Summary of Contents for Boyo Vision VTR93MHD
- Page 1 VTR93MHD 2 Channel Full HD Mirror Monitor Rear View Camera • Dashcam USER MANUAL...
- Page 3 Do not force the memory card into the slot as it can damage the card or VTR93MHD. When the micro-SD card is inserted properly and in the right direction, a micro-SD card will drop into the card slot and only gentle press is needed at the end to secure –...
- Page 4 VTR93MHD Streaming Media Rear-View Mirror Monitor to obtain clear images. Please handle VTR93MHD with care. Avoid using VTR93MHD in a high electromagnetic environment. Operating temperature of the VTR93MHD is -4°F to 140°F. Continuous exposure to sunlight, especially when VTR93MHD is mounted in a vehicle where the temperature exceeds above 158°...
-
Page 5: Package Content
VTR93MHD Streaming Media Rear-View Mirror Monitor Package Content VTR93MHD Streaming Media Rear-View Mirror Mirror Monitor Front Camera Rearview Camera Mounting Straps Car Charger GPS Antenna User Manual Hardwiring... -
Page 6: Product Structure
VTR93MHD Streaming Media Rear-View Mirror Monitor Product Structure 1. USB Power Port 7. ON/OFF Power Button 2. Rear-view Camera Port 8. Reset 3. Micro-SD Card Slot 9. Speaker 4. GPS Antenna Port 10. Back Strap Mounting Hook 5. IPS Screen 11. -
Page 7: Power Function
Cigarette jack power on Hard-wired turn the key to accessories position The power will be supplied to VTR93MHD. The BOYO logo will appear first, and then the icons and the camera(s) will be displayed. Recording will start automatically. Cigarette jack... -
Page 8: Home Screen Icons
VTR93MHD Streaming Media Rear-View Mirror Monitor B. Home Screen Icons VTR93MHD will display the homepage after it is powered ON. Homepage screen: Impact Sensor On/O Indicator GPS Antenna Connect Status Compass & Speed Sensor Recording Indicator Loop Recording Timer Brightness Control... - Page 9 VTR93MHD Streaming Media Rear-View Mirror Monitor “Impact Sensor” – If shown, the impact sensor is turned on “Vehicle Speed” shows the current travelling speed. “Video Resolution” Current video resolution settings for the front and rear cameras. “Compass” - The arrow will show the real-time driving direction of the vehicle.
- Page 10 VTR93MHD Streaming Media Rear-View Mirror Monitor : Turn on : Turn off Recording Lock/Unlock button: Save the current video file and lock it. The loop recording will not overwrite the file. icon will appear on the top right of screen.
- Page 11 VTR93MHD Streaming Media Rear-View Mirror Monitor “front camera folder” button – ‘1’ indicates that the folder contains the front camera videos or photos “rear camera folder” button – ‘2’ indicates that the folder contains the rear camera videos or photos at the bottom right of the screen indicates the current page number.
-
Page 12: System Setting
VTR93MHD Streaming Media Rear-View Mirror Monitor System Setting Click to enter the system setting menu (shown as below). To change a setting Click key to switch the menu pages. Select menu item – e.g. “Resolution”, “Loop Recording”, etc. Select an option – e.g. “1080P” or “720P”... - Page 13 VTR93MHD Streaming Media Rear-View Mirror Monitor the specified time and the monitor will act as rear- view mirror. Impact Sensor Options: Off, Low, Medium, High Sensitivity When the vehicle brakes suddenly or be hit, the impact sensor will be activated. The current recording file will be saved and locked to prevent from being overwritten.
- Page 14 VTR93MHD Streaming Media Rear-View Mirror Monitor Note: On sequence of vibrations, only the first video will be locked. This function can only work normally in the condition of a fully charged battery or powered by car charger. Motion Options: Off, On...
- Page 15 VTR93MHD Streaming Media Rear-View Mirror Monitor “Confirm” to reset the system setting to factory default. Default Version Firmware Version of the device Time Zone Select local time zone Speed Unit Options: MPH, KPH E. GPS Player – Video Playback with Geo-Location Display (PC Only) ** GPS Player is available at www.visiontechamerica.com.
- Page 16 VTR93MHD Streaming Media Rear-View Mirror Monitor Settings: the language, speed unit and map can be set here. Video View Window Scroll Bar: show the current point of the video; click forward or backward to check the point users want view.
- Page 17 VTR93MHD Streaming Media Rear-View Mirror Monitor F. USB Mode – Connecting device to a PC ** USB cable not included When the VTR93MHD is connected to a PC via a USB cable, the following selection will pop-up on the screen. 1. Memory Mode The device is acting as a storage device, and you can access the recorded videos and photos from the connected PC.
-
Page 18: Specifications
VTR93MHD Streaming Media Rear-View Mirror Monitor Specifications Specifications may change without prior notice. Screen 9.66” full touch IPS screen 1920*1080P (front) Video Resolution 1920*1080P (rear) 170° diagonal viewing angle(front) Cameras 100° diagonal viewing angle(rear) Frame Rate 30fps Video Format Photo Format... -
Page 19: Warranty Information
WARRANTY INFORMATION This one-year limited warranty is given to the end-user or the retail purchaser (referred to this warranty as “Original Purchaser”) that it will be free from defects in material and workmanship for a period of one year from the date of the purchase of the new product (excluding accessory items such as power cords, cradle, memory card, adaptor, and cables). - Page 20 For technical support call 888-941-3060 Email info@VisionTechAmerica.com Visit www.VisionTechAmerica.com Vision Tech America, Inc. 1452 E. Valencia Dr. Fullerton, CA 92831...
