Summary of Contents for Broadata 6820E Series
- Page 1 PTIC THERNET WITCHING ONVERTER BCI reserves the right to make changes to the products described herein without prior notice or consent. No liability is assumed as a result of their use or application. All rights reserved. ©2005 Broadata Communications, Inc.
- Page 2 This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend the life of your equipment. Broadata Technical Support, CustomerService@Broadatacom.com...
-
Page 3: Table Of Contents
4.0 SPECIFICATIONS ............8 5.0 REAR PANEL DIP SWITCH ..........8 6.0 FIBER LINK ALARM ............9 7.0 SERVICE PROCEDURE ..........10 7.1 REPLACEMENT POLICY ..........10 7.2 RETURN AND REPAIR SERVICE ......... 10 8.0 LIMITED WARRANTY ............ 11 Broadata Technical Support, (800) 214-0222... -
Page 4: Product Description
The installation and operation procedures of the 6820E/6821E are simple and straightforward. Operation status can be monitored through a set of diagnostic LED located in the front panel (as shown in Figure 1-1). FX TX LINK/ FDX PWR 5VDC IN Figure 1-1 6820E/6821E Front/Rear Panels Broadata Technical Support, CustomerService@Broadatacom.com... -
Page 5: Setup
T P - to- S C/S T S C/S T H dx F i ber F dx Networ k F i g. 2 B as i c Networ k Connecti on Figure 2-1 6820E/6821E Basic Network Connection Broadata Technical Support, (800) 214-0222... -
Page 6: Led Description
BCI 6820E/6821E User’s Manual Fast Ethernet Switching Converter 3.0 LED DESCRIPTION a l i i l r c i f l l u c i f Broadata Technical Support, CustomerService@Broadatacom.com... -
Page 7: Specifications
Status Indicators Power, FDX, TP Link, Optical Link Optical Fiber Type Multimode or Singlemode Number of Fibers 2 (6820) or 1 (6821) Operating Wavelength 1310, or 1550 nm Fiber Optic Connector SC (Multimode and Singlemode) Broadata Technical Support, (800) 214-0222... -
Page 8: Rear Panel Dip Switch
Further, if fiber port link down during operation, it will not turn down the UTP port link and vice versa. Notice The Link Alarm will be effective only when the TP Auto-negotiation is enabled. Broadata Technical Support, CustomerService@Broadatacom.com... -
Page 9: Service Procedure
The BCI 6820E/6821E System contains no user serviceable components. If you have a problem with your unit, please contact the Customer Service Department. To facilitate our return/repair processing please contact Broadata Communications, Inc. to obtain a Return Material Authorization (RMA). Please include the following information: •... -
Page 10: Limited Warranty
Fast Ethernet Switching Converter 8.0 LIMITED WARRANTY Broadata Communications, Inc. (BCI) warrants, for a period of one year from date of shipment, each product sold shall be free from defects in material and workmanship. BCI will correct, either by repair, or at BCI’s... - Page 11 BCI 6820E/6821E User’s Manual Fast Ethernet Switching Converter Broadata Technical Support, (800) 214-0222...
- Page 12 BCI 6820E/6821E User’s Manual Fast Ethernet Switching Converter Broadata Technical Support, CustomerService@Broadatacom.com...
- Page 13 BCI 6820E/6821E User’s Manual Fast Ethernet Switching Converter Broadata Technical Support, (800) 214-0222...
- Page 14 Broadata Communications, Inc. 2545 West 237th Street, Suite K Torrance, CA 90505 1-800-214-0222 (310) 530-1416 (310) 530-5958 (Facsimile) e-mail: CustomerService@Broadatacom.com Website: www.broadatacom.com 6000E-6820-B...
