Summary of Contents for Siemens KG49NXXDF
- Page 1 KG..N.. Fridge-freezer EN Information for Use Register your appliance on My Siemens and discover exclusive services and offers. Siemens Home Appliances...
-
Page 2: Table Of Contents
Table of contents 1 Safety ........... 4 7.3 Switching off the appliance .. 17 1.1 General information.... 4 7.4 Setting the temperature... 17 1.2 Intended use...... 4 8 Additional functions .... 17 1.3 Restriction on user group.. 4 8.1 Super cooling ...... 17 1.4 Safe transport ...... - Page 3 14 Troubleshooting...... 25 14.1 Power failure...... 28 14.2 Conducting an appliance self-test ........ 28 15 Storage and disposal.... 28 15.1 Taking the appliance out of operation ....... 28 15.2 Disposing of old appliance ... 29 16 Customer Service.... 29 16.1 Product number (E-Nr.) and production number (FD)..
-
Page 4: Safety
en Safety 1 Safety Observe the following safety instructions. 1.1 General information Read this instruction manual carefully. ¡ Keep the instruction manual and the product information safe ¡ for future reference or for the next owner. Do not connect the appliance if it has been damaged in transit. ¡... -
Page 5: Safe Installation
Safety en 1.5 Safe installation WARNING ‒ Risk of electric shock! Incorrect installation is dangerous. Connect and operate the appliance only in accordance with the ▶ specifications on the rating plate. Connect the appliance to a power supply with alternating cur- ▶ rent only via a properly installed socket with earthing. The protective conductor system of the domestic electrical in- ▶... -
Page 6: Safe Use
en Safety Portable multiple socket strips or portable power supply units may overheat and cause a fire. Do not place portable multiple socket strips or power supply ▶ units on the back of the appliance. 1.6 Safe use WARNING ‒ Risk of electric shock! An ingress of moisture can cause an electric shock. - Page 7 Safety en WARNING ‒ Risk of fire! Electrical devices within the appliance may cause a fire, e.g. heat- ers or electric ice makers. Do not operate electrical devices within the appliance. ▶ WARNING ‒ Risk of injury! Containers that contain carbonated drinks may burst. Do not store containers that contain carbonated drinks in the ▶...
-
Page 8: Damaged Appliance
en Safety Store raw meat and fish in suitable containers in the refrigerator ▶ so that they do not touch or drip on other food. If the fridge/freezer is empty for an extended period of time, ▶ switch off the appliance, defrost it, clean it and leave the door open to prevent the formation of mould. - Page 9 Safety en Unplug the mains plug from the mains or switch off the circuit ▶ breaker in the fuse box. Call customer service. → Page 29 ▶...
-
Page 10: Preventing Material Damage
en Preventing material damage Preventing material damage Environmental protection and saving energy 2 Preventing material 3 Environmental protec- damage tion and saving energy Preventing material damage Environmental protection and saving energy ATTENTION! 3.1 Disposing of packaging If not rolling freely, the appliance's The packaging materials are environ- castors may damage the floor when mentally compatible and can be re- the appliance is moved. -
Page 11: Installation And Connection
Installation and connection en Allow warm food and drinks to ¡ 4.2 Criteria for the installation cool down before storing them. location Thaw frozen food in the refrigerator ¡ compartment to utilise the low tem- WARNING perature of the food. Risk of explosion! Always leave some space between ¡... -
Page 12: Installing The Appliance
en Installation and connection 4.3 Installing the appliance Install the appliance in accordance ▶ with the enclosed installation in- structions. 4.4 Preparing the appliance for the first time Remove the informative material. Remove the protective foil and transit bolts, e.g. remove the ad- hesive strips and carton. -
Page 13: Familiarising Yourself With Your Appliance
Familiarising yourself with your appliance en Familiarising yourself with your appliance 5 Familiarising yourself with your appliance Familiarising yourself with your appliance 5.1 Appliance You can find an overview of the parts of your appliance here. Refrigerator compartment Lighting → Page 20 Bottle shelf → Page 15 Freezer compartment → Page 21 Storage container... -
Page 14: Control Panel
en Familiarising yourself with your appliance 5.2 Control panel Fruit and vegetable container → Page 15 You can use the control panel to con- Rating plate → Page 30 figure all functions of your appliance and to obtain information about the Frozen food container operating status. → Page 24 Screw foot Control panel → Page 14... -
Page 15: Features
Features en 6.3 Storage container Displays the set temperature for the refrigerator compart- The temperatures in the storage con- ment in °C. tainer are lower than in the refriger- super (Refrigerator compart- ator compartment. Temperatures be- ment) switches Super cooling low 0 °C may occur occasionally. on or off. -
Page 16: Door Tray
en Basic operation To loosen the ice cubes, twist the 6.5 Door tray ice cube tray slightly or hold it To adjust the door tray as required, briefly under flowing water. you can remove the door tray and re- insert elsewhere. → "Removing door tray", Page 23 Basic operation 7 Basic operation 6.6 Accessories... -
Page 17: Switching Off The Appliance
Additional functions en The temperature in the appliance Note: When Super cooling is ¡ varies due to the following condi- switched on, increased noise may tions: occur. – How often the appliance is Switching on Super cooling opened – Load capacity Press super (Refrigerator compart- ▶... -
Page 18: Manual Super Freezing
en Additional functions Deactivating automatic Super 8.4 Holiday mode freezing If you are going to be away for a long Press and hold super (Freezer ▶ time, you can switch on energy-sav- compartment) for 5 seconds. ing holiday mode on the appliance. If 3 audible signals sound, the automatic Super freezing is deac- CAUTION tivated. -
Page 19: Freshness Mode
Alarm en Switching off energy-saving mode Switching on Sabbath mode Press eco. Press and hold vacation for ▶ ▶ 15 seconds until an audible signal sounds. 8.6 Freshness mode "vacation" lights up. In order to keep the food fresh for longer, you can switch on the fresh- Note: After approx. 80 hours, the ap- ness mode on the appliance. -
Page 20: Refrigerator Compartment
en Refrigerator compartment Refreeze food only after cooking. 10.1 Tips for storing food in ▶ These items should no longer be ▶ the refrigerator compart- stored for the maximum storage ment period. Only store food when fresh and ¡ The temperature alarm can be undamaged. -
Page 21: Freezer Compartment
Freezer compartment en 11.3 Tips for storing food in Freezer compartment 11 Freezer compartment the freezer compartment You can store frozen food, freeze Freezer compartment Store food in air-tight packaging. ¡ food and make ice cubes in the Do not bring food which is to be ¡... -
Page 22: Shelf Life Of Frozen Food At −18 °C
en Defrosting Label the packaging with the con- Defrosting 12 Defrosting tents and the date of freezing. Defrosting 11.5 Shelf life of frozen food 12.1 Defrosting in the freezer at −18 °C compartment Food Storage time The fully automatic NoFrost system Fish, sausages, pre- up to ensures that the freezer compartment pared meals and 6 months... -
Page 23: Cleaning The Appliance
Cleaning and servicing en 13.2 Cleaning the appliance 13.3 Removing the fittings If you want to clean the fittings thor- WARNING oughly, remove these from your ap- Risk of electric shock! pliance. An ingress of moisture can cause an electric shock. Removing the shelf Do not use steam- or high-pres- ▶... - Page 24 en Cleaning and servicing Lift the storage container at the Lift the frozen food container at the front and remove it . front and remove it . Removing the fruit and vegetable Removing the front of the container container Pull out the fruit and vegetable You can remove the front of the fruit container as far as it will go.
-
Page 25: Troubleshooting
Troubleshooting en Troubleshooting 14 Troubleshooting You can rectify minor faults on your appliance yourself. Read the troubleshoot- Troubleshooting ing information before contacting after-sales service. This will avoid unneces- sary costs. WARNING Risk of electric shock! Improper repairs are dangerous. Repairs to the appliance should only be carried out by trained specialist ▶... - Page 26 en Troubleshooting Fault Cause and troubleshooting A warning tone The freezer compartment door is open. sounds and the tem- Close the freezer compartment door. ▶ perature display (freezer compartment) "alarm" flash. The door alarm is switched on. The temperature dis- A sensor is defective.
- Page 27 Troubleshooting en Fault Cause and troubleshooting Condensation accu- The water contained in warm and humid air con- mulates on the sur- denses on the colder surfaces of the appliance. face of the appliance Wipe away the condensation water with a soft, dry and on the shelves in- cloth.
-
Page 28: Power Failure
en Storage and disposal If, at the end of the appliance self- 14.1 Power failure test, two audible signals sound During a power failure, the temperat- and the temperature display indic- ure in the appliance rises; this re- ates the set temperature, your ap- duces the storage time and the qual- pliance is OK. -
Page 29: Disposing Of Old Appliance
Customer Service en 15.2 Disposing of old appli- Customer Service 16 Customer Service ance Function-relevant genuine spare parts Customer Service Valuable raw materials can be re- according to the corresponding Eco- used by recycling. design Order can be obtained from Customer Service for a period of at WARNING least 10 years from the date on Risk of harm to health! -
Page 30: Technical Data
en Technical data Make a note of your appliance's de- tails and the Customer Service tele- phone number to find them again quickly. Technical data 17 Technical data Refrigerant, cubic capacity and fur- Technical data ther technical specifications can be found on the rating plate. → "Appliance", Fig. - Page 32 EN Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom BSH Hausgeräte GmbH Carl-Wery-Straße 34...
