ORIGINAL INSTRUCTIONS
OPERATION MANUAL
#005-965
#005-965
READ THIS MANUAL ENTIRELY
BEFORE CONNECTING TO POWER.
Damage not covered by the warranty may result from not
following the instructions and maintenance in this manual.
NOTICE
This engraving system requires clean, dry, oil-free air. An oil-free compressor is
recommended for use with this system. For any oil-type compressors, an oil-removal fi lter
(coalescing type) in the air supply line to this engraving system MUST BE INSTALLED AND
IN USE.
For help with ordering or installing an oil-removal fi lter, or for guidance with operation or
maintenance, please contact GRS
To send a request for assistance via electronic formats, e-mail support@glendo.com or
visit:
Important notes are highlighted in yellow or
OIL OR WATER CONTAMINATION
IS NOT COVERED BY WARRANTY.
or an authorized GRS
®
grs .com/contact‑us/
dealer.
®
marked in red.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GRS GRAVERMACH AT
Summary of Contents for GRS GRAVERMACH AT
- Page 1 (coalescing type) in the air supply line to this engraving system MUST BE INSTALLED AND IN USE. OIL OR WATER CONTAMINATION IS NOT COVERED BY WARRANTY. For help with ordering or installing an oil-removal fi lter, or for guidance with operation or maintenance, please contact GRS or an authorized GRS dealer. ® ®...
-
Page 2: Table Of Contents
GraverMach AT Overview . . . . . . . . . . . . . . . . . . . -
Page 3: Important Notice For Operators
FOR PROPER OPERATION, THIS SYSTEM REQUIRES: • Included 24-volt power converter connected to a properly grounded electrical power outlet • Clean, dry, oil-free air provided by an air compressor • A compatible GRS pneumatic handpiece ® • A graver or similar tool •... -
Page 4: Required Equipment & Important Notes
The power converter must be used with a suitable grounded electrical system. Using it with an ungrounded system could expose the equipment to electrical damage. Do not use older generation power converters. If a replacement is needed, contact GRS or an authorized GRS dealer to order #022-987. - Page 5 Clean, dry, oil‑free air from an air compressor • Oil-free compressors are ALWAYS RECOMMENDED. When using an oil-lubricated compressor, install an oil-removal fi lter (coalescing type – GRS #004-730-6MM or ® equivalent) in the air supply line to this engraving system. Damage due to oil or water contamination IS NOT COVERED BY WARRANTY.
-
Page 6: Gravermach At Overview
GraverMach AT Overview ® Front View x100 G R A V E R M A C H G R A V E R M A C H ® ® 40 PSI (2.7 BAR) FOOT THROTTLE CONNECTION Back View G R A V E R M A C H ®... -
Page 7: Introduction, Operation Note
G R A V E R M A C H Overview ® A. Air pressure gauge Auxiliary tool push-to-connect fitting B. Power on/off button Airtact Handpiece twist-lock fittings ® C. Speed dial K. Air input push-to-connect fitting D. Air pressure control knob Air filter Auxiliary air on/off knob M. -
Page 8: Setup & Connections
SETUP & CONNECTIONS Hose and Cord Connections Overview x100 G R A V E R M A C H ® To Air Supply A. Auxiliary tool fitting B. Standard Handpiece fittings C. Airtact Handpiece fittings ® D. Air compressor input E. - Page 9 SETUP & CONNECTIONS (CONTINUED) Connect Electrical Power DO NOT OPERATE ENGRAVING SYSTEM WITHOUT AN ACTIVE AIR SUPPLY CONNECTED. x100 G R A V E R M A C H ® Connect Airtact Handpiece(s) ® x100 G R A V E R M A C H ®...
- Page 10 x100 SETUP & CONNECTIONS (CONTINUED) G R A V E R M A C H ® Connect Standard Handpiece(s) x100 G R A V E R M A C H ® G R A V E R M A C Connect Auxiliary Air Tool x100 G R A V E R M A C H...
- Page 11 Keep hands away from foot pedal completely on the foot pedal. during use to avoid pinching hazard. SPECIAL NOTE: When powered on, Power on air supply and GRS ® System to check for leaks and improper the system pushes a small amount of connections;...
-
Page 12: Power & Settings
POWER & SETTINGS x100 Power on the air compressor and allow tank to fill. G R A V E R M A C H ® Wait for the compressor to cycle off. Select Handpiece. Power on the Air System. x100 ®... - Page 13 HANDPIECE TUNING (CONTINUED) Hold the selected Set the Air Pressure to 5 psi handpiece vertically near (0.4 bar). either ear as shown. x100 G R A V E R M A C H G R A V E R M A C H ®...
- Page 14 HANDPIECE TUNING (CONTINUED) The settings in the chart may be used for adjusting the selected handpiece; this method is not as precise. Set the SPM dial and the air pressure control knob to the Recommended Initial Setting for the selected handpiece. H A N D P I E C E F I N E A D J U S T M E N T...
-
Page 15: Operation & Troubleshooting
OPERATION & TROUBLESHOOTING Depress the foot pedal Press the handpiece to actuate the standard knob to actuate the handpiece. Airtact handpiece. Apply more pressure to foot pedal or Airtact handpiece knob to increase handpiece power. Rely on increasing the power provided by the handpiece instead of manually pushing through the cut. -
Page 16: Important Notices
GRS dealer to order replacement parts and for ® ® instructions on replacement. Do not attempt to service parts that must be sent to GRS ® an authorized GRS dealer; these must be repaired or replaced by GRS or an authorized ®... -
Page 17: Specifications
GRAVERMACH AT SPECIFICATIONS ® DIMENSIONS SIZE: 7.12" x 9.3" x 6.3" [181 mm x 236 mm x 160 mm] WEIGHT: 11.4 lb [5.170953 kg] ENVIRONMENTAL OPERATING CONDITIONS Temperature range: 40°F [4°C] to 100°F [38°C] Relative humidity: Up to 85% at a maximum temperature of 100°F [38°C] Altitude: Up to 10,000 ft [3048 m] above mean sea level Transportation and storage temperature range: 0°F [-18°C] to 120°F [49°C] ELECTRICAL SUPPLY REQUIREMENTS... - Page 18 N O T E S ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ G R A V E R M A C H ®...
- Page 19 N O T E S ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ G R A V E R M A C H ®...
-
Page 20: Warranty
WARRANTY Each GRS Air System, including provided foot pedal, carries a full 2-year warranty covering parts and labor. Contact GRS or an authorized GRS dealer before ® ® returning any equipment. These products are designed for reliable operation using most sources of compressed air.
