Aiphone PanTilt MY Series Installation & Operation Manual

83634400 0595
®
® AIPHONE
PanTilt MY Series \
VIDEO-MONITOR, single entry
Models:
V____
MY-CU
MYH-CU
INSTALLATION & OPERATION MANUAL
CONTENTS
1 SYSTEM OUTLINE & COMPONENTS. 1
2 NAMES & FEATURES.
3
PRECAUTIONS ON INSTALLATION & WIRING.
4
WIRING. 4 ~
5
MOUNTING. 1
6 OPERATIONS on MY-CU & MYH-CU. 11
7
BEFORE ASKING FOR REPAIR. 12
8 SPECIFICATIONS. 12
1 SYSTEM OUTLINE & COMPONENTS -
MY-CU is a video monitor unit to enable an intercom to verify callers at a single PanTilt entry.
MYH-CU is a sub-monitor, to increase monitor location.
PanTilt door MY-CU MYH-CU 1 MYH-CU 2
station
■ Components available
MY-CU MYH-CU
Identically designed with Pan/tilt control pad.
★ Prerun 8-conductor cable to extend
distance to MYH-CU 2. (See page 12)
■ Package contents
• Video-monitor (MY-CU or MYH-CU)
• Mounting template
• Packet of screws
• Installation & Operation Manual
-
