English version

Microphone

Note! When using the built-in microphone, Windows must have selected it as an active recording device. You can check this as follows:
Go to START "Control Panel"
Or, if the Windows classic style is used:
Go to START "Settings"
Here, open "Sound and audio devices" and go to the "Audio" tab.
Check if the sound recording device is set to 'USB camera'.
LED indicator
The Sweex USB Webcam 300K with Microphone has 1 green LED. This is continuously lit, which means that the webcam has been connected and
is functioning properly.
Focus ring
The picture of the Sweex USB Webcam 300K with Microphone can be brought into focus manually by means of the focus ring. This can be found at
the front of the camera and can be identified by a black notch. By turning it either to the left or right, the picture can be brought into focus.
Snapshot button
The Sweex USB Webcam 300K with Microphone also has a so-called snapshot button. Use this to take a picture at any random moment. It is
enabled following installation. The button can be found on top of the webcam.
"Control Panel".
