- Page 1 FINGERPRINT DOOR LOCK Model: SH-WB01(SE) Doc.No.: SH-WB01(SE)-Ins11142023100 Version No: V1.00 Date: 11-14-2023...
- Page 2 Congratulations on your purchase of the SECURAM EOS Fingerprint Door Lock! Quick Tour of EOS Fingerprint Door Lock Fingerprint Sensor Battery Cover Thumb Turn Button: Button: Function/Cancel/No Confirm/Yes...
- Page 3 • The EOS Fingerprint door lock has 9 user capacity (including Administrator) > Each user can set 1 code and register up to 2 fingerprints • Users can be set as Owners or Visitors > Owners and Visitors can unlock using a fingerprint or code •...
-
Page 4: What's Included In The Package
What’s included in the package... - Page 5 Touchpad Assembly Deadbolt, Strike Plate & Security Box Strike Screws (4) Interior Assembly Deadbolt Screws (2) Mounting Plate Door Magnet AA Batteries (4) Override Keys (2) Mounting Tape Mounting Screws (8)
-
Page 6: Installation
Installation: Scan the QR code to view the EOS Fingerprint Door Lock installation video. To open the lock with the default Administrator code: The default Adminstrator code is 123456. First, wake the device by swiping your fingers over the Touchpad. Enter 123456 then button to open the lock using the default Administrator code. - Page 7 Note: if you do not want to add a code for this user, press to skip > Repeat new code - enter the same code again followed by the button > Operation successful IMPORTANT: This new code is the Administrator code. It replaces the default Administrator code 123456.
- Page 8 Delete User - press 3 > Wake the device by swiping your fingers over the Touchpad > Press the Function button > Press 3 to delete user > Please login as Administrator - enter the Administrator code of fingerprint > Verified Successfully When deleting users from the Touchpad, you must delete all owners / family members or all visitors.
- Page 9 Set Volume - press 6 > Wake the device by swiping your fingers over the Touchpad > Press the Function button > Press 6 to adjust volume - Press 6 - Volume High Press to confirm Press to confirm - Press 6 - Volume Low Press to confirm - Operation Successful...
- Page 10 Integrated door sensor The SECURAM EOS Fingerprint Door Lock is equipped with an optional integrated door sensor to detect door open/closed position. To set up the door sensor, slide the sensor slider from the back of interior assembly. You may need to remove the interior assembly from the door to slide the sensor slider.
- Page 11 Resetting to default The lock can be reset to default by pressing the reset button on the front of the interior assembly. Open the battery compartment Find the red reset button (see diagram below) Using a paper clip, press and hold the reset button inside the reset hole for approximately 5 seconds.
- Page 12 Even though the touchpad is disabled, fingerprints can still open the lock. Low Battery Under low battery conditions, the SECURAM EOS fingerprint door lock will provide a low battery warning upon code or fingerprint entry. The lock will unlock with the voice warning “Low Battery”, and the low battery indicator flashes red.
-
Page 13: Specifications
Override Key The SECURAM EOS fingerprint door lock is equipped with a mechanical override key to open the lock. Insert the key and turn to unlock. Strike Plate & Security Box (Optional) Inside the package you will find the strike plate and security box. Install the strike plate on the jamb of the door to receive the deadbolt. -
Page 14: Operating Environment
Clean the device with a dry towel. Warranty SECURAM EOS fingerprint door lock is protected by a 12-month warranty against Manufac- turer’s defects. This warranty is applicable for 12 months from the Date of Manufacture or 12 months from the Date of Consumer Purchase. - Page 15 FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 16 SECURAM Systems, Inc.
