M-system KWSBS Instruction Manual

Analog subtractor

Advertisement

Quick Links

INSTRUCTION MANUAL
ANALOG SUBTRACTOR
BEFORE USE ....
Thank you for choosing M-System. Before use, check con-
tents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact M-System's Sales Office or representatives.
PACKAGE INCLUDES:
Signal conditioner (body + base socket) ..................... (1)
MODEL NO.
Check that model No. described on specification label is
exactly what you ordered.
INSTRUCTION MANUAL
This manual describes necessary points of caution when you
use this product, including installation, connection and basic
maintenance procedures.
COMPONENT IDENTIFICATION
Body
Specification
Label
Zero Adj.
Ch.1
Span Adj.
Zero Adj.
Ch.2
Span Adj.
(two isolated outputs)
Base Socket
MODEL
INSTALLATION
Detach the yellow clamps located at the top and bottom of the
unit for separating the body from the base socket.
DIN RAIL MOUNTING
Set the base socket so that its
DIN rail adaptor is at the bot-
tom. Position the upper hook
at the rear side of base socket
on the DIN rail and push in the
lower.
When removing the
socket, push down the DIN rail
adaptor utilizing a minus
screwdriver and pull.
WALL MOUNTING
Refer to the drawings in the
following page.
KWSBS
KWSBS
Clamp
(top & bottom)
DIN Rail
35mm wide
Spring Loaded
DIN Rail Adaptor
Shape and size of the base socket
are slightly different with various
socket types.
P. 1 / 3
EM-3640

Advertisement

loading
Need help?

Need help?

Do you have a question about the KWSBS and is the answer not in the manual?

Questions and answers

Summary of Contents for M-system KWSBS

  • Page 1 (two isolated outputs) BEFORE USE ..INSTALLATION Thank you for choosing M-System. Before use, check con- Detach the yellow clamps located at the top and bottom of the tents of the package you received as outlined below. unit for separating the body from the base socket.
  • Page 2 KWSBS TERMINAL CONNECTIONS Connect the unit as in the diagram below or refer to the connection diagram label on the front of the unit. DIMENSIONS mm (inch) CLAMP (top & bottom) 7.8 (.31) DIN RAIL 35mm wide 2–4.5 (.18) dia.
  • Page 3 M-System's sole liability, and purchaser's exclusive remedies, under this warranty are, at M-System's option, the repair, replacement or refund of the purchase price of any M-System product which is defective under the terms of this warranty. To submit a claim under this warranty, the purchaser must return, at its expense, the defective M-System product to the below address together with a copy of its original sales invoice.
