Manual
Congratultions on the purchase of your double lock seamer.
These instructions will help you to use the device safely & effectively!
Read, observe and follow this manual
and the other applicable documents,
especially all safety instructions and
warnings. Keep the manual for future
consultation.
Double lock hand seamer
Item no.:
Seam height
91515-1
from 25 mm/1"
91515-1S1
from 25 mm/1"
Max Draenert Apparatebau GmbH & Co. KG
Gutenbergstrasse 15-17
D-73779 Deizisau
K7 & K7S1
K7
Closing length Length
210 mm
210 mm
: +49-(0)7153-82170
:
@: info@dracotools.com
Always wear protective gloves!
K7S1
with swivelling lever
Width
310 mm 320-610 mm 3,08 kg
310 mm 320-610 mm 3,04 kg
www.dracotools.com
Weight
Advertisement
Related Manuals for Draco K7
Summary of Contents for Draco K7
- Page 1 Always wear protective gloves! and the other applicable documents, especially all safety instructions and warnings. Keep the manual for future consultation. Double lock hand seamer K7 & K7S1 K7S1 with swivelling lever Item no.: Seam height Closing length Length Width...
- Page 2 E Side guides (L+R) K7S1 2. Intended use The K7 & K7S1 double lock hand seamer can only be used to manually close of the pre-closed standing seam to a double standing seam in the material thicknesses mentioned under point 3.
- Page 3 7. Spare parts K7 (lever BGKH70025) & K7S1 (swivelling lever BGKH70070)
- Page 4 Fig. 1: Starting position: Eccentric lever in "OPEN" position (parallel to seam) and closing handle in open position. Place the K7-1 like here shown on the seam. Fig. 2: 2.1 Eccentric lever in "CLOSED" position (parallel to Apply handle) so that both clamping hooks are locked under the standing seam.
