850
EASY-TO-REMOVE BUR
INTRODUCTION
The GRS 850 Turbo Handpiece uses
regular friction grip burs. The rotor
spindle uses a non-lube bearing
and requires no further lubrication.
Work on porcelain, wood and other
materials completely free of the
problems associated with use of
lubricating oils. Turbine exhaust from
the nose of this handpeice helps
keep the workpiece clear of debris.
There are a few things the 850 needs to
work properly, a clean air supply of 30 - 35
psi at 1.34 CFM, regulator/air filter, and
a on/off air switch. We recommend a foot
switch for working convenience and safety.
fig. 1:
1 #004-762 Air Regulator/Filter
(not included)
2 Short Hose Connector
3 #004-863 GRS Foot Switch
(not included)
SIMPLY TURN RELEASE RING
Ultra High-Speed Rotary Handpiece
Complete Ultra 850
Rotary System with On/
Off Foot Control
NON-LUBE AIR TURBINE
90 DAY WARRANTY
SPECIFICATIONS
RECOMMENDED AIR PRESSURE:
30-35 psi max. (2.5kg/cm2) [0.2-0.25MPa]
SPEED: 320,000 rpm
AIR FLOW: 1.34 CFM (38 l / min)
HANDPIECE DIMENSIONS:
Approx. 5/8" dia. X 5 1/8" long
(16.6mm dia. X 130mm long)
HANDPIECE WEIGHT: 2.5 oz. (70.8g)
Specifications may change without notice.
850 High-Speed Rotary
Handpiece shown
attached to a GraverMach
2
1
fig. 1
3
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for GRS 850 Turbo Handpiece
Summary of Contents for GRS 850 Turbo Handpiece
- Page 1 EASY-TO-REMOVE BUR SIMPLY TURN RELEASE RING Ultra High-Speed Rotary Handpiece SPECIFICATIONS INTRODUCTION The GRS 850 Turbo Handpiece uses RECOMMENDED AIR PRESSURE: regular friction grip burs. The rotor 30-35 psi max. (2.5kg/cm2) [0.2-0.25MPa] spindle uses a non-lube bearing and requires no further lubrication.
- Page 2 35 psi (2.4 bar). Stop the rotary handpiece by turning the auxiliary knob until the air is shut OFF. For frequent ON / OFF usage, we recommend adding a GRS foot switch in the air line. Included with the handpiece are two air hose clamps.
- Page 3 850 Handpiece Cartridge with Chuck 5 #022-365 Chuck ONLY 6 #004-762 Air Filter-Regulator (as shown) #004-863 GRS On / Off Foot Control (3 on front of instructions) 7 #004-862 Ultra 850 Stand Assembly (as shown) #004-511 Carbide Bur Set (6 Piece Bur Set) #004-512 Diamond &...
- Page 4 1. Do not force the bur to cut, use BUR CHECK LIST light wiping motions when removing • USE ONLY .062” dia.(1.6mm) background material or cutting a shank burs. pattern during layout of a design. • Do NOT use broken or damaged burs. 2. Always use a sharp bur, when it You may damage the handpiece or becomes dull, do not push it harder yourself.
