English version
MO128 SWEEX ISDN MODEM 128K PCI
Introduction
First of all, many thanks for purchasing this Sweex ISDN PCI adapter. To ensure this product operates correctly, we advise you to carefully read this
manual first. If despite this manual you still experience problems during installation or operation of this product, go to sweex.com and look under the
heading service & support.
Contents of the box
Prior to installation, check if all required parts are present. The following parts must be present in the box:
• ISDN PCI adapter
• RJ-45 Cable
• CD-ROM with RVS-COM Lite and Panda antivirus trial software
• CD-ROM with manual and drivers
If one of the above parts is missing, please contact the supplier.
Specifications
• Cologne chipset
• Plug and Play
• Data transfer up to 128 Kbps
• Multilink PPP combines the two ISDN lines up to 128K
• Supports: Windows 98SE, 2000 and XP
Additional specifications
• ISDN Interface: S/T Interface ITU-T I.430
• ISDN Standard: automatic (euro ISDN)
• B-channel protocol: ML-PPP asynchronous to synchronous HDLC transparent, PPP asynchronous to synchronous HDLC transparent
S W E E X . C O M
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SWEEX MO128 - QUICK_START_GUIDE
Summary of Contents for SWEEX MO128 - QUICK_START_GUIDE
-
Page 1: Specifications
Introduction First of all, many thanks for purchasing this Sweex ISDN PCI adapter. To ensure this product operates correctly, we advise you to carefully read this manual first. If despite this manual you still experience problems during installation or operation of this product, go to sweex.com and look under the heading service &... -
Page 2: English Version
PC casing. Make sure that you minimise contact with any contact points of the PC Card or the memory. 5. Find a vacant PCI slot and remove the metal guard plate part of the computer casing in front of the relevant slot. On occasion the card does not allow to be inserted in the PCI slot smoothly. - Page 3 Insert the Sweex CD-ROM in the CD-ROM player and click “Next” (Next). Or click “Browse” (Browse). Select the CD-ROM drive and the folder “98me2kxp” and click “OK” (OK). You will then be led back to the above screen. Here click “Next” (Next).
- Page 4 Subsequently, you will be prompted to restart the PC. Having restarted to PC, the following screen will appear. Here select EURO-ISDN (DSS1) and click “Next” (Next). In the following two screens you will be given the opportunity to submit your ISDN number. You can also leave it blank and click “Next” (Next).
- Page 5 Click “Finish” (Finish). When prompted, insert the Windows 98SE CD-ROM into your CD-ROM drive. In the following screen, type “X:\win98 “ (X being the letter of your CD-ROM drive which will be different from this example). Click “OK” (OK). Click on “Finish” (Finish) to complete the installation.
- Page 6 Windows 2000 and XP installation After the card has been installed in the system, switch on the PC. Windows will detect the card and show the following screen. Here select “No, not this time” (No, not this time) and click “Next” (Next).
- Page 7 Insert the Sweex CD-ROM in the CD-ROM player and click “Next” (Next). Sweex extensively tests the drivers of all its products. Here click “Continue Anyway” (Continue Anyway) to confirm the logo test. Select European ISDN (DSS1) and click “Next” (Next).
- Page 8 English version Here submit your ISDN number. You can also leave it blank and click “Next” (Next). Click “Finish” (Finish). In the following screens click “Finish” (Finish). to complete and “Next” (Next) to set up the installation process.
-
Page 9: Warranty
Warranty All products under the Sweex brand are warranted for a period of three years. We do not grant support or warranties for any software and/or (rechargeable) batteries included. Warranty claims are only settled via the dealer where the product concerned was purchased.
