OWNER'S MANUAL
RVM10V1
RVM10V1
10" MECHLESS SOURCE UNIT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RVM10V1 and is the answer not in the manual?

Questions and answers

Related Manuals for MB QUART RVM10V1

Summary of Contents for MB QUART RVM10V1

  • Page 1 OWNER’S MANUAL RVM10V1 RVM10V1 10" MECHLESS SOURCE UNIT...

  • Page 2: Safety Information

    SAFETY INFORMATION CAUTION Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit protect you only if you observe the following procedures for installation, use, and servicing. Notes: • Consult with your nearest dealer if installation requires the drilling of holes or other modifications of the vehicle.

  • Page 3: Din Front/Rear-Mount

    INSTALLATION Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, hot air, heater, or where it would be subject to dust, dirt, or excessive vibration. DIN FRONT/REAR-MOUNT This unit can be properly installed either from “Front”(conventional DIN Front-mount) or “Rear” (DIN Rear-mount installation, utilizing threaded screw holes at the sides of the unit chassis).
  • Page 4 CONNECTIONS V-OUT ZONE 1-R ZONE 2-R R-IN ZONE 1-L ZONE 2-L L-IN HIGH DEFINITION HIGH DEFINITION USB-A THROUGHPUT THROUGHPUT FUSE AM/FM PIN NO. WIRE COLOR LABEL PIN NO. WIRE COLOR LABEL PINK REAR CAM TRIGGER BROWN BRAKE BLUE POWER ANTENNA YELLOW BATTERY+ BLUE/WHITE...

  • Page 5: Source Unit

    SOURCE UNIT RVM10V1 1. IR Remote Sensor 5. Headphone Button 2. Mute 6. High Definition Throughput 3. USB 7. VOLUME + 4. AUX-IN 8. VOLUME -...

  • Page 6: Operation

    OPERATION LOC RDS TURN ON/OFF THE UNIT AND ALL MUTE FUNCTION 95.1 Press the button to turn on the unit. When the unit is powered on, Shortly press this button for both ZONE1 and ZONE2 mute on/off. Press and hold turn off the unit. LOC RDS LOC RDS ZONE1 OR ZONE2 INDIVIDUALLY MUTE OPERATION...
  • Page 7 OPERATION SETTINGS ADJUSTMENT LOC RDS LOC RDS In main menu, press the icon to enter settings menu. Press the corresponding icons to 95.1 adjust: Language/Radio Area/Time/Other/Display/Wallpaper/System Info. 95.1 LANGUAGE SELECTION In this item, you can select: English/Spanish/French/Italian... RADIO AREA In this item, you can select: Europe/USA/South America/Russia TIME SETTING In this item, you can adjust the clock, 12Hr/24Hr format and time synchronization with the station.

  • Page 8: Dimmer Function

    OPERATION DISPLAY In this menu, you can set the value of Brightness/Contrast/Saturability/Hue. WALLPAPER In this menu, you can change the wallpaper. SYSTEM INFO MCU and MPEG software version information. DIMMER FUNCTION LOC RDS In main menu, press the icon to the brightness to LOW/HIGH. LOC RDS 95.1 DISPLAY ON/OFF...
  • Page 9 RADIO OPERATION AUTO-STORE STATIONS This is a useful method to populate available radio stations in a new area. • Press button to automatically store stations to numeric buttons 1-6 of band 1, 2 or (if FM) 3. Stations will store in the order of scanning and reception. Use front panel buttons 1-6 to recall presets.
  • Page 10 MUSIC/VIDEO/PHOTO PLAYING OPERATION When a USB source such as a thumb drive is inserted to the USB port on the front panel of the unit, it supports playback of MP3 and WMA files automatically. SELECTING MUSIC FILE • Press the NEXT ► ► I or PREVIOUS I ◄ ◄ button to skip to next/previous file. •...

  • Page 11: Camera Operation

    BLUETOOTH SOURCE OPERATION BLUETOOTH PAIRING You must first pair a Bluetooth-enabled device to stream music to your unit. • Select “search” or “discover” on the Bluetooth device while the unit is in the BT MUSIC mode. “RVM_10V1” should appear in the list of available devices. Select “RVM_10V1”.

  • Page 12: Remote Operation

    REMOTE OPERATION REMOTE CONTROL KEY FUNCTIONS KEYS ACTION RADIO BLUETOOTH Short Power on/off Power on/off Power on/off Power on/off POWER Long Short Zone 1 mute on/off Zone 1 mute on/off Zone 1 mute on/off Zone 1 mute on/off ZONE 1 MUTE Long Short...
  • Page 13 REMOTE OPERATION KEYS ACTION RADIO BLUETOOTH Short DISP Long Short Recall 1 station Play/pause 1/►II Long Save station to 1 Short Recall2 station 2/INT Long Save station to 2 Short Recall3 station RPT one/all 3/RPT Long Save station to 3 Short Recall4 station RDM on/off...
  • Page 14 RADIO & AUDIO SPECIFICATION MP3/WMA Tuning Range 87.5-107.9MHz 530 - 1710Khz Sensitivity 4uV ( S/N=30dB) 63uV ( S/N=20dB) S/N Ratio 50dB 45dB 60dB Stereo Separation >25dB 50dB Frequency Response 40Hz - 12KHz 100Hz - 2KHz 20Hz - 16KHz AUDIO SUPPORTED FORMATS Audio Format Profile Max Bitrate...
  • Page 15 VIDEO SUPPORTED FORMATS Video Format Resolution Video Decode MPEG4/XVID,DIVX4/DIVX5/MSMPEG4V3,MPEG2,RV1.0/RV2.0/RVG2,RV3.0/RV4.0/RV8 1280x720 720x480 H264/AVC 640x480 DIVX3 MPEG4/XVID,DIVX4/DIVX5/MSMPEG4V3,MPEG2 1280x720 H264/AVC 720x480 DIVX3 640x480 MPEG4/XVID,DIVX4/DIVX5/M MPEG4V3,MPEG2,MPEG1,H2 63,MJPEG 1280x720 H264/AVC 720x480 MOV/MP4 DIVX3 640x480 MPEG2 1280x720 H264/AVC 720x480 MPEG4/XVID,DIVX4/DIVX5/ 1280x720 MPEG4/XVID,DIVX4/DIVX5/ MSMPEG4V3,MPEG2,MPEG1,H2 63,MJPEG 720x480 DIVX3 640x480 H263 1280x720...
  • Page 16 Maxxsonics, LLC. This warranty is limited to defective parts and specifically excludes any incidental or consequential damages connected therewith. To view the full warranty, please visit the website. MB Quart products are designed and engineered in the USA by www.maxxsonics.com...
