Product Overview
Front View
Internal View
1
3
2
4
5
1. Cup Rack
2. Spray Arm
(one under the
upper and one
under the lower
basket)
3. Upper Basket
Control
panel
Door handle
Mains cable
4. Salt Reservoir
5. Rinse Aid Reservoir
6. Detergent Dispenser
7. Filtering System
8. Lower Basket
9. Cutlery Basket
Rear View
9
4
7
8
2
7
6
Water inlet
(connect to
supply hose)
Drain hose
15
