engine emits combustion byproducts, including carbon monoxide (CO), oxides of nitrogen (NOx), and hydrocarbons (HC). Gasoline evaporation also emits hydrocarbons. Controlling the production of NOx, CO, and HC is important for the environment.
  • Page 101 Vehicle emission control information label instructions provided. Compliance with the terms of the Distributor's Warranties for Honda Motorcycle Emission Noise Emission Requirements Control Systems is necessary in order to The EPA requires that vehicles built after maintain a valid emissions system warranty.
  • Page 102 Emission Control Systems Secondary Air Injection System Exhaust Emission Control System The secondary air injection system adds filtered The exhaust emission control system includes air into the exhaust gas to help improve the following components that should not need emission control performance. adjustment, although periodic inspection by your dealer is recommended.
  • Page 103 Emission Control Systems Crankcase Emissions Control System Noise Emission Control System The engine is equipped with a closed crankcase TAMPERING WITH THE NOISE CONTROL system to prevent discharging crankcase SYSTEM IS PROHIBITED: emissions into the atmosphere. U. S. federal law prohibits the following acts or Blow-by gas is returned to the combustion the causing thereof: (1) The removal or chamber through the air cleaner housing and...
  • Page 104 Emission Control Systems AMONG THOSE ACTS PRESUMED TO Problems Affecting Vehicle Exhaust CONSTITUTE TAMPERING ARE THE Emissions FOLLOWING ACTS: Have your vehicle inspected and repaired by Removal of, or puncturing the muffler, ● your dealer if you experience any of the baffles, header pipes or any other following symptoms: component which conducts exhaust gases.

  • Page 105: Catalytic Converter

    A defective catalytic converter contributes to air riding and turn off the engine. Have your pollution and can impair your engine's vehicle serviced as soon as possible. performance. A replacement unit must be an original Honda part or equivalent.

  • Page 106: Oxygenated Fuels

    Oxygenated Fuels Oxygenated Fuels If you accidentally fill your fuel tank with an oxygenated fuel containing higher percentages, Some conventional fuels blended with alcohol you may experience performance problems. To or an ether compound are available in some resolve the problem, have your dealer drain the locales to help reduce emissions to meet clean fuel tank and replace with the correct fuel.

  • Page 107: Authorized Manuals

    However, if you possess The Service Manual used by your authorized the proper tools, observe the safety standards, dealer is available from your Honda dealer or and are mechanically capable, you should find Helm, Inc. them easy to use.

  • Page 108: Warranty Coverage And Service

    Service Your warranty coverage is not voided if you Coverage perform your own maintenance. However, Your new Honda is covered by the following failures that occur due directly to improper warranties: maintenance are not covered by these Vehicle Limited Warranty ●...
  • Page 109 Warranty Coverage and Service authorized service provider caused damage to Statement on Warranty Coverage for another part of the vehicle otherwise covered Aftermarket and Recycled Parts under warranty before denying warranty The Magnuson-Moss Warranty Act, 15 U.S.C. s. coverage. Additionally, federal law allows a 2301 et seq., makes it illegal for motor vehicle manufacturer to void a motor vehicle warranty manufacturers to void a motor vehicle warranty...
  • Page 110 If you believe you have a problem with your dealership or their designated representative. vehicle, call the service department of your Honda dealer. Make an appointment for an inspection and diagnosis. You will be asked to authorize that inspection, and your dealer will return the results of the inspection.

  • Page 111: Honda Contacts

    Dealer name and address ● or with your dealer, please send your comments using one of the following methods: We will likely ask your Honda dealer to respond, or possibly acknowledge your comments directly. Powersports Customer Relations American Honda Motor Co., Inc.
  • Page 112 Honda Contacts Your Honda Dealer The service department of your Honda dealer offers trained personnel to perform regular maintenance and unexpected repairs. It has the latest available service information from Honda and also handles warranty inspections and repairs. The parts department offers Honda Genuine...

  • Page 113: Reporting Safety Defects

    Highway Traffic Safety Administration Administrator, NHTSA, (NHTSA) in addition to notifying 1200 New Jersey Avenue, SE., American Honda Motor Co., Inc. Washington, DC 20590. You can also obtain other information If NHTSA receives similar complaints, it about motor vehicle safety from: may open an investigation, and if it finds https://www.safercar.gov.

  • Page 114: Specifications

    Specifications Main Components ■ Displacement 17.4 cu-in (286 cm Overall length 80.1 in (2,035 mm) Bore x stroke 2.99 x 2.48 in (76.0 x 63.0 mm) Overall width 28.3 in (720 mm) Compression 10.7:1 ratio Overall height 44.1 in (1,120 mm) Unleaded gasoline Wheelbase 54.3 in (1,380 mm)
  • Page 115 SAE 10W-30, JASO T 903 Tire type Bias-ply, tubeless engine oil standard MA, Pro Honda GN4 4-stroke oil Front IRC RX-01FD Recommended (USA & Canada) or Honda 4-stroke oil, or tire Rear IRC RX-01RZ an equivalent motorcycle oil Front Up to After 1.5 US qt (1.4 L)
  • Page 116 Specifications RK 520KLO or DID 520VF Standard drive chain No. of links 108 Drive sprocket Standard sprocket size Driven sprocket Bulbs ■ Headlight 12 V-55 W x 2 Brake Light/Taillight 12 V-21/5 W Front turn signal 12 V-21 W x 2 Rear turn signal 12 V-21 W x 2 License plate light...
  • Page 117 Information Record Engine No. Color Label & Code Owner's Name Address City/State Phone Dealer's Name Address City/State Phone Service Manager...
  • Page 118 California Proposition 65 Warning WARNING: Operating, servicing and maintaining a passenger vehicle or off-highway motor vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm.
  • Page 119 31K75A60 00X31-K75-A600 PRINTED IN USA...
