- Page 1 OWNER’S MANUAL LOC RDS 95.1 BAND /SRC LOC RDS LOC RDS 95.1 95.1 LOC RDS 95.1 LOC RDS 95.1 LOC RDS 95.1 RVM35V1 RVM-35V1 3.5" MECHLESS MULTIMEDIA SOURCE UNIT...
-
Page 2: Safety Information
SAFETY INFORMATION CAUTION Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit protect you only if you observe the following procedures for installation, use, and servicing. Notes: • Professional Installation is recommended. • Choose the mounting location where the unit will not interfere with normal driving. -
Page 3: Din Front/Rear-Mount
INSTALLATION Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, hot air, heater, or where it would be subject to dust, dirt, or excessive vibration. DIN FRONT/REAR-MOUNT This unit can be properly installed either from “Front”(conventional DIN Front-mount) or “Rear” (DIN Rear-mount installation, utilizing threaded screw holes at the sides of the unit chassis). - Page 4 CONNECTIONS FUSE V-OUT ZONE 1-R ZONE 2-R R-IN AM/FM ZONE 1-L ZONE 2-L L-IN HIGH DEFINITION THROUGHPUT PIN NO. WIRE COLOR LABEL PIN NO. WIRE COLOR LABEL PINK CAMERA BLUE ANTENNA YELLOW BATTERY+ BLACK GROUND GRAY/BLACK ZONE1 RIGHT SPK (-) WHITE/BLACK ZONE1 LEFT SPK (-) GRAY...
-
Page 5: Source Unit
SOURCE UNIT LOC RDS 95.1 BAND /SRC LOC RDS LOC RDS 95.1 95.1 LOC RDS 95.1 LOC RDS 95.1 LOC RDS 95.1 RVM35V1 1. HOME BUTTON 8. TRACK BACK 2. VOLUME + 9. TRACK FORWARD 3. VOLUME - 10. PLAY/PAUSE 4. -
Page 6: Operation
OPERATION LOC RDS TURN ON/OFF THE UNIT AND ALL MUTE FUNCTION 95.1 Press the button to turn on the unit. When the unit is on, press and hold it for 2 seconds to turn off the unit. AUDIO & MENU SETTING Repeatedly press SEL knob for the audio setting: ZONE1 BAS->... -
Page 7: Radio Operation
OPERATION SOURCE CHANGE Shortly press SRC button to change source. Also shortly press button into the main menu then click the source you want. ZONE1/ZONE2 VOLUME UP/DOWN Press “+”/”-” button to up/down both ZONE1 and ZONE2 volume. In the volume screen window, you can control ZONE1 or ZONE2 individually. -
Page 8: Repeat One/All
MUSIC/VIDEO/PHOTO PLAYING OPERATION When a USB source such as a thumb drive is inserted to the USB port on the front LOC RDS panel of the unit, it supports playback of MP3 and WMA files automatically. To select USB 95.1 as the source, press the /SRC button until the USB mode display appears. -
Page 9: Bluetooth Pairing
MUSIC/VIDEO/PHOTO PLAYING OPERATION SONG LIST The unit allows users to browse the song list. LOC RDS • Press and hold button for 2 seconds. It will list all the songs on the screen, then click the desired song to play. 95.1 VIDEO/PHOTO/MUSIC CHANGING When insert a USB to the unit it play the music for default. - Page 10 AUX IN / AV IN OPERATION VIDEO OUTPUT TO THE MONITOR The unit allows users output the video to the monitor. • While video playing, connect a TV set to the video out RCA, Press and hold BAND button, It will off the TFT screen display and output the video signal to TV set. Press and hold BAND button again to return to TFT screen to display.
- Page 11 OPERATION MANUALLY SAVE STATION & RECALL PRESET STATION Tuning to a station with button. Press and hold one of the 1- 6 preset button for LOC RDS LOC RDS 2 seconds. The current station is stored into the number button. Shortly press the preset 95.1 95.1 button (1~6) to directly listen the station that saved in the corresponding preset button.
-
Page 12: Remote Operation
REMOTE OPERATION REMOTE CONTROL KEY FUNCTIONS KEYS ACTION RADIO BLUETOOTH Short Power on/off Power on/off Power on/off Power on/off POWER Long Short Zone 1 mute on/off Zone 1 mute on/off Zone 1 mute on/off Zone 1 mute on/off ZONE 1 MUTE Long Short... - Page 13 REMOTE OPERATION KEYS ACTION RADIO BLUETOOTH Short DISP Long Short Recall 1 station Play/pause 1/►II Long Save station to 1 Short Recall2 station 2/INT Long Save station to 2 Short Recall3 station RPT one/all 3/RPT Long Save station to 3 Short Recall4 station RDM on/off...
- Page 14 Maxxsonics, LLC. This warranty is limited to defective parts and specifically excludes any incidental or consequential damages connected therewith. To view the full warranty, please visit the website. MB Quart products are designed and engineered in the USA by www.maxxsonics.com...
