- Page 1 EASControl Land Rover Discovery 3/LR3 2004-2009 By User manual Firmware/Document version: 2.15.01...
- Page 2 Disclaimers Neither the distributor (Britpart -Border Holdings (UK) Ltd- and its resellers) nor the manufacturer (GAP Diagnostic, Inc.) accept any responsibility or liability for damages incurred through use of the EASControl. This includes all damages and/or personal in- juries to the vehicle itself, vehicle systems, the user or other persons and property. The warranty is limited to the functionality of the EASControl itself (for further warranty de- tails, please consult the last page of this document).
- Page 3 Those who use these proce- dures shall accept all responsibility for performing the work which may be described below. GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009...
-
Page 4: Table Of Contents
GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009 ... - Page 5 EAS : Electronic Air Suspension. This defines all the component of the air suspension system. GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009 ...
-
Page 6: Getting Started
1. Speed + = Menu up / increase value 2. Speed - = Menu down / decrease value 3. Resume = Enter 4. On/Off = Back one level / Exit GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009 ... - Page 7 Information is displayed in the instrument cluster message center. Due to limited space, longer messages such as error codes are scrolled through automatically. GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009 ...
- Page 8 The OBD connector is located at the bottom dash panel above and outside the brake pedal on the driver's side of the vehicle. GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009 ...
- Page 9 Once the unlock code is entered correctly, the Back Up done message will ap- pear and the unit will enter the menu. GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009...
- Page 10 (s), connect the EASControl to a new vehicle and follow the procedure above to activate the EASControl for the new VIN. When you access the GAP Diagnostic website to receive your unlock code you will be asked to enter your new VIN li- cense as well.
-
Page 11: Using The Eascontrol
When these functions are used again later, a press of the resume button can- cels the warning message. By Pressing the resume button, the user acknowledge that he has read and understood the warnings. GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009 ... -
Page 12: Menu Tree
III. Menu tree Land Rover Discovery 3/LR3 2004-2009 GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009 ... -
Page 13: Top Level Menu Options
5A27: Numeric DTC diagnostic trouble code designation. Compressor circuit: Plain English fault descriptor. This particular fault indicates a pos- sible defect in the electric circuit supplying the EAS compressor. GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009... - Page 14 In this condition, there is no suspension travel. There is severe risk of damage and the vehicle can become uncon- trollable in this state! GAP Diagnostic assumes no liability for damages oc- curred in using the EASControl.
- Page 15 Changes the height of only the rear axle in all modes. -10mm means the rear will be 10mm lower than the front in all modes. GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009...
- Page 16 The rear can be raised by a maximum of 250 - 195 = 55 mm.The rear can be lowered by a maximum of 183 - 150 = 33 mm. The EASControl automatically calculates these values and allows only changes within these parameters. GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009 ...
- Page 17 2. Use the EASControl to take note of the actual calibration. GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009...
- Page 18 Navigate to 'Heights'> Standard > Adjust Front' or 'Heights > Standard > Adjust Rear' and use the + / - buttons to adjust the value. GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009...
- Page 19 A correct calibration is achieved when the measured values are equal on each side. GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009...
- Page 20 After entering your unlock code, when connecting to another vehicle that’s never been unlocked, you will be asked if you want your EASControl to be unlocked for this particu- lar vehicle. GAP Diagnostic 2012-02-01 All right reserved EASControl User manual: 2.15.01 Land Rover Discovery 3/LR3 2004-2009 ...
-
Page 21: Limited Warranty
Limited Warranty GAP Diagnostic warranties this product for 2 full years after the date of purchase. The warranty covers only the EASControl of the original purchaser (non transferable). It covers manufacturing and workmanship defects for the duration defined above. The warranty is limited to the functionality of the system and the system itself.
