- Page 1 OPERATION AND MAINTENANCE MANUAL MYAC61-0525L MYAC61-0525LF MYAC61-2050L MYAC61-0525P MYAC61-0525PF MYAC61-2050P AC-TYPE Non-Carbon-Brush Electric Screwdrivers ANLIDAR INDUSTRIAL CO., LTD. http://www.anlidar.com Y2F070A-2ETL-001...
- Page 2 NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. Anlidar is not responsible for customer modification of tools for applications on which Anlidar was not consulted. WARNING Important safety information enclosed. Read all these instructions before placing tool in service or operation and save these instructions. It is the responsibility of the employer to place the information in this manual into the hands of the operator.
-
Page 3: Important Safety Rules
Important Safety Rules WARNING! Read all instructions. Failure to follow all instructions listed below may result in electric shock fire and/or serious injure. The term “power tool” in all of the warning listed below refers to your mains-operated (corded) power tool or battery operated (cordless) power tool. - Page 4 4) Power tool Use and Care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use power tool if switch does not turn it on / off.
-
Page 5: Grounding Instructions
WARNING！ DO NOT OPERATE THIS TOOL WITHOUT PROTECTIVE EARTH CONNECTED Grounding Instructions 1、This tool should be grounded while in use to protect the operator from electric shock. NOTICE! To ensure the grounding result, the grounding conductor of the power cord must be well connected with the grounding terminal of power facility. This tool is equipped with grounding conductors. - Page 6 Operations Cautions 1) Whenever changing a bit, make certain the Forward / Reverse Switch is in the “ OFF “ position and tool is unplugged. 2) To avoid damaging the housing of screwdriver, do not allow chemicals get in touch with housing of screwdriver. Ex.: Acetone, benzene, thinner, trichloroethylene ketone, and other similar chemicals.
-
Page 7: Description Of Operation
Description of Operation Attaching / detaching bit and bit type Push up the holder clamp by finger tip, and it will be unlocked. Thus, the bit can be freely attached and detached (single finger notion type) select such a bit whose shank is equal to the size shown below. ... - Page 8 All repairs and maintenance of this tool and its word must be performed by an authorized service center. Anlidar is not responsible for customer modification of tools for applications on which Anlidar was not consulted. Repairs should be made only by authorized, trained personnel. Consult your nearest MYTORQ authorized service center.
-
Page 9: Specifications
Specifications MYAC61- MYAC61- MYAC61- MYAC61- MYAC61- MYAC61- MODEL 0525L 0525LF 2050L 0525P 0525PF 2050L Input voltage(AC) AC115V 50/60HZ 0.5A Power Consumption (kgf.cm) 5-25 5-25 20-50 5-25 5-25 20-50 Torque (Lbf.in) 4.34-21.7 4.34-21.7 17.36-43.4 4.34-21.7 4.34-21.7 17.36-43.4 (N.m) 0.49-2.45 0.49-2.45 1.96-4.9 0.49-2.45 0.49-2.45 1.96-4.9... - Page 10 2. The numbers from zero to eight on the torque scale are reference number only and not an indication of actual torque output. 3. Please refer to Anlidar websitehttp://www.anlidar.com for the detail component list.
