DANLERS CASAMBI CBU-MNPIR5MSW Manual

CBU-MNPIR5MSW
Ceiling Flush Mount Passive Infra Red
(PIR) Occupancy Detector & Photocell
Input: 100-240 Vac 50/60Hz
PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLING THE PRODUCT
NOTE: CBU-MNPIR5MSW is only compatible to work with Casambi enabled app.
This fl ush mounted CBU-MNPIR5MSW is suitable
for easy mounting through a 38/40mm diameter
hole into a ceiling void which is at least 60mm
deep. Confi gurable for any room occupancy style,
via the free to download Casambi APP on Google
Play or Apple APP Store.
INSTALLATION
To be installed by a competent person with
reference to BS 7671 or equivalent local standards.
If in doubt consult a qualifi ed electrician.
• Plan where the CBU-MNPIR5MSW is to be
located (see diagram 1). Switch off supply and
check for hidden cables and pipes. Make a
38/40mm diameter hole through a standard
ceiling board.
• The MNPIRPSSW should be connected as
shown in diagram 2:
L - Live in. N - Neutral in. SW - Switched line.
• Ensure both springs are fi tted to the CBU-
MNPIR5MSW in the correct orientation (see
diagram 3)
• Fit one end of the Telejack into the MNPIRPSSW
the other end fi t to the CBU-MNPIR5SW. (see
diagram 4)
• Push both connected products into the ceiling
void.
OPERATION
To check the operation of the CBU-MNPIR5MSW
subject to software version:
• Turn on the supply then after 20 seconds if the
sensor has recognised movement of a person
within its zone of detection the integral red LED
on CBU-MNPIR5MSW will fl ash before the red
LED turns off .
• Every time movement is detected by CBU-
MNPIR5MSW the integral red LED will fl ash.
The control also features adjustable time out (time
lag) control and daylight threshold control which
are confi gured by the Casambi APP.
PRECAUTIONS
• Do not place the CBU-MNPIR5MSW near heat
sources, fans or in ventilated ceiling voids.
• Do not place close to, or positioned such
that, any light source points directly into the
CBU-MNPIR5MSW.
• Ensure wires and cables are securely held within
the connection terminals.
• The CBU-MNPIR5MSW should be protected by
a 5 or 6 Ampere mcb or fuse.
• Disconnect the CBU-MNPIR5MSW from the
circuit before performing insulation testing
of the wiring circuit.
DANLERS Limited, Vincients Road, CHIPPENHAM, Wiltshire, SN14 6NQ, UK.
Telephone: +44 (0)1249 443377 Fax: +44 (0)1249 443388 E-mail: sales@danlers.co.uk
www.danlers.co.uk
Company Registered Number 2570169 VAT Registration Number 543 5491 38
04/09/2023
TECHNICAL DETAILS
INPUT
Voltage: 100 - 240Vac
Frequency: 50/60Hz
Max. mains current: 20mA
Standby current: 14mA
LOADING
Fluorescent lamps,
2 amps (450W)
either high frequency
Incandescent or mains
2 amps (450W)
halogen lamps
LED lamps and drivers
2 amps (450W)
(PF ≥ 0.95).
RADIO TRANSCEIVER
Operating frequencies: 2.4... 2,480 GHz
Max. output power: +4 dBm
LUX PARAMETERS
Range: 5 - 2000 lux
OPERATING CONDITIONS
Note: The temperature diff erence between the
detection target and the background must be at
least 4 °C.
Ambient temperature:
-20... +40 °C
Storage temperature: -25... +75 °C
Max. relative humidity: 0... 80%, non cond.
CONNECTORS
Terminal block 0.5mm
Wire size: or stranded
Wire strip length: 6-7mm
Tightening torque: 0,4 Nm/4 Kgf.cm
MECHANICAL DATA
Dimensions:
See diagram 3
Weight:
102g (unpacked)
Degree of protection: IP40
Protection class: Built-in Class 2
Flame-retardant
Material (casing)
polycarbonate
Finish / Colour Matt /White (RAL 9003)
Protection class: Built-in Class 2
CONFORMITY AND STANDARDS
EMC emission:
EN 301 489-1 V2.2.0,
EN 301 489-17 V3.1.1,
EN 55032: 2015,
EN61000-3-2: 2014,
EN61000-3-3: 2013
DAT0239 CBU-MNPIR5MSW
EMC immunity:
EN 301 489-1 V2.2.0,
EN 301 489-17 V3.1.1
Environment:
Complies with WEEE and RoHS directives
5 YEAR WARRANTY
CBU-MNPIR5MSW comes with a 5 year
warranty from the date of manufacture
and is CE marked.
- 2.5mm solid
