- Page 1 OPERATION AND MAINTENANCE MANUAL MY7-1030L MY7-1030P MY7-0522LF MY7-0522PF MY8-0205L MY8-0205P DC-TYPE Automatic Non Carbon Brush Series ANLIDAR INDUSTRIAL CO., LTD. http://www.anlidar.com Y2F165A-2E-001...
- Page 2 NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. Anlidar is not responsible for customer modification of tools for applications on which Anlidar was not consulted. WARNING Important safety information enclosed. Read all these instructions before placing tool in service or operation this tool and save these instructions. It is the responsibility of the employer to place the information in this manual into the hands of the operator.
-
Page 3: Important Safety Rules
Important Safety Rules WARNING! Read all instructions Failure to follow all instructions listed below may result in electric shock fire and/or serious injure. The term “power tool” in all of the warning listed below refer to your mains operated (corded) power tool or battery operated (cordless) power tool. - Page 4 b) Do not use power tool if switch does not turn it on or off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. c) Disconnect the plug from the power source before making any adjustments, changing accessories, or storing the power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
-
Page 5: Grounding Instructions
WARNING！ DO NOT OPERATE THIS TOOL WITHOUT PROTECTIVE EARTH CONNECTED Grounding Instructions 1、This tool should be grounded while in use to protect the operator from electric shock. NOTICE ! To ensure the grounding result, the grounding conductor of the power cord must be well connected with the grounding terminal of power facility. This tool is equipped with grounding conductors. - Page 6 Operations Cautions 1) Whenever changing a bit, make certain the Forward / Reverse Switch is in the “ OFF “ position and tool is unplugged. 2) To avoid damaging the housing of screwdriver, do not allow chemicals get in touch with housing of screwdriver. Ex.: Acetone, benzene, thinner, trichloroethylene ketone, and other similar chemicals.
-
Page 7: Description Of Operation
Lo for slowest rotation. It's possible that the uncompleted shut-off occurs when the switch is setup to Lo and the presetting torque is more than 50% of torque range. Please refer to the following table. Lo Switch MY7-1030L MY7-1030P MY8-0205L MY8-0205P 15( kg )↓... - Page 8 All repairs and maintenance of this tool and its word must be performed by an authorized service center. Anlidar is not responsible for customer modification of tools for applications on which Anlidar was not consulted. Repairs should be made only by authorized, trained personnel. Consult your nearest MYTORQ authorized service center.
-
Page 9: Specifications
Specifications MODEL MY7-1030L MY7-1030P MY7-0522LF MY7-0522PF MY8-0205L MY8-0205P Input voltage (DC) DC32V / 24V DC 40V Power Consumption 120W (kgf.cm) 10-30 10-30 5-22 5-22 20-50 20-50 (Lbf.in) 8.67-26.02 8.67-26.02 4.34~19.10 4.34~19.10 17.35-43.37 17.35-43.37 Torque Hard Joint 0.98-2.94 0.98-2.94 0.49~2.16 0.49~2.16 1.96-4.9... - Page 10 3. The power supplier will generate low power when the button of the power controller is switched to "LO." Also, the electric screwdriver's torque output setting value should be adjusted to middle torsion value accordingly. 4. Please refer to Anlidar website http://www.anlidar.com for the detail component list.
