GUIA LITE
INSTALLATION MANUAL
Manual PN: AAP186 REV 1.0
AG-NAV
1-800-99 AGNAV
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Guia Lite and is the answer not in the manual?

Questions and answers

Fanie Keyser
January 17, 2025

Please help. My Ag Nav lite does not want to advance with the spray micro switch. It does make point A and point B and the advance to the second loc line. There after it does not want to advance. What can I do?

1 comments:
Mr. Anderson
May 14, 2025

If the AG-NAV Guia Lite does not advance with the spray micro switch after reaching point A and point B, check the remote switch wiring. If installed into the pistol grip, the wires may need to be cut and reconnected as shown in the installation drawing. Ensure all connections are secure and correctly installed.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for AG-NAV Guia Lite

  • Page 1 GUIA LITE INSTALLATION MANUAL Manual PN: AAP186 REV 1.0 AG-NAV 1-800-99 AGNAV...
  • Page 2 AG-NAV Inc. AG-NAV Inc. provides this manual “as is”, without warranty of any kind and reserves the right to make improvements and/or changes to the product described in this manual at any time and without notice.
  • Page 3: Contact Information

    Barrie, ON L4N8Z5, Canada In the event of a problem that cannot be resolved using the information supplied, please contact AG-NAV. You can also gain assistance through the user’s area on our web page at www.agnav.com. For further assistance, contact the AG-NAV technical support line by telephone, fax, or email. AGNAV customer support personnel will discuss your situation, determine the cause of problem and provide the appropriate technical assistance.
  • Page 4: Getting Started

    This manual contains information relating to the physical, mechanical and electrical characteristics of the AG- NAV DGPS aerial application guidance system. Before beginning the AG-NAV installation, read the AG-NAV operations manual and become familiar with the modes and functions of operation. The AG-NAV system is AG-NAV...
  • Page 5 The aircraft operator is responsible for ensuring that FAA OR TRANSPORT CANADA regulations, applying to the installation of the AG-NAV System in his aircraft are followed. Ag-Nav Inc. provides these instructions as a guide to customers and assumes no responsibility or liability for the installation in individual aircraft.
  • Page 6 Table 1 below gives the weight of the components. Weight (Lbs. Current Draw Component Part No. / Kgs ) (Amps) COMPONENT ONE Main computer AG-NAV Guia Lite AAP186 1.01 / 0.46 Guia Lite mounting kit Admpm0185 0.57 / 0.26 COMPONENT TWO External large bright bar AAP207 4.15/ 1.88...
  • Page 7 Before Installation Before you begin installation, please make sure to carefully read the installation instructions. If any questions arise, please contact Ag-Nav customer support. Contact information is located on page 3 of this manual. Installation plan Select optimal mounting locations...
  • Page 8 Guia Lite dimension Figure # 2 AG-NAV 1-800-99 AGNAV...
  • Page 9 Guia Lite console installation The figure # 2 above shows the dimensions of the Guia Lite. The dimension will assist you installing the system. The Guia Lite system has three different mounting options as shown below, the ram mount is optional.
  • Page 10 FAA or TRANSPORT CANADA regulation. The bracket mount to the back of the console with 10-32 1/2 stainless steel hardware and then to the aircraft using approved hardware as shown below. Insert adjustable mount drawings figure # 9 Adjustable mount Figure # 10 AG-NAV 1-800-99 AGNAV...
  • Page 11 The Ram mount bracket is used to mount the console in similar location as the other brackets but it offers easy quick movable adjustments and quick disconnect and connect of the console as desired. The Ram mount bolts to Agnav brackets and then to the aircraft using approved hardware as shown below. Insert Ram mount Drawings figure #11 AG-NAV 1-800-99 AGNAV...
  • Page 12 AG-NAV 1-800-99 AGNAV...
  • Page 13 AG-NAV 1-800-99 AGNAV...
  • Page 14 Please use the following drawing information and dimensions for the various guidance bar installation. Agnav is not responsible for any installation beyond the installation manual or improper installation. Insert mounting drawings> The guidance unit comes with cables and some with extender cable with connectors. See section 2.5.4 for cable connections. AG-NAV 1-800-99 AGNAV...
  • Page 15 Vertical Stabilizer. The antenna does not need an external ground plane. See the following drawings for installation information and dimensions. The Antenna should be installed more than 6inchs from any other antennas or receivers’ due to interference. See section 2.5.6 for cable installation. AG-NAV 1-800-99 AGNAV...
  • Page 16 Breaker 2.5.1 Install a new air craft approved 5 Amp circuit breaker for the console (Guia Lite computer) system (13 – 24 V D.C.) power supply in the conventional location. Please Note that this breaker is for the console system only, if have flow system see Flow installation manual for information.
  • Page 17 If installing into the pistol grip as shown above figure # , the wires will have to be cut and reconnected. Connect the wires for the remote switch as shown in installation drawing below figure # . AG-NAV 1-800-99 AGNAV...
  • Page 18 AG-NAV 1-800-99 AGNAV...
  • Page 19 This will reduce the signal strength. Connect the TNC to the antenna with no 90-degree bend unless using an adapter with 90-degrees. This adapter may reduce the signal. Connect the other TNC end of the cable to the back of the Guia Lite shown in figure # . AG-NAV...
  • Page 20 2.5.7 The Guia Lite is provided with a system harness. This harness has power leads, indicator connector, boom on/off and a 5- way remote switch. The unit does not have any on power switch simply attach the connector to the unit and provide power and it will start up.
  • Page 21 AG-NAV 1-800-99 AGNAV...
  • Page 22 Insure all cables are connected correctly as to the manual and the main harness is connected securely to the platinum console. If all is checked, then the system can be powered. The Guia Lite will start up automatically when power is applied.
  • Page 23: Setup Testing

    Setup testing Guia Lite setup test procedures GUIA-LITE-HANDBOOK for more details. Settings Menu Entering the setting page provides six tabs each one controlling parts of the system. The system tab as shown to the left controls the language, brightness, reset default (delete all saved areas) and the record option.
  • Page 24 Spray Volume App Rate Application rate XTrack Cross-Track Grnd Hdg Ground Heading LLNum Locked Line Number Angle Of Intercept A/B Hdg A/B Line Heading GPS Alt GPS Altitude TAE[0/180] Track Angle Error Tank Left Material Left In Tank AG-NAV 1-800-99 AGNAV...
  • Page 25 Guia Lite Help Menu. The Help screen can be access by pressing the GUIA LITE located in the top right of the main screen. This Tab shows the abbreviation used. Guia Lite system maintenance. Like any computer maintenance is needed for longevity. Start with keeping the console clean and dry as much as possible.
  • Page 26: Troubleshooting Guide

    Check the TNC connection at both the antenna and receiver for any issues such as looseness and moisture. Sometimes moisture is an issue reducing the gain of the signal to the receiver. Next check the receiver LEDs. One will be red for power, on will be green for communications and a blue LED for signal. AG-NAV 1-800-99 AGNAV...
