SWEEX SW005 - QUICK_START_GUIDE Introduction

English version English version
Introduction
First of all, many thanks for purchasing the Sweex 5/8 Port Switch 10/100 Mbps. To ensure this product operates correctly, we advise you to
carefully read this manual first. If despite this manual you still experience problems during installation or operation of this product, go to www.sweex.
com and look under the heading service & support.
Contents of the box
Prior to installation, check if all required parts are present. The following parts must be present in the box:
• Sweex 5/8 Port Switch 10/100 Mbps
• Power supply adaptor
• CD-ROM with manual
If one of the above parts is missing, please contact the shop or supplier.

Specifications

• Number of ports SW005: 5 x 10/100 Mbps UTP/RJ45 port
• Number of ports SW008: 8 x 10/100 Mbps UTP/RJ45 port
• Supports: IEEE 802.3 10BASE-T, IEEE 802.3U 100BASE-TX
• Supports: Full and half duplex (Auto-Negotiation)
• Not operating system dependent
Additional specifications
• Uplink facility for each port
• Network protocol: CSMA/CD
• External power supply SW005: AC12V, 0.35A
• External power supply SW008: AC 9V, 0.8A
• Operating temperature: 0 -50 °C
• Humidity: 10 - 90%
SW005 Sweex 5 Port Switch 10/100 Mbps
SW008 Sweex 8 Port Switch 10/100 Mbps
