Ocean Safety MOB LADDER Owner's Manual

Hide thumbs

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 1

Table of Contents

OCEAN SAFETY
MOB LADDER
Owner's Manual
REV02
YOUR SAFETY
OUR WORLD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOB LADDER and is the answer not in the manual?

Questions and answers

Related Manuals for Ocean Safety MOB LADDER

Summary of Contents for Ocean Safety MOB LADDER

  • Page 1 OCEAN SAFETY MOB LADDER Owner’s Manual REV02 YOUR SAFETY OUR WORLD...

  • Page 2: Table Of Contents

    CONTENTS INTRODUCTION Features INSTALLATION OPERATION RE-PACKING CARE & MAINTENANCE ADDITIONAL LANGUAGES Owner’s Manual...

  • Page 3: Introduction P3

    1.0 INTRODUCTION 1.0.1 The Ocean Safety MOB Ladder is designed for use in a man overboard situation. Available in 3m or 4m lengths. The ladder complies with the ISO-15085 standard and should hang at least 5 rungs (1.2m) below the water line when deployed.

  • Page 4: Installation P4

    2.0 INSTALLATION 2.1 Thread the 25mm 3-Bar slide buckle through the square buckle around the guard rail. WARNING: POSITION THE VALISE WITH THE ACTIVATION LINE TOWARDS THE OUTSIDE OF THE VESSELS GUARD RAILS. THE LADDER MUST BE ABLE TO DEPLOY FULLY AND UN-RESTRICTED INTO THE WATER WARNING: POSITION THE BUCKLES IN EITHER THE FRONT OR REAR OF THE GUARD RAIL.

  • Page 5: Operation P5

    When not in use, the activation line can be stored via the slots on the rear of the valise. 3.2 Pull down on the activation 3.3 The ladder will then fall from line to deploy the ladder. the valise ready for use. MOB LADDER MOB LADDER Owner’s Manual...

  • Page 6: 4.0 Re-Packing

    4.1 Remove from the guard rail to re-pack, folding in the lengths of vertical webbing starting from the bottom of the ladder. 4.2 Once all the rungs are gathered together, push them back into the valise. MOB LADDER DETAIL VIEW A Owner’s Manual...
  • Page 7 Check the valise is securely fitted to the vessel rail. Train all crew members in the safe and correct use of the MOB ladder. When the vessel is not in use, remove the ladder and store in a dry environment to prolong the product’s life.
  • Page 8 6.1 FR 6.1.1 Introduction 6.1.1.1 L’échelle de sauvetage d’Ocean Safety est conçue pour assister aux situations d’homme à la mer. Elle existe en longueurs de 3m ou 4m. L’échelle est conforme aux normes ISO-15085 qui spécifient qu’au moins 5 échelons (1.20m) doivent tremper sous la ligne de floattaison.
  • Page 9 6.0 ADDITIONAL LANGUAGES 6.2 DE 6.2.1 Einführung 6.2.1.1 Die Ocean Safety MOB-Leiter ist für den Einsatz in einer Mann-überBord-Situation konzipiert. Erhältich in 3m oder 4m Länge. Die Leiter entspricht der Norm ISO-15085 uund sollte mindestens 5 Sprossen (1.2m) unterhalb der Wasserlinie hängen.
  • Page 10 6.3 IT 6.3.1 Introduzione 6.3.1.1 La scala di recupero Ocean Safety è progettatta per recuperare persone finite in mare. Disponibile nelle lunghezze di 3 e 4 metri. La scala è conforme con lo standard ISO- 15085 e deve essere appesa su alment 5 pioli (1.2m) sotto la linea di galleggiamento.
  • Page 11 6.4 ES 6.4.1 Introducción 6.4.1.1 La escalera de Hombre al Agua de Ocean Safety està diseñada para su utilización en situaciones donde una persona haya caído fuera. Disponible en longitudes de 3m y 4m. La escalera cumple con la norma ISO-15085 y debe colgar al menos 5 peldaños (1.2m) por debajo de la línea de flotación.
  • Page 12 OCEAN SAFETY Saxon Wharf Lower York Street Southampton Hampshire SO14 5QF Tel: +44 (0)2380 720800 Email: info@oceansafety.com Web: www.oceansafety.com YOUR SAFETY ARTOS018 REV02 OUR WORLD...
