ESTEAM CLEANING SYSTEMS
DEFENDER 200D MODELS
OWNER'S MANUAL
Congratulations on your selection of a new Defender portable carpet cleaner built in
Canada by Esteam Cleaning Systems. Our goal is to produce the best, high
performance line of carpet cleaning equipment on the market today. Reading your
Owner's Manual will help to achieve maximum benefit from your purchase.
1
Advertisement
Table of Contents
Related Manuals for Esteam Cleaning Systems Defender 200D
Summary of Contents for Esteam Cleaning Systems Defender 200D
- Page 1 OWNER’S MANUAL Congratulations on your selection of a new Defender portable carpet cleaner built in Canada by Esteam Cleaning Systems. Our goal is to produce the best, high performance line of carpet cleaning equipment on the market today. Reading your...
-
Page 2: Table Of Contents
• Warranty • Defender 200D Drawings & Parts Lists • Defender 200D With Heat Drawings & Parts Lists • Internal Heatermate • Defender 200D 2 – 3 Stage Drawings & Parts List • 200PSI Diaphragm Pump Drawings & Parts List... -
Page 3: Introduction
Years of experience, engineering, and planning have gone into the design and manufacturing of the Defender 200D. We take great pride in our equipment; our goal is no less than your complete satisfaction. -
Page 4: Technical Specifications
Technical Specifications Defender 200D Defender 200D-05 Defender 200D-10 Defender 200D-20-05 Defender 200D-20-10 Defender 200D-20 ELECTRICAL One cord Two cords Two cords Amps 115 amps 15 amps per cord 15 amps per cord Volts 115 volts or 220 volts 115 volts or 220 volts... -
Page 5: Safety
• The two power cords must be plugged into separate circuits during operation. • Do not use the DEFENDER 200D outdoors, in standing water or on wet surfaces. Do not store the DEFENDER 200D in wet conditions. If extractor is leaking, unplug machine power cords from outlets before approaching or touching machine. - Page 6 (32ºF or 0ºC). If you suspect the Defender 200D has been frozen, do not plug in or turn on machine until you are sure it has thawed completely. • If the equipment cannot be stored or transported in a warm environment, it can be guarded from freezing by running an anti-freeze solution through the incoming water lines, solution pump, solution lines, tools.
-
Page 7: Operations
Operation Procedures Knowledge of the proper operation of the Defender 200D is required to ensure user safety and efficient performance of the extractor. SET UP AND OPERATION 1. Insert electrical cords into 3 pin grounded outlets. Two cord machines maybe equipped with the Optional Circuit Indicator located above the Switch Plate. - Page 8 cord. C. Turn the heater switch on. D. When the red light goes out, the solution is heated and ready to use. OPERATING INSTRUCTIONS (CONTINUED) WARNING: If your heater does not work DO NOT attempt to repair it yourself, call your distributor for repair procedures.
-
Page 9: Maintenance
WARNING: When using electrical equipment around water it is important to wear rubber soled shoes and keep machine properly grounded at all times. Failure to do so could result in electric shock. MAINTENANCE DAILY: - Clean high water level float screen inside the recovery tank. - Ensure high level float ball is working properly. -
Page 10: Optional Equipment
Optional strap for larger wands available Other Tool & Hose Storage Each side of the Defender 200D has a set of molded in threaded inserts to which holders can be attached to hold other accessories or supplies making it much easier to move around. -
Page 11: Trouble Shooting
TROUBLE SHOOTING WARNING: Prior to inspection or repair of this machine, disconnect all electrical cords rendering the machine powerless. Failure to do so could result in serious or fatal injury. PROBLEM CAUSE SOLUTION 1. Entire unit will not 1. Unit not plugged in 1. - Page 12 TROUBLE SHOOTING (CONTINUED) PROBLEM CAUSE SOLUTION 5.Pump runs but 1. Partial kink in solution hose 1. Remove kink has loss pressure 2. Partial blockage in solution 2. Remove blockage hose 3. Jet orifice opening on clean- 3. Total jet opening for 200 ing wand is too large PSI pump should be .06 or 08.
- Page 13 TROUBLE SHOOTING (CONTINUED) PROBLEM CAUSE SOLUTION 8. Machine spits water 1. High level float not working 1. Check auto shut off float out of exhaust port properly cage and ball for proper operation 9. Machine blowing 1. Damaged (leaking) 1. Immediately shut unit excessive amounts of recovery tank fittings down.
-
Page 14: Warranty
ESTEAM® CLEANING SYSTEMS DEFENDER EXTRACTOR WARRANTY NOTICE: REVIEW THIS WARRANTY CAREFULLY AS THIS DOCUMENT CONTAINS LIMITATIONS AND EXCLUSIONS. PART I: Esteam Manufacturing. (hereinafter referred to as "Esteam") warrants each new Defender Extractor, subject to the limitations as defined in the specific details of its warranty coverage defined below. LIMITED HOUSING WARRANTY COVERAGE: Esteam warrants the Defender Polyethylene Machine Housing Unit to be free from defects in material and workmanship (including cracking, leaking or deterioration) for three years, expressly subject to the limitations stated herein. - Page 15 PART II - REPLACEMENT PARTS (UNDER WARRANTY) Replacement warranty parts will be genuine Esteam parts, or parts of similar kind and quality. All replacement warranty parts are warranted to be free from defects in materials or workmanship from the date of the original unit purchase for the balance of the original warranty period namely: 90 days, 12 months, or the Limited Warranty, whichever is applicable;...
- Page 16 warranties. Esteam, its officers, directors, agents, dealers and its affiliates (and their respective officers, directors, agents and dealers) shall not be liable to the customer nor to any party for any liability, including without limitation, strict liability, liability for loss, injury or damage due directly or indirectly to the use or operation of the Esteam product;...
- Page 17 Require use of a defoamer. A vacuum motor showing moisture contamination on interior components shall void any warranty by Esteam. Pumps: All pumps require daily flushing with clean water after use. Internal Heatermate: The internal heater must be flushed with clean water after every use. Any buildup of hard water deposits or chemical buildup within the internal heater will void any Esteam warranty thusly exclude any liability of Esteam.
-
Page 18: Defender 200D Drawings & Parts Lists
Ninja 200D... - Page 19 Ninja 200D...
- Page 20 Ninja 200D...
- Page 21 Ninja 200D...
- Page 22 Ninja 200D...
- Page 23 Ninja 200D...
- Page 24 Ninja 200D...
- Page 25 Ninja 200D...
- Page 26 Ninja 200D...
- Page 27 Ninja 200D...
- Page 28 Ninja 200D...
- Page 29 Ninja 200D...
-
Page 30: Defender 200D With Heat Drawings & Parts Lists
Ninja 200D With Heat... - Page 31 Ninja 200D With Heat...
- Page 32 Ninja 200D With Heat...
- Page 33 Ninja 200D With Heat...
- Page 34 Ninja 200D With Heat...
- Page 35 Ninja 200D With Heat...
- Page 36 Ninja 200D With Heat...
- Page 37 Ninja 200D With Heat...
- Page 38 Ninja 200D With Heat...
- Page 39 Ninja 200D With Heat...
- Page 40 Ninja 200D With Heat...
- Page 41 Ninja 200D With Heat...
-
Page 44: Defender 200D 2 - 3 Stage Drawings & Parts List
Ninja 200D 2 – 3 Stage... - Page 45 Ninja 200D 2 – 3 Stage...
- Page 46 Ninja 200D 2 – 3 Stage...
- Page 47 Ninja 200D 2 – 3 Stage...
- Page 48 Ninja20 D2 – 3 Stage...
- Page 49 Ninja 200D 2 – 3 Stage...
- Page 50 Ninja 200D 2 – 3 Stage...
- Page 51 Ninja 200D 2 – 3 Stage...
- Page 52 Ninja 200D 2 – 3 Stage...
- Page 53 Ninja 200D 2 – 3 Stage...
- Page 54 Ninja 200D 2 – 3 Stage...
- Page 55 Ninja 200D 2 – 3 Stage...
