Toro Flex-Force Power System 51827 Operator's Manual

Toro Flex-Force Power System 51827 Operator's Manual

60v max leaf blower
Hide thumbs Also See for Flex-Force Power System 51827:

Advertisement

Quick Links

Download this manual
Register at www.Toro.com.
Original Instructions (EN)
Flex-Force Power System
60V MAX Leaf Blower
Model No. 51827—Serial No. 324000000 and Up
Model No. 51827T—Serial No. 324000000 and Up
Form No. 3467-105 Rev B
*3467-105*
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the Flex-Force Power System 51827 and is the answer not in the manual?

Questions and answers

Related Manuals for Toro Flex-Force Power System 51827

Summary of Contents for Toro Flex-Force Power System 51827

  • Page 1 Form No. 3467-105 Rev B Flex-Force Power System ® 60V MAX Leaf Blower Model No. 51827—Serial No. 324000000 and Up Model No. 51827T—Serial No. 324000000 and Up *3467-105* Register at www.Toro.com. Original Instructions (EN)
  • Page 2 Model 51827T does not include a battery or a charger. Read this information carefully to learn how to operate and maintain your product properly and to avoid injury and product damage. You are responsible for operating the product properly and safely. © 2024—The Toro® Company *3467-105* Original Instructions...
  • Page 3 Whenever you need service, genuine Toro parts, or additional information, contact an Authorized Service Dealer or Toro Customer Service and have the model and serial numbers of your product ready. Figure 1 identifies the location of the model and serial numbers on the product.

  • Page 4: Safety Alert Symbol

    Safety-Alert Symbol The safety-alert symbol (Figure 2) shown in this manual and on the machine identifies important safety messages that you must follow to prevent accidents. g000502 Figure 2 Safety-alert symbol The safety-alert symbol appears above information that alerts you to unsafe actions or situations and is followed by the word DANGER, WARNING, or CAUTION.
  • Page 5 Safety WARNING Read all safety warnings, instructions, illustrations and specifications provided with this mahcine. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “machine” in all the warnings refers to your mains-operated (corded) machine or battery-operated (cordless) machine.
  • Page 6 When operating a machine outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. If operating a machine in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
  • Page 7 IV. Machine use and care Do not force the machine. Use the correct machine for your application. The correct machine will do the job better and safer at the rate for which it was designed. Do not use the machine if the switch does not turn it on and off. Any machine that cannot be controlled with the switch is dangerous and must be repaired.
  • Page 8 V. Battery tool use and care Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. Use machines only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
  • Page 9 VII. Blower safety Do not use the machine in bad weather conditions, especially when there is a risk of lightning. This decreases the risk of being struck by lightning. Wear eye protection and ear protection. Adequate protective equipment will reduce the risk of personal injury. While operating the machine, always wear non-slip and protective footwear.

  • Page 10: Safety And Instructional Decals

    Safety and Instructional Decals Safety decals and instructions are easily visible to the operator and are located near any area of potential danger. Replace any decal that is damaged or missing. decal161-7051 161-7051 decal161-7054 161-7054 3. Thrown object hazard—keep 1. Warning—read the Operator’s Manual; wear eye and ear protection;...
  • Page 11 decal161-7050 161-7050 1. Warning—read the Operator’s Manual; 3. Thrown object hazard—keep wear eye and ear protection; do not bystanders away. expose to rain or snow; stay away from moving parts; keep all guards and shields in place; remove the battery pack before performing maintenance.
  • Page 12 decal161-3764 161-3764 1. Battery charge status decal161-7064 161-7064 1. Read the 5. Keep away Operator’s from open fire Manual . or flames 2. Call2Recycle ® 6. Do not expose battery to rain recycling program 3. Recycle the 7. Electrical shock battery hazard 4.
  • Page 13 Setup Important: The battery pack is not fully charged when you purchase it. Before using the tool for the first time, refer to Charging the Battery Pack (page 21). Mounting the Battery Charger (Optional) If desired, mount the battery charger securely on a wall using the wall-mount key holes on the back of the charger.

  • Page 14: Assembling The Blower

    Assembling the Blower Install the blower nozzle to the blower tube. g472735 Figure 4 Slide the blower tube onto the blower housing. You may need to press down on the tube latch for the blower tube to lock into place (Figure g472734 Figure 5...

  • Page 15: Product Overview

    Product Overview g472736 Figure 6 1. Battery and battery cavity 5. Blower tube latch 2. Turbo boost button 6. Blower tube 3. Speed lock 7. Variable-speed trigger 4. Handle knob g355813 Figure 7 1. Battery charger Model 88902 (included 2. Battery pack Model 88941 (included with Model 51827) with Model 51827)

  • Page 16: Specifications

    Store the tool, battery pack, and battery charger in an enclosed clean, dry area. Attachments/Accessories A selection of Toro approved attachments and accessories is available for use with the machine to enhance and expand its capabilities. Contact your Authorized Service Dealer or authorized Toro distributor or go to www.Toro.com for a list of all approved attachments and accessories.

  • Page 17: Operation

    Operation WARNING The blower can throw debris, possibly causing serious personal injury to you or bystanders. • Do not blow hard objects, such as nails or bolts. • Do not operate the blower near bystanders or pets. • Be careful of blowing direction (i.e., blow away from bystanders, windows, automobiles, etc.).
  • Page 18 To start the blower, squeeze the variable-speed trigger (Figure Note: Engage the speed lock to keep the machine on without pressing the variable-speed trigger (Figure g472737 Figure 9 1. Speed lock 4. Battery latch 2. Turbo boost button 5. Blower venting areas 3.
  • Page 19 Adjusting the Air Speed of the Blower To adjust the air speed as you blow, use the variable-speed trigger (Figure To maintain the current air speed, engage the speed lock (Figure To achieve maximum performance, depress the variable-speed trigger, then press the turbo boost button to turn boost on (Figure To turn boost off, press the turbo boost button again or completely release the variable speed trigger.
  • Page 20 Removing the Battery from the Blower Press the battery latch to release the battery pack and slide the battery pack out of the blower (Figure 11). g472739 Figure 11 1. Battery latch...

  • Page 21: Charging The Battery Pack

    Charging the Battery Pack Important: The battery pack is not fully charged when you purchase it. Before using the tool for the first time, place the battery pack in the charger and charge it until the LED display indicates the battery pack is fully charged.
  • Page 22 Refer to the following table to interpret the LED indicator light on the battery charger. Indicator Indicates light No battery pack inserted Green Battery pack is charging blinking Battery pack is charged Green Battery pack and/or battery charger is over or under the appropriate temperature range Red blinking Battery pack charging fault*...
  • Page 23 Storage Important: Store the tool, battery pack, and charger only in temperatures that are within the appropriate range; refer to Specifications (page 16). Important: If you are storing the battery pack for the off-season, remove the battery pack from the tool and charge the battery pack until 2 or 3 LED indicators turn green on the battery.

  • Page 24: Troubleshooting

    Call2Recycle seal, please contact your local municipality for more information on how to responsibly recycle the battery. If you are located outside of the US and Canada, please contact your authorized Toro distributor. Troubleshooting Perform only the steps described in these instructions.
  • Page 25 Problem Possible Cause Corrective Action The tool does not reach full 1. The battery pack charge 1. Remove the battery power. capacity is too low. pack from the tool and fully charge the battery pack. 2. The air vents are 2.
  • Page 26 Problem Possible Cause Corrective Action The LED indicator light 1. There is an error in 1. Remove the battery on the battery charger is the communication pack from the battery blinking red. between the battery charger, unplug the pack and the charger. battery charger from the outlet, and wait 10 seconds.
  • Page 27 California Proposition 65 Warning Information What is this warning? You may see a product for sale that has a warning label like the following: WARNING: Cancer and Reproductive Harm—www.p65Warnings.ca.gov. What is Prop 65? Prop 65 applies to any company operating in California, selling products in California, or manufacturing products that may be sold in or brought into California.

This manual is also suitable for:

Flex-force power system 51827t
