Checking the firmware version
Before beginning to update the firmware, check the firmware version of the CA-XLR2d being used.
Preparing
o Detach the CA-XLR2d from the camera unit before updating the firmware.
o Disconnect all cables connected to the unit.
ATTENTION
For Windows
Use a computer running Windows 10 or later to conduct firmware updates.
Downloading the firmware updater
For Windows
1.
Download the firmware updater for Windows (zip file) from
the TEAC Global Site (http://teac-global.com/) and save it
on the computer to be used.
2.
Uncompress the saved zip file on the desktop or another
location to generate the updater execution file (exe file).
Connecting
Use a USB cable to connect this unit to the computer.
o After connecting them, confirm that both the
POWER SUPPLY indicators on the unit are lit.
NOTE
The USB port of this unit is specifically for firmware updates.
Bus power from the computer USB port will provide the
necessary power to the unit for the firmware update.
0622.MA-3501B
For Mac
Download the Mac firmware updater (as a ZIP file) for the
operating system you are using from the TEAC Global Site
(http://teac-global.com/) and save it on the computer.
NOTE
Depending on the computer's settings, the downloaded ZIP
file might not have opened automatically. In this case, unzip
the ZIP file to access the disk image file.
and
CA-XLR2d
TASCAM CA-XLR2d
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CA-XLR2d and is the answer not in the manual?

Questions and answers

Related Manuals for Tascam CA-XLR2d

Summary of Contents for Tascam CA-XLR2d

  • Page 1 CA-XLR2d Checking the firmware version Before beginning to update the firmware, check the firmware version of the CA-XLR2d being used. Preparing o Detach the CA-XLR2d from the camera unit before updating the firmware. o Disconnect all cables connected to the unit.

  • Page 2: Checking The Firmware Version

    “To”. The current firmware version is shown under “From” and the update version is shown under “To”. Click on the “Cancel” button to close the updater window. Click on the “Cancel” button to close the updater window. TASCAM CA-XLR2d...
  • Page 3 Procedures for updating the firmware NOTE The CA-XLR2d updater may contain an update program for the shoe mount adapters. Please check the contents of the update in the release notes. In case the shoe mount adapter requires to be updated, attach the shoe mount adapter to the main unit before proceeding with all updates.

  • Page 4: Updating The Firmware

    Therefore, even if it is attached to the main unit, button on the upper right of the windows to close the screen. the firmware update of the shoe mount adapter will not be executed and the next control firmware update will be executed. TASCAM CA-XLR2d...
  • Page 5 Click the “OK” button to start the firmware update. Double-click the application shown below to launch the firmware updater. ATTENTION Do not disconnect the USB cable or turn the computer off during the update. Doing so could corrupt the firmware, making updating and ordinary operation impossible. TASCAM CA-XLR2d...
  • Page 6 The following screen will appear when firmware updating finishes. This completes the update. Click the button at the top left to close the window and disconnect the USB cable from this unit and the computer. NOTE Updating will take about 8 minutes at most. TASCAM CA-XLR2d...
