Austin Hughes InfraPower Manager IPM-03 Troubleshooting

Replacement, Removal or addition for PDU & IP dongle
1. How to replace the failed IP dongle ?
Step 1 - Prepare a new IP dongle.
Step 2 - Disable alarm email in <Alarm> page.
Step 3 - Replace the failed IP dongle with the new one on 1st level PDU.
Step 4 - Confi gure the setting of the new IP dongle same as the old one.
(Please refer to user manual < 2.2 > for details)
Step 5 - Click Start Connection in <Status> page for the relevant IP dongle.
Step 6 - Enable alarm email in <Alarm> page again.
2. How to replace the failed 1st level PDU with a new one ?
Step 1 - Prepare a new PDU and set the PDU to 1st level.
(Please refer to user manual < 1.2 > display 9.1 for details)
Step 2 - Disable alarm email in <Alarm> page.
Step 3 - Power off & unplug the device(s) which connected to the PDU.
Step 4 - Power off & remove the failed 1st level PDU from connection.
Step 5 - Install the IP dongle on the new 1st level PDU.
Step 6 - Install and connect the new PDU.
Step 7 - Power on the new PDU and connect to the device(s).
Step 8 - Click Start Connection in <Status> page for the relevant IP dongle.
Step 9 - Confi gure the new PDU in <Details> and <TH Sensor> page such as Alarm Amp , Name,
Location...
Step 10 - Enable alarm email in <Alarm> page.
3. How to replace a failed certain level PDU with a new one ?
Step 1 - Prepare a new PDU and set the PDU level accordingly.
(Please refer to user manual < 1.2 > display 9.1 for details)
Step 2 - Prepare an appropriate length Cat. 5/6 cable.
Step 3 - Click Set maintenance in <Details> page for the failed PDU.
Step 4 - Use the Cat. 5/6 cable to bridge over the failed PDU which will be replaced to minimize log / data loss.
Step 5 - Power off & unplug the device(s) which connected to the failed PDU.
Step 6 - Power off & remove the failed PDU from connection.
Step 7 - Install the new PDU, cancel the cable-bridging and reconnect the
PDU to the last and next one.
Step 8 - Power on the new PDU and connect to the device(s).
Step 9 - Click Remove maintenance in <Details> page for the new PDU.
Step 10 - Confi gure the new PDU in <Details> and <TH Sensor> page such as Alarm Amp, Name,
Location...
Ignore step 2 & 4 if the failed PDU is in the last level.
TRS-IPM-03-Q313V3
Troubleshooting
P.1 www.austin-hughes.com
