InfraPower Manager - IPM-04-3P-400V
1. Is IPM-04 management software free of charge ?
Yes.
2. What is InfraPower Manager ?
The InfraPower Manager IPM-04 is a Windows based system to consolidate management of max. 800
PDUs via 50 IP dongles, using a simple web interface which monitors and controls dual feed single
phase , single & 3 Phase W series PDUs.
- SNMP Capability v2 / v3 via IP Dongle
- Outlet switch On/Off and scheduling
- Outlet level kWh & amp measurement
- Temp-Humid monitoring
- Graphic user interface
- PDU & outlet reporting ( kWh / Amp / Event / Temp & Humid )
3. Which OS platform does IPM-04 support ?
- MS Windows 10 Pro
- MS Windows 7 Professional with SP1
- MS Windows Server 2012 R2 Standard Edition
- MS Windows Server 2008 Standard Edition SP2
- MS Windows Server 2008 R2 Standard Edition SP1
- MS Windows Server 2003 R2 Standard Edition with SP2
Ensure the user logins as a member of "Administrators" Group before IPM-04 Installation
and execution.
4. What are the default ports used in the IPM-04 ?
- UTP port : 8890 for searching IP Dongle
- TCP port : 4000 for IP Dongle communication
- TCP port : 80 for HTTP
- TCP port : 25 for email alarm service ( can be changed by user )
5. Why can't I access the login page ?
- If the web service is started & the port of web server is open in fi rewall setting
6. Why can't I login remotely ?
- If the login name & password is correct
7. Which database does the IPM-04 support ?
PostgreSQL
8. What is the PostgreSQL default password for IPM-04 ?
1qaz2WSX
9. How can I receive alarm email and get full log report ?
Ensure that IPM-04 is executed and the alarm server is confi gured properly and being enabled.
10. What is the default user name & login password of IPM-04 ?
Default user name " admin " / Default login password " 00000000 "
FAQ-IPM-04-3P-400V-Q419V1
FAQ
P.1
P.1
www.austin-hughes.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Austin Hughes InfraPower Manager IPM-04-3P-400V
Summary of Contents for Austin Hughes InfraPower Manager IPM-04-3P-400V
- Page 1 InfraPower Manager - IPM-04-3P-400V 1. Is IPM-04 management software free of charge ? Yes. 2. What is InfraPower Manager ? The InfraPower Manager IPM-04 is a Windows based system to consolidate management of max. 800 PDUs via 50 IP dongles, using a simple web interface which monitors and controls dual feed single phase , single &...
- Page 2 11. What is the command password of IPM-04 ? - Each IP Dongle group has its command password ( Default “ 00000000” ) . - For security, it will be requested for any PDU confi guration and control. - Only administrator can set command password. - The passwords are disabled or enabled, same or different subject to the administrator’s management.
- Page 3 IP Dongle 1. What is the IP Dongle ? The IP Dongle, with patented hot-plug & fi eld replaceable design and SNMP function, provides a simple and economical way to consolidate management of max. 16 pcs of Dual Feed single phase , single & 3 Phase PDUs via a single network IP address to save IP address cost.
- Page 4 IP Dongle 11. Will the reset of IP Dongle affect the power to the outlets ? No, the IP Dongle operates on a separate circuit, so the power to the outlets will remain unchanged. 12. What are the symptoms if the IP Dongle fails ? - UI shows IP Dongle disconnection and users fail to access the whole cascaded PDUs - Green LED off of IP Dongle 13.
- Page 5 W Meter 1. What are features of the W Meter ? Support Dual Feed single phase , single & 3 Phase PDU and they can be inter-cascaded in a single daisy chain - Support switched PDU and outlet amp + kWh measurement - Simply connect 1 x IP Dongle to access up to 16 PDUs to save IP network address - SNMP Capability v2 / v3 via IP Dongle - Sensor port x 2...
- Page 6 W Meter 10. How accurate is the energy measurement on W Meter ? The W Meter have an accuracy of +/- 1% of reading across the entire power and outlets energy measure- ment compliant with IEC 62053/ANSI C12.20 Standards - Ampere - squelched to 0A under 0.3A - Accuracy is not defi...
- Page 7 Power Module 1. What is feature of the Power Module ? - convert AC to DC for W Meter, IP Dongle & outlet control module - fi eld replaceable design allows quick replacement 2. How affect the W Meter if the Power Module fails ? It will cause the meter fails to work as below : - if the W Meter PDU is one of level among the 2nd to the last, UI shows PDU disconnection and users fail to access this PDU...
- Page 8 Outlet Control Module 1. How many types of Outlet Control Module ? The outlet control module is a built-in PCB and NOT a hot-swapped & fi eld replaceable design. - switched & measurement module for WSi switched & outlet level measurement PDU - outlet measurement module for Wi outlet level measurement PDU - switched module for WS switched PDU 2.
- Page 9 TH Sensors 1. How accurate is the Temp. & Humid. sensor ? ± 1°C ( typical ) & ± 4.5% RH ( typical ) 2. How accurate is the Temp. sensor ? ± 1.5°C ( typical ) 3. What is the default TH setting ? Default : Deactivate 4.
