PROLiNK Professional II Series User Manual

Tower & rack types
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Guide
Professional II/II+ Series (1P/1P)
Tower & Rack Types
PRO900-WS/WL & PRO900-WRS/WRL
PRO900-ES/EL & PRO900-ERS/ERL
1-3KVA
Version 4.20
(English)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Professional II Series and is the answer not in the manual?

Questions and answers

Related Manuals for PROLiNK Professional II Series

Summary of Contents for PROLiNK Professional II Series

  • Page 1 User Guide Professional II/II+ Series (1P/1P) Tower & Rack Types PRO900-WS/WL & PRO900-WRS/WRL PRO900-ES/EL & PRO900-ERS/ERL 1-3KVA Version 4.20 (English)

  • Page 2: Table Of Contents

    Table of Contents 1. Important Safety Warning ....................1 1-1. Transportation ........................1 1-2. Preparation ........................1 1-3. Installation ......................... 1 1-4. Operation .......................... 1 1-5. Maintenance, Service and Faults ................... 2 2. Installation and Setup ......................3 2-1. Rear Panel View ....................... 3 2-2.

  • Page 3: Important Safety Warning

    1. Important Safety Warning Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully 1-1.

  • Page 4: Maintenance, Service And Faults

    1-5. Maintenance, Service and Faults The UPS system operates with hazardous voltages. Repairs may be carried out only by  qualified maintenance personnel. Caution - risk of electric shock. Even after the unit is disconnected from the mains  (building wiring outlet), components inside the UPS system are still connected to the battery and electrically live and dangerous.

  • Page 5: Installation And Setup

    2. Installation and Setup NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep the original package in a safe place for future use. This package should contain: One UPS One input power cord •...
  • Page 6 Argentina Type UK Type NEMA Type PRO903-WS / PRO903-ES India Type IEC Type Schuko Type Universal Type Argentina Type UK Type NEMA Type IEC Type II PRO901-WL / PRO901-EL India Type IEC Type Schuko Type Universal Type...
  • Page 7 Argentina Type UK Type PRO902-WL India Type IEC Type Schuko Type Universal Type Argentina Type UK Type PRO902-EL India Type IEC Type Schuko Type Universal Type...
  • Page 8 Argentina Type UK Type PRO903-WL India Type IEC Type Schuko Type Universal Type Argentina Type UK Type PRO903-EL India Type IEC Type Schuko Type Universal Type...
  • Page 9 Argentina Type UK Type PRO901-WRS / PRO901-ERS IEC Type Universal Type IEC + Universal Type Schuko Type India Type NEMA Type NEMA Type Argentina Type...
  • Page 10 PRO902-WRS / PRO902-ERS IEC Type Universal Type IEC + Universal Type Schuko Type India Type NEMA Type NEMA Type Argentina Type PRO903-WRS / PRO903-ERS IEC Type IEC Type Universal Type Schuko Type...
  • Page 11 India Type NEMA Type NEMA Type Argentina Type PRO901-WRL / PRO901-ERL IEC Type Universal Type Schuko Type India Type Argentina Type PRO902-WRL IEC Type Universal Type...
  • Page 12 Schuko Type India Type Argentina Type PRO902-ERL IEC Type Universal Type Schuko Type India Type Argentina Type PRO903-WRL / PRO903-ERL IEC Type I IEC Type II...

  • Page 13: Ups Installation Guide

    Universal Type Schuko Type India Type Argentina Type 1. AC input 2. Input circuit breaker 3. USB communication port 4. RS-232 communication port 5. SNMP intelligent slot (option) 6. External battery connection (only available for L model) 7. Output receptacles 8.

  • Page 14: Operating Principle

    Place UPS: It’s equipped with fan for cooling. Therefore, place the UPS in a well-ventilated area. It’s required to maintain minimum clearance of 100mm in the front of the UPS and 300mm in the back and two sides of the UPS for heat dissipation and easy-maintenance.

  • Page 15: Setup The Ups

    Tower Installation Step 1 Step 2 Step 3 2-5. Setup the UPS Step 1: Connect battery wires If UPS is long-run model, please connect external batteries as below chart. If using rack UPS, the UPS is shipped out from factory without connecting battery wires for safety consideration.

  • Page 16: Battery Replacement (Only For Rack Ups)

    c) Upon completion of the wiring configuration, please check whether the wires are securely affixed. d) Put the small cover back to the rear panel. Step 4: Communication connection Communication port: USB port RS-232 port Intelligent slot To allow for unattended UPS shutdown/start-up and status monitoring, connect the communication cable one end to the USB/RS-232 port and the other to the communication port of your PC.

  • Page 17: Battery Kit Assembly (Option For Rack Ups)

    Step 1 Step 2 Step 3 Remove front panel. Disconnect battery wires. Pull out the battery box by removing two screws on the front panel. Step 4 Step 5 Step 6 Remove the top cover of After replacing the batteries, put Re-connect the battery wires.
  • Page 18 2-battery kit Step 1: Remove adhesive tapes. Step 2: Connect all battery terminals by following below chart. Tapes Step 3: Put assembled battery packs on one Step 4: Cover the other side of plastic shell as side of plastic shells. below chart.
  • Page 19 4-battery kit Step 1: Remove adhesive tapes. Step 2: Connect all battery terminals by following below chart. Tapes Tapes Step 3: Put assembled battery packs on one Step 4: Cover the other side of plastic shell as side of plastic shells. below chart.

  • Page 20: Operations

    3. Operations 3-1. Button Operation Button Function  Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds to turn on the UPS.  Mute the alarm: When the UPS is on battery mode, press and hold this button for at least 5 seconds to disable or enable the alarm system.
  • Page 21 Display Function Remaining backup time information Indicates the remaining backup time in pie chart. Indicates the remaining backup time in numbers. H: hours, M: minute, S: second Fault information Indicates that the warning and fault occurs. Indicates the warning and fault codes, and the codes are listed in details in 3-5 section.

  • Page 22: Audible Alarm

    3-3. Audible Alarm Battery Mode Sounding every 4 seconds Low Battery Sounding every second Overload Sounding twice every second Fault Continuously sounding Bypass Mode Sounding every 10 seconds 3-4. LCD Display Wordings Index Abbreviation Display content Meaning Enable Disable Escape High loss Low loss Battery...
  • Page 23 230: presents output voltage is 230Vac (Default) 240: presents output voltage is 240Vac 02: Frequency Converter enable/disable  Interface Setting Parameter 2 & 3: Enable or disable converter mode. You may choose the following two options: CF ENA: converter mode enable CF DIS: converter mode disable (Default) 03: Output frequency setting ...

  • Page 24: Operating Mode Description

    07: Bypass voltage range setting  Interface Setting Parameter 2 & 3: Set the acceptable high voltage point and acceptable low voltage point for Bypass mode by pressing the Down key or Up key. HLS: Bypass high voltage point For 200/208/220/230/240 VAC models: 230-264: setting the high voltage point in parameter 3 from 230Vac to 264Vac.

  • Page 25: Faults Reference Code

    Battery mode When the input voltage is beyond the acceptable range or power failure and alarm is sounding every 4 second, UPS will backup power from battery. Bypass mode When input voltage is within acceptable range but UPS is overload, UPS will enter bypass mode or bypass mode can be set by front panel.

  • Page 26: Troubleshooting

    4. Troubleshooting If the UPS system does not operate correctly, please solve the problem by using the table below. Symptom Possible cause Remedy No indication and alarm even though The AC input power is not Check if input power cord the mains is normal.

  • Page 27: Storage And Maintenance

    5. Storage and Maintenance Operation The UPS system contains no user-serviceable parts. If the battery service life (3~5 years at 25°C ambient temperature) has been exceeded, the batteries must be replaced. In this case, please contact your dealer. Be sure to deliver the spent battery to a recycling facility or ship it to your dealer in the replacement battery packing material.

  • Page 28: Specifications

    6. Specifications Tower UPS – WS/WL Series PRO903-WS / PRO901-WS / PRO902-WS / MODEL PRO902-WS -72 PRO903-WL / PRO901-WL PRO902-WL PRO903-WS-96 CAPACITY* 1000 VA / 800 W 2000 VA / 1600 W 2000 VA / 1600 W 3000 VA / 2400 W INPUT 160VAC/140VAC/120VAC/110VAC±5% Low Line Transfer...
  • Page 29 Tower UPS – ES/EL Series PRO901-ES / PRO902-ES / PRO903-ES / MODEL PRO902-ES -72 PRO901-EL PRO902-EL PRO903-EL CAPACITY* 1000 VA / 900 W 2000 VA / 1800 W 2000 VA / 1800 W 3000 VA / 2700 W INPUT 160VAC/140VAC/120VAC/110VAC±5% Low Line Transfer (Ambient Temp.<35 ( based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0)
  • Page 30 Rack UPS – WRS/WRL Series PRO901-WRS / PRO902-WRS / PRO903-WRS / MODEL PRO901-WRL PRO902-WRL PRO903-WRL CAPACITY* 1000 VA / 800 W 2000 VA / 1600 W 3000 VA / 2400 W INPUT 160VAC/140VAC/120VAC/110VAC±5% Low Line Transfer (Ambient Temp.<35 ( based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0) Voltage 175VAC/155VAC/135VAC/125VAC ±...
  • Page 31 Rack UPS – ERS/ERL Series PRO901-ERS / PRO902-ERS / PRO903-ERS / MODEL PRO901-ERL PRO902-ERL PRO903-ERL CAPACITY* 1000 VA / 900 W 2000 VA / 1800 W 3000 VA / 2700 W INPUT 160VAC/140VAC/120VAC/110VAC±5% Low Line Transfer (Ambient Temp.<35 (based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0) Voltage 175VAC/155VAC/135VAC/125VAC ±...
  • Page 32 Note: Closed on Saturdays, Sundays and local/regional Public Holidays. Register online for your Product Warranty at www.prolink2u.com Prolink is a registered trademark of Fida International (S) Pte Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. Product images are purely for illustrative purposes and may defer from the actual product.
