Jabra Pro 9470 Mono
How to connect my Jabra PRO 9400 / GO 6400 with Avaya
1408, 1416, 1608, 1616, 9404, 9408, 9504, 9508, 9608, 9610,
9611G, 9620, 9620C, 9620L, 9621G, 9630, 9630G, 9640C,
9640G, 9641G, 9650, 9650C, 9670
Prerequisite:
Jabra PRO 9460 / 9470 + Jabra Link 14201-20
In combination with one of the following Avaya phones:
1408 / 1416
1608 / 1616
9404 / 9408
9504 / 9508
9608 / 9610 / 9611G / 9620 / 9620C / 9620L / 9621G
9630 / 9630G / 9640C / 9640G / 9641G / 9650 / 9650C / 9670
Connection:
1. Plug the supplied RJ9 to RJ9 connection cable into the socket
marked "phone" on your Jabra PRO 94x0 base and the other end to
the socket marked with a "phone" symbol on the EHS adapter.
2. Now connect the cable marked red to the socket marked "AUX" on
the EHS adapter and to the "AUX" socket on your Jabra PRO 94x0
base.
3. Now connect the cable marked white "C" to the socket marked
"Headset/handset" on the EHS adapter and to the "headset" socket
on your phone.
4. Important: If you have a 1408/1416 or 9404/9408 phone, you should
use the cable marked white "A" (instead of the "C" cable).
https://www.jabra.co.uk/supportpages/jabra-pro-9470/9470-26-904-
102/faq/8fe604fe-a271-4ae5-9e1a-af95d0606785
11/07/2024 02:16
Page 1 of 4
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Jabra Pro 9470 Mono
Summary of Contents for Jabra Pro 9470 Mono
- Page 1 Connection: 1. Plug the supplied RJ9 to RJ9 connection cable into the socket marked "phone" on your Jabra PRO 94x0 base and the other end to the socket marked with a "phone" symbol on the EHS adapter. 2. Now connect the cable marked red to the socket marked "AUX" on the EHS adapter and to the "AUX"...
- Page 2 Please be aware that the device will not be fully functional until the coloured markings for all cables have been connected to the EHS adapter, see photo. Then follow the instructions on the Jabra PRO 94x0 base SmartSetup Wizard. Select the phone setting "Desk phone", then "Connect to a desk phone?", "Manual".
- Page 3 Set the phone set-up switch to position "A". Microphone level setup: We recommend setting the microphone volume to 7 out of 13. Guided setup: As part of the installation, you can dial into your local Jabra Setup https://www.jabra.co.uk/supportpages/jabra-pro-9470/9470-26-904- Page 3 of 4 102/faq/8fe604fe-a271-4ae5-9e1a-af95d0606785...
- Page 4 11/07/2024 02:16 Server, which will configure the audio path. Please follow the instructions shown on the display. If your Jabra Setup Server is unavailable, please contact your local Jabra support team. https://www.jabra.co.uk/supportpages/jabra-pro-9470/9470-26-904- Page 4 of 4 102/faq/8fe604fe-a271-4ae5-9e1a-af95d0606785...
