INTERFACE CONNECTIONS
The AMG110-2X-SP features two
independant surge protection
channels in a single unit. These
channels are clearly labelled as
"P1" and "P2" on the front panel.
① Connect the Ethernet devices
that you would like to protect
to the Protected Ports shown in
yellow and labelled as "OUT".
② Connect the long external
Ethernet cables that could be
susceptable to surge or transients
to the ports labelled as "IN".
APPLICATION DIAGRAM
CAT5e 1Gb
Ground Point
PoE 30W
PoE 90W
Surge Protected
PoE Port
AMG110
AMG570
2X-SP
AMG Systems Ltd. 4 Pioneer Way, Castleford, WF10 5QU, UK T: +44 (0) 1767 600 777 E: technical@amgsystems.com
AMG Systems Inc. 62 Spring Hill Road, Trumbull, CT 06611, USA T: +1-855-AMGPOE1 (855-264-7631)
D35164-00
100M (328 ft.)
AMG110M
1X-SP
100M (328 ft.)
AMG110M
1X-SP
www.amgsystems.com
AMG110-2X-SP
AMG110-2X-SP
Industrial Dual Channel
Industrial Dual Channel
PoE Surge Protector
PoE Surge Protector
Installation Manual - Hardware
Installation Manual - Hardware
amgsystems.com
