INTERFACE CONNECTIONS
The AMG110M-1X-SP features a
single surge protection channel in
a mini sized unit.
① Connect the Ethernet device
that you would like to protect
to the Protected Port shown in
yellow and labelled as "OUT".
② Connect the long external
Ethernet cable that could be
susceptable to surge or transients
to the port labelled as "IN".
APPLICATION DIAGRAM
CAT5e 1Gb
Ground Point
PoE 30W
PoE 90W
Surge Protected
PoE Port
AMG110
AMG570
2X-SP
AMG Systems Ltd. 4 Pioneer Way, Castleford, WF10 5QU, UK T: +44 (0) 1767 600 777 E: technical@amgsystems.com
AMG Systems Inc. 62 Spring Hill Road, Trumbull, CT 06611, USA T: +1-855-AMGPOE1 (855-264-7631)
D35163-00
100M (328 ft.)
AMG110M
1X-SP
100M (328 ft.)
AMG110M
1X-SP
www.amgsystems.com
AMG110M-1X-SP
AMG110M-1X-SP
Industrial Mini
Industrial Mini
PoE Surge Protector
PoE Surge Protector
Installation Manual - Hardware
Installation Manual - Hardware
