6. Maintenance
All parts of the hand seamer are standardized, exchangeable,
made of rustproof materials and thus largely maintenance-free.
The two side guides (KH70016+KH70017see previous page)
should be lubricated with grease periodically.
7. Accessories and additional tools
To close the double lock seam you need the
double lock hand seamer K7-1. The K7-1
closes the preclosed standing seam
(closed by the K8) into a double lock seam in
one operation, item no.: 91515-1.
Swiveling handle #BGKH70070 can also be ordered to retrofit
the K6, K7 or K8.
Max Draenert Apparatebau GmbH & Co. KG
Gutenbergstrasse 15-17
D-73779 Deizisau
:
+49-(0)7153-82170
:
www.dracotools.com
@:
info@dracotools.com
Manual
Read, observe and follow this manual
and the other applicable documents,
especially all safety instructions and
warnings.
Standing seam closer
Item no.
Closing length Length
91520S1
210 mm
Max Draenert Apparatebau GmbH & Co. KG
Gutenbergstrasse 15-17
D-73779 Deizisau
Always wear
protective gloves!
K8 S1
Width
Weight
255 mm
270-570 mm
2,4 kg
:
+49-(0)7153-82170
:
www.dracotools.com
@:
info@dracotools.com
